OWNER'S MANUAL
PORTABLE GENERATOR
Platinum series:
PRE4000K
PRE6000K
PRE9000KE
IMPORTANT:
Record product information to reference when ordering parts or
obtaining warranty coverage.
Specification
Serial Number
Purchase Date
Read all safety precautions and instructions carefully
before operating equipment.
Ensure engine is stopped and level before performing
any maintenance or service.
www.firmangenerators.com
®
Advertisement
Table of Contents
Summary of Contents for Arman PRE4000K
- Page 1 ® OWNER’S MANUAL PORTABLE GENERATOR Platinum series: PRE4000K PRE6000K PRE9000KE IMPORTANT: Read all safety precautions and instructions carefully before operating equipment. Ensure engine is stopped and level before performing any maintenance or service. Record product information to reference when ordering parts or obtaining warranty coverage.
- Page 2 Thank you for purchasing a FIRMAN generator. This manual covers operation and maintenance of the FIRMAN generators. All information in this publication is based on the latest production information available at the time of approval for printing. Pay special attention to statements preceded by the following words: WARNING Indicates a strong possibility of severe personal injury, loss of life and equipment damage if instructions are not followed.
-
Page 3: Safe Operation Checklist
Safe Operation Checklist Safe operation of the portable generator requires the completion of the following tasks: Carbon Monoxide (CO) Alarm Carbon monoxide (CO) alarm(s) in working order. Smoke Alarm Smoke alarm(s) in working order. Generator Location Generator placed in a Carbon Monoxide (CO) safe zone. See Generator Location to reduce the Risk of Carbon Monoxide Poisoning. -
Page 4: Table Of Contents
Table of Contents 1. SAFETY PRECAUTIONS .................04 2. SPECIFICATIONS..................08 3. COMPONENTS....................09 4. PRE-OPERATION CHECKS................10 5. OPERATING PROCEDURES................14 6. SERVICING THE GENERATOR...............18 7. “HOW-TO” MAINTENANCE................29 8. PREPARATION FOR STORAGE...............22 9. TROUBLE SHOOTING...................23 10. WARRANTY....................24 Page 03... -
Page 5: Safety Precautions
1. SAFETY PRECAUTIONS WARNING POISONOUS GAS HAZARD. Engine exhaust contains carbon monoxide, a poisonous gas that could kill you in minutes. You CANNOT smell it, see it, or taste it. Even if you do not smell exhaust fumes, you could still be exposed to carbon monoxide gas. - Page 6 WARNING Starter cord kickback (rapid retraction) will pull hand and arm toward engine faster than you can let go which could cause broken bones, fractures, bruises, or sprains resulting in serious injury. • When starting engine, pull cord slowly until resistance is felt and then pull rapidly to avoid kickback.
- Page 7 WARNING • This generator does not meet U. S. Coast Guard Regulation 33CFR-183 and should not be used on marine applications. • Failure to use the appropriate U. S. Coast Guard approved generator could result in death or serious injury. WARNING Generator voltage could cause electrical shock or burn resulting in death or serious injury.
- Page 8 WARNING Unintentional sparking could cause fire or electric shock resulting in death or serious injury. WHEN ADJUSTING OR MAKING REPAIRS TO YOUR GENERATOR • Disconnect the spark plug wire from the spark plug and place the wire where it cannot contact spark plug.
-
Page 9: Specifications
2 . SPECIFICATIONS Model PRE 4000K PRE 6000K PRE 9000KE Starting Watts 4000Watts@60Hz 6000Watts@60Hz 7500Watts@60Hz Running Watts 3500Watts@60Hz 5000Watts@60Hz 9000Watts@60Hz Rated AC Voltage 120V/240V Single Phase Phase Voltage regulator Power Factor Alternator Type Brush Engine Model KOHLER CH270 KOHLER CH395 KOHLER CH440 Engine Type Single Cylinder, 4-Stroke OHV Air Cooled... -
Page 10: Components
3. COMPONENTS 1. SOCKET 2. CIRCUIT BREAKER 3. FUEL GAUGE 4. DIGITAL DISPLAY 5. FUEL TANK CAP 6. ENGINE SWITCH 7. FUEL VALVE 8. CHOKE LEVER 9. RECOIL STARTER 10.OIL DRAIN PLUG 11.OIL FILLER CAP 12.GROUND TERMINAL 13.AIR CLEANER 14.SUPPORTING LEGS 15.MUFFLER 16.FUEL TANK 17.HANDLE FRAME... -
Page 11: Pre-Operation Checks
4. PRE-OPERATION CHECKS Remove the Generator from the Shipping Carton 1. Set the shipping carton on a solid, flat surface. 2. Remove everything from the carton except the generator. 3. Carefully cut each corner of the box from top to bottom. Fold each side flat on the ground to provide a surface area to install the wheel kit and support leg. - Page 12 (see table below) to upper level line. Do not screw in the oil filler cap when checking oil level. Change oil if contaminated. (See “HOW TO MAINTENANCE) Oil capacity: Model....Upper level PRE4000K.....0.6 L ECE6000K.....1.1 L ECE9000KE...1.1 L Single grade 10W-30 Multigrade 10W-40...
