Contents Safety Precautions Power Supply..............................1 Installation................................2 Use and Maintenance............................3 Important Safety Instructions ..........................4-5 User Guidance Information Names of each part(Front View) / Accessories ....................6 Names of each part(Back View) ........................7 Remote control ..............................8-9 Basic Operation Basic Operation ..............................
Names of each part Front View INPUT MENU VOL- VOL+ STANDBY INPUT: Display the input source menu. MENU: Display/exit the OSD menu. CH+/-: Scan through channels. VOL+/-: Adjust the volume. STANDBY: Turn on/standby the TV set. INFO INPUT ENTER MENU EXIT TV/RADIO CH.LIST...
Names of each part Back View AC POWER IN Coax VIDEO Headphone HDMI1 HDMI2 HDMI3 AC POWER IN: Connect it to AC100-240V~ 50/60Hz power supply. Headphone : Connect it to your headphone or other audio equipment. HDMI1/2/3: Connect it to the HDMI of DVD or other equipment. Video : Connect it to video output terminal of DVD.
Remote Control POWER: Turn the TV on/standby. MUTE: Press to mute the sound, press again or press VOL+ to unmute. NUMBER BUTTONS Press 0-9 to select a TV channel directly when you are watching TV. Return to the previous channel viewed. INFO INFO: Press to display the current mode's/TV channel's information.
Remote Control INFO Colour buttons: Short cuts-follow the coloured links in the text INPUT Stop program. Play/Pause program. Fast reverse. Fast forward. Previous chapter. Next chapter. ENTER TV/TXT: Turn off/on the Teletext display. MENU EXIT CANCEL: Cancel the Teletext display. REVEAL: Reveal any hidden text.
Basic Operation Power on/off 1. Connect to the power supply with the power cord. 2. -To turn on the TV Press STANDBY button on the TV or remote control. -To turn off the TV Press STANDBY button on the TV or remote control. Input Source select Press INPUT button on the TV set or remote control to display the input source menu, and use CH+/- button on the TV set or...
OSD Menu 1. Picture menu Description Picture Mode: Select your desired picture mode from Dynamic, Standard, Mild and User. Brightness: Adjust image black level. Contrast: Adjust image contrast. Sharpness: Adjust the sharpness(Gray and invalid in VGA/PC mode). Colour: Adjust image colour from black and white. Tint: Control the tint ( NTSC mode only).
OSD Menu 2. Sound menu Description Sound Mode: Select your desired sound mode from Standard, Movie, Music, Speech and User. Bass: Adjust the level of the lower-pitched sounds. Treble: Adjust the level of the higherpitched sounds. Balance: Adjust the audio output between left and right speakers. Surround: Turn on/off the surround sound function.
OSD Menu 3. Channel menu(In ATV/DTV mode) Australia Description Channel Management: Enter the Channel management menu to edit the channels. Delete: Press RED button to sign the channels you want to delete, it will hint you when you exit. Lock: User must set the “Lock enable”(Feature-Lock- Lock enable) at ON to active this function.
Page 17
OSD Menu Country: Select the country. When the Child Lock is on, please enter the Password (Lock Password in Feature menu) to start Auto and Manual Search. Auto Search: Press OK button to enter the Auto Search menu, select search mode, and press OK button to start auto search.
OSD Menu 4. Feature menu Description Lock: This menu allows you to lock certain features of the television so that they can not be used or viewed. For example if you don’t want certain channels viewed by children or if the television is to be used in a hotel and you want certain channels be locked.
Page 19
OSD Menu Language: Lets you adjust the different language options available. Clock: Allows you to set the clock (as default the information is taken automatically from the digital signal). Sleep Timer: Lets you set the sleep timer so the television automatically switches off after a certain amount of time.
OSD Menu 5. Setup menu Description OSD Timer: Lets you adjust the amount of time the On Screen Menu stays on the screen before disappearing. PC Setup: Change the PC Settings in PC mode. Auto Adjust: Setup the parameter of the screen automatically. H/V-Position: Adjust the transverse/vertical position of the screen.
Multimedia Operation Basic Operation 1). Press the INPUT button on the remote control to display the input source menu, select Media source by the buttons, and press OK button to enter the Multimedia menu as shown below. 2). Insert USB device, and select the Media mode form Photo, Music, Movie and eBook, then you will find the name of the device display on the screen as shown below.
Page 22
Multimedia Operation 1. Photo Play the photo OK button to change. Press button to select the option on the table, and press Note: You could press OK button to display the option table when it disappears. Play/Pause the photo playing. Stop and exit the full screen program.
Page 23
Multimedia Operation 3. Movie Play the movie Press button to select the option on the table, and press OK button to change. Note: You could press OK button to display the option table when it disappears. Play/Pause the movie playing. Stop and exit the full screen program.
Recording Operation PVR settings Press the MENU button select Feature-PVR/Timeshift menu, press OK button to enter the menu as below. 1). Record File Format Select Record File Format mode from TS and PS for storing in the USB device. 2). Partition Select USB device informations Format: Press RED button to format the selected USB device.
Page 25
Recording Operation 5). Record List Display the Record list menu. Delete: Press RED button to delete the selected record plan. 6). Recorder Start Press OK button to start recording, as the function of the REC button on the remote control. EPG and Timer Record Press EPG button on the remote control to display the EPG menu.
Recording Operation Recording Press REC button on the remote control to start recording in DTV mode, and the TV will give you a hint. Select “OK” item, and press OK to start recording, there will be a sign on the screen. Note: a.
Trouble shooting Do not use other functions that are not mentioned in this user’s manual. In case a problem occurs with your TV, please take the following steps first. If you still have the problem, turn the power off and contact your dealer or an authorized service center. i t c Is the power plug pulled out? Insert the power plug.
