Tyco Electronics F08 Installation & Programming Manual

Fire alarm panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TYCO ELECTRONIC PRODUCT GROUP
F08 INSTALLATION & PROGRAMMING MANUAL
Document Number
Document Title
Manual Volume
Word Processor
File Name
Printer
Current Issue
LT0082 Issue 3.0 Amendment 0
Prefix
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
Appendix A1 :
Appendix A2 :
Appendix A3 :
1.
Paper Type:
2.
Manual Size:
3.
Place in 4-ring binder
Front and spine inserts to be fitted with labels stating:
TYCO F08
INSTALLATION & PROGRAMMING
5.
All pages are double sided, except for the diagrams at the end of the manual.
Chapter 0
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
Appendix A1-3
Drawings
DOCUMENT DATA SHEET
DO NOT PRINT
LT0082
F08 Installation & Programming Manual
1
Word 2000
G:\CH_TSP_All Staff\VIGDOCS\MANUALS\F08\LT0082 Iss 3.04.DOC
HP Laserjet 4M Plus
Issue 3.04, 24 March 2006
:
Introduction
:
FIP Installation
:
Placing into Operation
:
Programming
:
Application Considerations
Compatible Batteries
Compatible Actuating Devices
Installation Drawings
Zone Designation Label
PRINTING SPECIFICATIONS
80gsm Bond White
A4
LT0082
6
=
4
=
34
=
8
=
24
=
14
=
6
=
96
+
3
double-sided
2
double-sided
17
double-sided
4
double-sided
12
double-sided
7
double-sided
3
double-sided
48
5 single-sided
PAGE 1 OF 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F08 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tyco Electronics F08

  • Page 1 TYCO ELECTRONIC PRODUCT GROUP PAGE 1 OF 1 F08 INSTALLATION & PROGRAMMING MANUAL DOCUMENT DATA SHEET DO NOT PRINT Document Number LT0082 Document Title F08 Installation & Programming Manual Manual Volume Word Processor Word 2000 G:\CH_TSP_All Staff\VIGDOCS\MANUALS\F08\LT0082 Iss 3.04.DOC File Name...
  • Page 2 F08 Installation & Programming Manual Document No: LT0082 THIS PAGE INTENTIONALLY LEFT BLANK Page ii 24 March 2006 Issue 3.04...
  • Page 3 INSTALLATION & PROGRAMMING MANUAL F08 PRODUCT MANUAL DOCUMENT: LT0082 Issue 3.04; 24 March 2006 The F08 Fire Indicator Panel is manufactured for Tyco Services Fire & Safety 47 Gilby Road Mt Waverley VIC 3149 AUSTRALIA Tel : +61-3-9538 7220 Fax : +61-3-9538 7255...

  • Page 4: Non-Disclosure Agreement

    The F08 Fire Indicator Panel provides a configuration programming facility which may be accessed via a programming push-button. Because this programming facility allows the user to define in detail the operation of the F08 System, changes may be made by the user that prevent an installation from meeting statutory requirements.

  • Page 5: Table Of Contents

    Document No: LT0082 F08 Installation & Programming Manual TABLE OF CONTENTS NON-DISCLOSURE AGREEMENT..................ii END USER LIABILITY DISCLAIMER ...................ii AMENDMENT LOG ......................v 1. INTRODUCTION ......................1-1 USING THIS MANUAL ..................... 1-2 ASSOCIATED DOCUMENTATION................1-3 TERMINOLOGY ....................... 1-4 2. FIP INSTALLATION ......................2-1 OVERVIEW.......................
  • Page 6 F08 Installation & Programming Manual Document No: LT0082 COMMISSIONING CHECKLIST................3-6 4. PROGRAMMING......................4-1 PROGRAMMING FEATURES.................. 4-2 ENTERING PROGRAMMING MODE............... 4-5 EXITING PROGRAMMING MODE ................4-6 RESET TO DEFAULT PARAMETERS ..............4-7 PROGRAMME ZONE TO OUTPUT MAPPING............4-8 PROGRAMMING ZONES AS LATCHING OR NON-LATCHING ......4-12 PROGRAMMING ZONE INPUT TYPE ..............