- Page 13 Check fuel level at fuel gauge. If fuel level is low, refill with unleaded automotive gasoline. Be sure to use the fuel filter screen on the fuel filter neck. Fuel tank capacity: PRE4000K.....4 Gallon PRE6000K.....7 Gallon PRE9000KE...7 Gallon Fuel must meet these requirements: EMPTY FULL •...
- Page 14 CHECKING GENERATOR SURROUNDINGS Make the generator using in proper position. The generator is very easy to move, take the handle up and then use your leg to make a fulcrum, you can very relaxed to make the generator tilt. Two wheels help you to move the generator very relaxed.
-
Page 15: Operating Procedures
5. OPERATING PROCEDURES STARTING NOTE: Choke is not required to start a warm engine. Push choke lever in to original position. 1.Turn main AC circuit breaker “OFF”. 2. Turn Fuel cock “ON”. 3. Turn engine switch to “ON” position and pull rope (or push start button for electric start). - Page 16 USING ELECTRIC POWER (a) Check the digital display for proper voltage. This generator is thoroughly tested and adjusted in the factory. If the generator does not produce the specified voltage, consult your nearest FIRMAN Generator dealer. (b) Turn off the switch(es) of the electrical appliance(s) before connecting to the generator.
-
Page 17: Operation At High Altitude
Operation at High Altitude The density of air at high altitude is lower than at sea level. Engine power is reduced as the air mass and air-fuel ratio decrease. Engine power and generator output will be reduced approximately 3% for every 1000 feet of elevation above sea level. - Page 18 STOPPING THE GENERATOR (a) Turn off the power switch of the electric equipment or unplug the cord from receptacle of the generator. (b) Allow the engine about 3 minutes to cool down at no-load before stopping. (c) Set the engine switch to "OFF" position. (d) Close (stop) the fuel lever.
-
Page 19: Servicing The Generator
6. SERVICING THE GENERATOR MAINTENANCE SCHEDULE Maintenance Schedule After first 5 Hours ● Change oil. Every 25 Hours or Annually ● Check starter battery . Every 100 Hours or Annually ● Clean low-profile air cleaner element . ● Change oil. ●... -
Page 20: How-To" Maintenance
7. "HOW-TO" MAINTENANCE ENGINE OIL CHANGE Change engine oil every 100 hours. (for a new engine, change oil after 5 hour.) Please use a container to load the NOTE: used oil for protecting environment. 1. Clean area around oil fill cap/dipstick (N) and oil drain plug (M). - Page 21 CLEANING AND ADJUSTING SPARK PLUG (a) If the plug is contaminated with carbon, using a plug cleaner and wire brush. (b) Adjust the electrode gap to 0.7 to 0.8 mm (0.028” to 0.031”). SPARK PLUG: NGK BPR6HS equivalent. CLEANING FUEL STRAINER Dirt and water in the fuel are removed by the fuel strainer.
- Page 22 Inspect Muffler and Spark Arrester Inspect the muffler for cracks, corrosion, or other damage. Remove the spark arrester, if equipped, and inspect for damage or carbon blockage. If replacement parts are required, make sure to use only original equipment replacement parts. WARNING Exhaust heat/gases could ignite combustibles, structures or damage fuel tank causing a fire, resulting in death or serious injury.
- Page 23 8. STORAGE The following procedures should be followed prior to storage of your generator for periods of 3 months or longer. Drain fuel from fuel tank carefully. Gasoline left in the fuel tank will eventually deteriorate making engine-starting difficult. Loosen the drain screw on the bottom of the carburetor float chamber, and drain the fuel completely.
-
Page 24: Trouble Shooting
9. TROUBLE SHOOTING Problem Cause Correction 1. Circuit breaker is open. 1. Reset circuit breaker. 2. Fault in generator. 2. Contact authorized service facility. Engine is running, but no 3. Poor connection or defective cord 3. Check and repair. AC output is available. set. - Page 25 10.Kohler engine 3 Year Limited Warranty Kohler Co. warrants to the original retail consumer that each new engine will be free from manufacturing defects in materials or workmanship for the applicable coverage period as set forth below, beginning on date of purchase; provided the engine is operated and maintained in accordance with Kohler Co.’s instructions and manuals.
- Page 26 OWNER’S WARRANTY RESPONSIBILITIES: As the SORE or engine powered equipment owner, you are responsible for the performance of the required maintenance listed in your owner’s manual. Kohler Co. recommends that you retain all receipts covering maintenance on your SORE or engine powered equipment, but Kohler Co. cannot deny warranty solely for the lack of receipts. As the SORE or engine powered equipment owner, you should however be aware that Kohler Co.
-
Page 27: Warranty
FIRMAN GENERATOR 3 YEAR LIMITED WARRANTY Proof of purchase must be presented when requesting warranty service. This product is manufactured by SUMEC MACHINARY & ELECTRIC Co, Ltd. WHAT IS COVERED UNDER THE 3 YEAR LIMITED WARRANTY This FIRMAN® generator is warranted to the original purchaser only to be free from defects in material and workmanship subject to certain exceptions and limitations stated below, for a period of three (3) years after date of purchase. - Page 28 WWW.FIRMANGENERATORS.COM Toll Free:1-844-347-6261 P/N:335735001 Rev 00...
