Summary of Contents for TIA NC-9900
-
Page 3: Table Of Contents
CONTENTS Safety Precautions Introduction III. Prior to Use Product Description (tia NC-9900) Using your tia Settings o Unit of Measure o Alarm Setup o Body or Surface Mode o Total Variation o Laser / Light Setup o Memory Data o Battery Changing VII. -
Page 4: Safety Precautions
122°F (50°C) Do not use thermometer if relative humidity is greater than 85% • Always protect glass over the lens (this is the most fragile part of your tia • thermometer) Do not touch glass of infrared lens with fingers or objects •... -
Page 5: Prior To Use
As with all thermometers, the tia NC-9900 must be used properly in order to obtain reliable and consistent results. Read ALL instructions and safety precautions prior to use. III. PRIOR TO USE • tia NC-9900 is pre-set at the factory •... - Page 6 97.0°F - 100.0°F (36.1°C - 37.8°C) 11 - 65 years: 96.6°F - 99.7°F (35.9°C - 37.6°C) > 65 years: 96.4°F - 99.5°F (35.8°C - 37.5°C) DESCRIPTION OF tia NC-9900 1. Laser pointer lens 6. Fahrenheit 2. Infrared Sensor 7. Memory 3.
-
Page 7: Using Your Tia
• Wipe away any perspiration • Avoid drafts (e.g. vents, another person’s breath, etc.) If a temperature change of the environment occurs, allow your tia NC- • 9900 to reach current room temperature (about 15 – 20 minutes) before using •... - Page 8 Measurement range for BODY mode 90°F - 109°F (32°C - 42.9°C) • You can also use your tia NC-9900 to measure the temperature of an area or an object, a food, a liquid or a room temperature by changing to...
- Page 9 • Important Note: Area temperature differs from internal body temperature. To obtain the internal temperature of a person to determine whether or not fever is present it is essential that your tia NC-9900 is set to BODY mode. • To change from BODY to SURFACE mode Press trigger to activate unit Press and hold “°C”...
-
Page 10: Battery Changing
6. Date setting • Press trigger to activate unit • Press and hold ∆ button for approximately 3 seconds to display year • Press “°C” button to advance one year • Press “°F” button to go back one year • Press ∆... -
Page 11: Functions
Nest battery inside the compartment Close compartment • Take care with proper positioning of battery • Incorrect battery attachment may void warranty of your tia NC-9900 • Always use regular single-use batteries • Never use rechargeable batteries in the tia NC-9900 VII. -
Page 12: Specifications
ADDITIONAL USES: tia NC-9900 can also be used to measure the temperature of a baby-bottle, bath, or room temperature (by using the surface temperature function). This function is in accordance with the directive 89/336/EEC Electromagnetic Compatibility. ADVANTAGES OF TEMPORAL ARTERY (TA) TEMPERATURE Infrared arterial temperature can be measured using a device placed near the forehead, in the temporal artery region. -
Page 13: Troubleshooting
One 9-volt battery • Your tia NC-9900 TROUBLESHOOTING Should a problem occur with your tia NC-9900, follow the guidelines below to help resolve the issue. If problem persists, please contact our customer service department at cs@americocorp.com Display shows temperature greater than 95°F •... - Page 14 Display shows “HI” Indicates that temperature reading is above the normal measurement range Above 109°F (42.9°C) in BODY mode Above 140°F (60°C) in SURFACE mode • Display shows “LO” Indicates that temperature reading is below the normal measurement range Below 90°F (32°C) in BODY mode Below 32°F (0°C) in SURFACE mode Other reasons for display to show “LO”...