  • Page 7: Amendment Log

    Combined Installation, Programming and Brigade Kit Documentation. 28 May 98 Converted to Word 95 document. 27 Oct 98 For V3.00 F08 software, additional input types, 2769 RAD/SAD, etc, 15V MCP, Resistor EOL. 3.01 31 Jul 02 Prefix, Pages 2-6, 2-7, 2-27, 5-6….5-12, Appendix A 3322 revised.
  • Page 8 F08 Installation & Programming Manual Document No: LT0082 THIS PAGE INTENTIONALLY LEFT BLANK Page vi 24 March 2006 Issue 3.04...

  • Page 9: Introduction

    Document No: LT0082 F08 Installation & Programming Manual Introduction INTRODUCTION Issue 3.04 24 March 2006 Page 1-1...

  • Page 10: Using This Manual

    USING THIS MANUAL This Manual provides information for personnel engaged in the installation, programming and commissioning of the F08 Fire Alarm Panel. It is available only to bonafide installation and maintenance organisations. The structure of this manual is as follows: Chapter 1, Introduction, describes the manual, explains the format and terminology used in this manual, and lists associated F08 product manuals.

  • Page 11: Associated Documentation

    F08 Operator's Manual, provides a complete guide to the operation and maintenance of the F08 FIP, according to Australian Standards AS1603 Part 4. This manual is provided as standard with F08 FIP panels. It is available in a bound A5 format (LT0054) and in an A4 loose-leaf format (LT0078).

  • Page 12: Terminology

    FIP alarm signals. Fire Indicator Panel "FLT" Display abbreviation for FAULT Flat Ribbon Cable GLOBAL No F08 zone/output/battery selected. (i.e. all "SEL" LED indicators are OFF) "ISO" Display abbreviation for ISOLATED Light Emitting Diode MAPPING Programming AZCs to control outputs...

  • Page 13: Fip Installation

    Document No: LT0082 F08 Installation & Programming Manual FIP Installation FIP INSTALLATION Issue 3.04 24 March 2006 Page 2-1...

  • Page 14: Overview

    F08 Installation & Programming Manual Document No: LT0082 FIP Installation OVERVIEW This chapter describes in detail the following FIP installation procedures: Cabinet Installation Mains Wiring Battery Installation MCP Wiring Alarm Zone Wiring & Circuit Types Bell Output Wiring Supervised Ancillary Relay Output Wiring...

  • Page 15: Cabinet Installation

    F08 Installation & Programming Manual FIP Installation CABINET INSTALLATION The location of the F08 FIP is determined by the FIRE AUTHORITY and the OWNER or OWNERS' REPRESENTATIVE in accordance with the current Australian Standard AS1670.1. The cabinet is normally fixed to a wall with four (4) 6 mm screws or bolts. The drilling details are shown in Figure 2.1.
  • Page 16 F08 Installation & Programming Manual Document No: LT0082 FIP Installation │───────────────────────────────────│ │ │ ┌───────────────────────────────────────────┐ ─── │ │ │ │ │ 50 │ │ │ │ │ ───────────────│── o ───────────────────────────────── o ──│──── │ │ │6.5 6.5│ │ │ │ │ │...
  • Page 17 Document No: LT0082 F08 Installation & Programming Manual FIP Installation ▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄▄ │ │ │ │ │ 0.5m │ F08 FIP │ 0.5m │ │ │ │ │ ───── ┌──────────── └┬┬──────────────────────┘ ───────────┐ │░░░░░░░░░░░░░░││░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░│ │░░░░░░░░░░░░░░││░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░│ │░░░░░░░░░░░░░░││░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░│ │░░░░░░░░░░░░░░││░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░│ │░░░░░░░░░░░░░░││░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░│ │░░░░░░░░░░░░░░││░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░░│ │░░░░░░░░░░░░░░││░░░░░░░░░ AS1670 CLEAR AREA ░░░░░░░│...

