TRACKER ™ HUB
HUB Components Received .......................................................................................................................................................... 2
Wired TR Configuration .................................................................................................................................................................. 2
Wireless TR Configuration ............................................................................................................................................................. 2
Optional HUB Components ............................................................................................................................................................ 3
Establishing a Wireless Network ................................................................................................................................................... 4
Establishing a Wired TR Network .................................................................................................................................................. 4
HUB Overview ................................................................................................................................................................................. 5
HUB Input/Output Panels .......................................................................................................................................................... 5
Powering Up Your HUB ................................................................................................................................................................. 5
Powering Up Your TRs .................................................................................................................................................................. 5
Getting Started ................................................................................................................................................................................ 6
Tools Menu ................................................................................................................................................................................. 7
Display Items. .......................................................................................................................................................................... 7
Linear Display.......................................................................................................................................................................... 7
Trackers .................................................................................................................................................................................. 7
Tracker Settings ...................................................................................................................................................................... 8
HUB Options ........................................................................................................................................................................... 8
Systems Menu ............................................................................................................................................................................ 9
Color Types ............................................................................................................................................................................. 9
Languages............................................................................................................................................................................. 10
Status Types ......................................................................................................................................................................... 12
Status Languages ................................................................................................................................................................. 13
Tracker Menu. ........................................................................................................................................................................... 14
Color ...................................................................................................................................................................................... 14
Language .............................................................................................................................................................................. 14
Status. ................................................................................................................................................................................... 15
Visibility ................................................................................................................................................................................. 15
by Output Technology, Inc.
www.TrackMyOps.com
HUB User's Manual
EMAIL: sales@TrackMyOps.com
TEL:
(763) 546-9078
Advertisement
Table of Contents
Summary of Contents for Tracker HUB
-
Page 1: Table Of Contents
Establishing a Wireless Network ..............................4 Establishing a Wired TR Network ..............................4 HUB Overview ....................................5 HUB Input/Output Panels ................................5 Powering Up Your HUB ................................. 5 Powering Up Your TRs .................................. 5 Getting Started ....................................6 Tools Menu ....................................7 Display Items. -
Page 2: Hub Components Received
Wireless TR Kit: Required for Each Wireless TR Wireless Client One (1) 3-ft Cat5 Cable WIFI Cat003 Power Requirements: 120/220V, 50/60Hz, Grounded Plug. TrackMyOps.com Page 2 See training videos at ©Output Technology, Inc. Jan15.—All rights reserved. Specifications subject to change. TRACKER™ Real-Time, Real Results... -
Page 3: Optional Hub Components
100-ft Cat100 and wireless USB keyboard and mouse. 250-ft Cat250 All optional components are available for purchase at TrackMyOps.com TrackMyOps.com Page 3 See training videos at ©Output Technology, Inc. Jan15.—All rights reserved. Specifications subject to change. TRACKER™ Real-Time, Real Results... -
Page 4: Establishing A Wireless Network
Ethernet switch Port 1. Connect Ethernet cable from Ethernet port Port 1: Wireless Router Ports 2-16: TRs to Ethernet switch Ports 2-16 TrackMyOps.com Page 4 See training videos at ©Output Technology, Inc. Jan15.—All rights reserved. Specifications subject to change. TRACKER™ Real-Time, Real Results... -
Page 5: Hub Overview
HUB User’s Manual HUB Overview HUB Input/Output Panels Please note: additional in/out ports not listed are not used for HUB operation. Front Panel 2 Female USB 3.0 Ports 1 Female USB 2.0 Port Power ON/RESTART Button Power (Rear) Power Supply... -
Page 6: Getting Started
HUB User’s Manual Getting Started At this point you should have your HUB powered on, TRs powered on, your TR network powered on. Move curser to the top left of the window in the OTI-HUB program and three menus will appear: Tools Menu ... -
Page 7: Tools Menu
Linear Display: toggle between linear and grid displays. 16 TR units can be connected to a HUB. The first 8 selected TRs will appear on Screen #1, and 9-16 on Screen #2. In Linear Display, the first selected TR unit will display at the top of screen then fill down the screen from 1-8 in rows. -
Page 8: Tracker Settings
Tracker Settings: change Job Information and Tracker Setting from the HUB. The top line item, “Tracker” contains a drop-down list of currently connected TRs. The TRs name is the “Machine Id” entered in the TR’s “Tracker Settings” screen. Select which TR unit to which changes will be made. -
Page 9: Systems Menu
HUB User’s Manual System Menu Changes made in the Systems menu are saved as templates; update TR units in the Tracker menu. Color Types: change the colors and appearance of the TR units. Colors are configured with the RGB color model. Use any web browser to look up an RGB table for reference. - Page 10 Add New to save a new template and preserve the original. Click Close to exit the dialog box. TrackMyOps.com Page 10 See training videos at ©Output Technology, Inc. Jan15.—All rights reserved. Specifications subject to change. TRACKER™ Real-Time, Real Results...
-
Page 11: Languages
Languages: edit or add new languages for TR units. In this dialog box, the left column is for reference of a current language in the HUB, and the right column is to modify each label used in TR operations for a selected language. The default operating language for TR units and the HUB is English (US). -
Page 12: Status Types
Timeout Active: this box is checked if after a set amount of time (Pulse Timeout field in the “Update Tracker Settings” screen on the TR unit) the TR will go into an “Undefined” status if the opposite of the Expect Pulses setting is happening. -
Page 13: Status Languages
Click Update to save changes. Click Close to exit the dialog box. TrackMyOps.com Page 13 See training videos at ©Output Technology, Inc. Jan15.—All rights reserved. Specifications subject to change. TRACKER™ Real-Time, Real Results... -
Page 14: Tracker Menu
<< . The selected language will be removed from the right column. Click Close to exit the dialog box. TrackMyOps.com Page 14 See training videos at ©Output Technology, Inc. Jan15.—All rights reserved. Specifications subject to change. TRACKER™ Real-Time, Real Results... -
Page 15: Status
Check the box to make a Display Item visible. For example, if you want to change Job Information and Tracker Settings for a TR unit only from the HUB in Tools > Tracker Settings, and remove the buttons on the TR, uncheck the “update info”...
