OWNER'S MANUAL AND
OPERATING INSTRUCTIONS
2 - WAY COMMUNICATOR
PLEASE READ THIS
OWNER MANUAL
CAREFULLY BEFORE USE.
KEEP FOR YOUR
REFERENCE.
FOR INSTALLATION INSTRUCTIONS PLEASE SEE PAGE 6.
Contents
Preparation
Communicator Controls - Location & Function ....................................... 4
Getting Started
Removing Belt Clip ....................................................................................... 6
Installing Belt Clip ......................................................................................... 6
Battery Installation ....................................................................................... 7
LCD Screen ................................................................................................... 8
Turning the Unit ON ...................................................................................... 9
Turning the Unit OFF ...................................................................................... 9
Adjusting Speaker Volume .......................................................................... 9
Receiving a Signal ....................................................................................... 9
Transmitting a Signal .................................................................................... 9
Operation
Changing Channels .................................................................................... 10
Monitor .......................................................................................................... 10
Enter / Back-Light / Button Lock ................................................................ 10
Channel Scan .............................................................................................. 11
Sending Call Tones ....................................................................................... 11
Battery Level Indicator ................................................................................ 12
BUSY
DW
SCAN
VOX
C
M
2
Special Features
PRODUCT DESCRIPTION
The COMMUNICATOR is the newest generation in personal two-way
communications. The COMMUNICATOR operates in a radio band , on
any of the 40 channels. (Refer to "channel table" section on page 19 for
more information.)
The COMMUNICATOR is a lightweight, compact two-way communication
device that can be used to communicate with family or friends at parks,
shopping malls, sporting events, concerts -- any indoor or outdoor activity!
The COMMUNICATOR is compatible with other brands utilizing the same
frequency band (operating in the frequency range from 476.425MHz to
477.400MHz).
The COMMUNICATOR has 40-CHANNELS, featuring a multi-functional LCD
Screen (which displays the current channel and various status icons).
Other features include ELECTRONIC VOLUME CONTROL, BATTERY SAVE
CIRCUITRY and DUPLEX MODE.
Please read this Owner's Manual carefully to get the most out of your
TWO-WAY COMMUNICATOR.
NOTE: The maximum transmission range will vary depending on terrain
and environment. Range will be greater in open fields, while range
is shorter within and around buildings or large structures.
This unit may not ensure privacy of communication.
Contents
Battery Charge Indication .......................................................................... 12
To Charge the Communicator ................................................................... 12
Dual Watch .................................................................................................. 13
Internal VOX Control Function ................................................................... 13
Second Counter Function ......................................................................... 14
Duplex Function .......................................................................................... 14
Other Information
Troubleshooting ............................................................................................ 15
Care and Maintenance .............................................................................. 16
Specifications ............................................................................................... 19
1