  • Page 18: Mains Wiring

    F08 Installation & Programming Manual Document No: LT0082 FIP Installation MAINS WIRING Mains wiring must be done in accordance with AS1670.1 and AS3000 Wiring Regulations. * * WARNING * * Ensure mains is isolated at Distribution Board before connecting or inspecting mains wiring.
  • Page 19 Document No: LT0082 F08 Installation & Programming Manual FIP Installation THIS PAGE INTENTIONALLY LEFT BLANK Issue 3.04 24 March 2006 Page 2-7...

  • Page 20: Main Board

    F08 Installation & Programming Manual Document No: LT0082 FIP Installation MAIN BOARD Figure 2.4 shows the basic layout of the F08 FIP Main Board. 2.4.1 TERMINALS The following terminals and connectors are provided: Display FRC Output Connector. 12 Way Screw Input Terminal for MCP AZC, MCP, AZC1, AZC2 and AZC3.
  • Page 21 Document No: LT0082 F08 Installation & Programming Manual FIP Installation Figure 2.4 F08 Main Board Layout Issue 3.04 24 March 2006 Page 2-9...
  • Page 22 FIP Installation 2.4.4 FIELD SUPPLY CONNECTIONS The F08 FIP Main Board provides two types of fused power outputs. Terminals labelled "+VB" provide 27.3 VDC supply output, which is battery backed. "+VB" terminals are fused by F2. Terminals labelled "+VNB" provided a non-battery backed 27.9 VDC supply output.

  • Page 23: Battery Installation

    * * NOTES * * The F08 system should be system tested before connecting the batteries. If the batteries are located remotely from the F08, a battery protection device (> 3 Amps) must be located at the batteries. USE ONLY THE BATT+ & BATT- TERMINALS PROVIDED. PARALLEL CONNECTION OF BATTERIES IS NOT PERMITTED.

  • Page 24: Fip Mcp Wiring

    F08 Installation & Programming Manual Document No: LT0082 FIP Installation FIP MCP WIRING The front door manual call point is factory connected by four wires to the "MCP" connector J2, located at the top left hand side of the Main Board, and to ZONE 1 (AZC1).

  • Page 25: Alarm Zone Wiring & Circuit Types

    Detector positioning, installation and wiring must conform with AS1670.1 and detector manufacturer's instructions. The F08 EOL resistor (2k7 1%) must be fitted to the base of the last detector/MCP on each AZC. If the circuit is disabled the resistor may be left off to reduce current consumption.
  • Page 26 F08 Installation & Programming Manual Document No: LT0082 FIP Installation Detector Detector AZC# Figure 2.8 Example of Correct AZC Detector/MCP Wiring 2k7 1% EOL Resistor Last Detector on Alarm Zone Circuit Figure 2.9 Correct EOL Wiring Page 2-14 24 March 2006...
  • Page 27 Document No: LT0082 F08 Installation & Programming Manual FIP Installation ┌─┐ ┌──────┐ ┌──────┐ ┌──────┐ │ ├─┤ │E├───┼o+ +o┼──┼o+ +o┼── ─ ─ ─ ─ ─┼o+ +o┼───────────────┤O│ + │O│ │OUT IN│ │OUT IN│ │OUT IN│ │ ├─┤AZC │L├───┼o- -o┼──┼o- -o┼── ─ ─ ─ ─ ─┼o- -o┼───────────────┤O│...
  • Page 28 F08 Installation & Programming Manual Document No: LT0082 FIP Installation 2.7.2 INPUT TYPES Each AZC can be programmed with one of ten different input types (refer Section 4.7). These types are defined as follows and in Table 2.1. Input Type 1 : Standard Standard detector circuit without AVF.

  • Page 29: Input Types

    Document No: LT0082 F08 Installation & Programming Manual FIP Installation INPUT TYPES (CONTINUED) Input Type 9 : Loop Powered Circuit / Fast Alarm 0-13V band is alarm with half a second delay into alarm. 13-17V band is normal for 15V loop powered circuit.

  • Page 30: Bell Output Wiring

    The Bell Monitor Board can support wiring of up to 3 separate branches (each with an EOL resistor), and a load current of 1.0A (as limited by the F08 Bell Output). The end of line resistor depends on the number of branches.
  • Page 31 Document No: LT0082 F08 Installation & Programming Manual FIP Installation /\/\/\/\/\/\/\/\/│ │ ──────── ┌┬─┐ │ ││O│ │ │├─┤ │ ││O│ │ │├─┤ │ ││O│ │ ──────── │├─┤ │ ││O│ │ │├─┤ │ ││O│ │ │├─┤ │ ││O│ │ │├─┤ │...
  • Page 32 PA0494 24V BELL EVAC MONITOR BOARD * EOL Value – Refer to Bell Monitor Installation Instructions LT0190 PA0730 24V RELAY BOARD F08 EOL Cut Lk1 Figure 2.12 F08 Bell Output with PA0494 Bell Monitor Board Page 2-20 24 March 2006 Issue 3.04...
  • Page 33 F08 as well as, or instead of, the standard bells output. There are four ways to connect the T-GEN to the F08. For each the T-GEN must be powered from the battery terminals through a 3A slow blow fuse and T-GEN’s DEF- output wired into an AZC input to signal a fault with the wiring.
  • Page 34 SOLDER WIRE FROM TOP +VNB HOLDER TO 0V BATT+ BELLS+ BATT- REMOVE BELLS EARTH FUSE F1 SLOW T-GEN 50 +24V BLOW FUSE +24V ALM- A/I/F- DEF- Figure 2.13A F08 using T-GEN on Bells Relay Page 2-22 24 March 2006 Issue 3.04...
  • Page 35 MAIN BOARD ANCILLARY AZC+ PROGRAM INPUT AZC- TYPE 8 +VNB BATT+ BELLS+ BATT- EARTH SLOW T-GEN 50 +24V BLOW FUSE +24V ALM- A/I/E- DEF- Figure 2.13B F08 using T-GEN on Ancillary Relay Issue 3.04 24 March 2006 Page 2-23...
  • Page 36 FIP Installation Connect T-GEN using the Alarm Relay. As the F08’s Brigade Interface has two Alarm contacts, the second set of contacts may be used to activate T-GEN as shown in Figure 2.13C. This method has some limitations. All zones that are required to operate the T-GEN must be mapped to Master Alarm as well.
  • Page 37 AUX4 AUX5 AUX6 AUX7 AZC+ PROGRAM INPUT AUX8 AZC- TYPE 8 BATT+ +VNB BATT- EARTH SLOW T-GEN 50 +24V BLOW FUSE +24V ALM- A/I/E- DEF- Figure 2.13D F08 using T-GEN via Auxiliary Outputs Issue 3.04 24 March 2006 Page 2-25...

  • Page 38: Ancillary Relay Output Wiring

    F08 Installation & Programming Manual Document No: LT0082 FIP Installation ANCILLARY RELAY OUTPUT WIRING The "ANCILLARY" relay on connector block J8 provides voltage free changeover contacts. Terminals available are: COM - Common NC - Normally Closed NO - Normally Open SUP - Input for supervision (Not voltage free).
  • Page 39 Document No: LT0082 F08 Installation & Programming Manual FIP Installation /\/\/\/\/\/\/\/\/│ │ ──────── ┌┬─┐ │ ││Q│ │ │├─┤ │ ││Q│ │ │├─┤ │ ││Q│ │ ──────── │├─┤ │ ││Q├───────────────────────────────────┐ │├─┤ │ │ ││Q├───────────┐ ├─────┐ │├─┤ │ │ + │ │...

  • Page 40: Auxiliary Output Wiring

    F08 Installation & Programming Manual Document No: LT0082 FIP Installation 2.10 AUXILIARY OUTPUT WIRING The "OPEN COLLECTOR" Auxiliary Outputs (AUX1 to AUX8) must only be connected to external equipment via approved isolating devices such as relays or optoisolators mounted within the panel.

  • Page 41: Door Holder Wiring

    "mapped" to the Master Alarm Relay. Use NON-BATTERY backed supply "+VNB" to power door holders. "+VNB" rating is 1.5 A. ( Note total F08 load must be < 1.5A ). Relay rating is 2 A @ 30 VDC resistive, 1A inductive.

  • Page 42: Brigade Interface Relays

    Tyco Centaur ASE Line Isolating Unit; LIU001 Torrens Transponder Unit Transponder Interface Adaptor; TIA001 The F08 provides four (4) sets of voltage free, changeover relay contacts at connector J7, as shown in Figure 2.17. The four relays are detailed below. 2.12.1 “STANDBY”...
  • Page 43 Document No: LT0082 F08 Installation & Programming Manual FIP Installation 2.12.3 “ISOLATE” RELAY Normally de-energised. The Isolate Relay will energise on Isolation of any zone mapped to "MASTER ALARM" or the supervised Ancillary Output. (ie. COM switches from NC to NO).
  • Page 44 F08 Installation & Programming Manual Document No: LT0082 FIP Installation /\/\/\/\/\/\/\/\/\/\/│ │├─┤ │ ││Q│ +VB │ <─┐ │├─┤ │ │ ││Q│ +VB │ <─┴── Use these terminals, if +24 VDC │├─┤ │ Battery Backed voltage required ││Q│ +VNB │ │├─┤...
  • Page 45 Document No: LT0082 F08 Installation & Programming Manual FIP Installation Figure 2.17 Brigade Relay Termination Issue 3.04 24 March 2006 Page 2-33...

  • Page 46: Display & Zone Labelling

    2.13.2 DISPLAY BOARD REMOVAL OR INSTALLATION The F08 Display Board is attached to the rear of the internal door by five M4 x 12mm screws and flat washers. To remove the display board simply unplug the display FRC from J1 on the Main Board, then remove all 5 screws.

  • Page 47: Documentation

    F08 Installation & Programming Manual FIP Installation 2.14 DOCUMENTATION The following documentation MUST be included inside the F08 panel: F08 Operator's Manual A Maintenance Log-Book An "AS INSTALLED" fire detection system diagram and/or summary describing the installed layout of the F08 fire detection system.

  • Page 49: Placing Into Operation

    Document No: LT0082 F08 Installation & Programming Manual Placing into Operation PLACING INTO OPERATION Issue 3.04 24 March 2006 Page 3-1...

  • Page 50: General

    (see Figure 3.1). MAINS ISOLATE SWITCH To switch the F08 FIP ON or OFF, open the front protective door. The "MAINS ISOLATE SWITCH" is located at the bottom of the cabinet, to the right of the mains transformer. This switch controls the mains power supply to the panel, including the battery charger.
  • Page 51 Document No: LT0082 F08 Installation & Programming Manual Placing into Operation Figure 3.1 F08 Internal View Issue 3.04 24 March 2006 Page 3-3...

  • Page 52: Power Up

    F08 Installation & Programming Manual Document No: LT0082 Placing into Operation POWER UP To place a correctly installed and programmed F08 FIP into operation perform the following steps: STEP 1 Ensure that the Mains Isolate Switch is OFF and that 240VAC is available to the panel from the mains distribution switchboard.
  • Page 53 Document No: LT0082 F08 Installation & Programming Manual Placing into Operation POWER UP (CONTINUED) STEP 7 Perform a Battery Test. Select Battery/Charger ( By pressing SELECT until the Battery/Charger "SEL" indicator is illuminated). Press the key once. TEST The Battery/Charger "SEL" indicator will flash to indicate a battery test is in progress.

  • Page 54: F08 Installation & Programming Manual Document No: Lt0082

    Placing into Operation COMMISSIONING CHECKLIST The commissioning of an F08 FIP is the most important phase of any contract. If any problems are not corrected in this stage, experience shows that even the simplest of mistakes can cause major problems over a long period of time.
  • Page 55 Document No: LT0082 F08 Installation & Programming Manual Placing into Operation COMMISSIONING CHECKLIST (CONTINUED) Ensure System and Zone Tests perform satisfactorily. Verify the programming, wiring and operation of the system. Ie Check for each zone: Alarm and fault conditions can be generated.
  • Page 56 F08 Installation & Programming Manual Document No: LT0082 Placing into Operation THIS PAGE INTENTIONALLY LEFT BLANK Page 3-8 24 March 2006 Issue 3.04...

  • Page 57: Programming

    Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming PROGRAMMING Issue 3.04 24 March 2006 Page 4-1...

  • Page 58: Programming Features

    Programming should only be carried out by a suitably qualified FIRE-PROTECTION technician or engineer. If the F08 FIP was pre-programmed prior to delivery, it may NOT NEED TO BE RE- PROGRAMMED in the field. The F08 "PROGRAMMING MODE" provides four (4) programming functions with the programming keys and indications summarised in Tables 4.1 and 4.2.
  • Page 59 Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming PROGRAMMING FEATURES (CONTINUED) FUNCTION 4; ZONE & ANCILLARY RELAY SUPERVISION - ENABLED / DISABLED; AUXILIARY ZONE OUTPUT OPERATION MODE This programming function enables the programmer to select which zone inputs are enabled and also select whether or not the Ancillary Relay Output is Supervised.
  • Page 60 VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming FUNCTION PRESS KEY INDICATED BY Enter into Zone Output TEST Ancil Relay “SEL” LED Flashing Mapping Output “ISO” LEDs Flashing Select Output for Mapping TEST Selected Output “SEL” LED Flashing Select Zones SELECT Selected Zone “SEL”...

  • Page 61: Entering Programming Mode

    Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming ENTERING PROGRAMMING MODE Located at the top left hand side of the main board is a push-button labelled "PROGRAM". MAIN BOARD - Top Left-Hand Side ┌───────────────────────────────────── │ ┌─┐ ┌────────────┐ │ ├─┤...

  • Page 62: Exiting Programming Mode

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming EXITING PROGRAMMING MODE 4.3.1 WITHOUT SAVING CHANGES This sequence exits "PROGRAMMING MODE" without saving any changed parameters. I.E. the system returns to normal operation with the same parameters that existed prior to entering the programming mode.

  • Page 63: Reset To Default Parameters

    Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming RESET TO DEFAULT PARAMETERS This sequence returns all programmable system parameters to the following default settings, but leaves the user in "PROGRAMMING MODE" still. All zones enabled. All zones latching for both alarms and faults.

  • Page 64: Programme Zone To Output Mapping

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming PROGRAMME ZONE TO OUTPUT MAPPING 4.5.1 FUNCTION Selects which zone inputs will activate the following outputs: a) "ANCILLARY RELAY" b) "MASTER ALARM" c) "ALARM BELLS". When a zone input is mapped to an output, that output will be turned on if an alarm is detected on the zone and it is not isolated.
  • Page 65 Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming 4.5.3 MAPPING ZONES TO SELECTED OUTPUT Press the "SELECT" key once. Zone 1 "SEL" LED will turn ON. SELECT Selected Output "SEL" LED continues to flash. Press the "TEST" key to toggle the mapping state.
  • Page 66 VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming 4.5.4 EXAMPLE 1 Enter "PROGRAMMING MODE", then reset the parameters to default as shown below: ┌───┐ ┌───┐ ╓▄▄▄▄▄▄▄▄▄▄┐ │ O │ ────────────────────────> │ O │ ──> ║ RESET │ └───┘ └───┘...
  • Page 67 Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming EXAMPLE 1 (CONTINUED) ┌────────────────────────┐ │(b) Re-map MASTER ALARM │ └─┬──────────────────────┘ │ Select Select Select Select │ Master Alarm Zone 1 Zone 2 Zone 3 │ ╓──────────┐ ╓──────────┐ ╓──────────┐ ╓──────────┐ └──>║ TEST │──>║...

  • Page 68: Programming Zones As Latching Or Non-Latching

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming PROGRAMMING ZONES AS LATCHING OR NON-LATCHING 4.6.1 FUNCTION This function selects which zone inputs will be latching or non-latching for ALARM and latching or non-latching for FAULT. I.e. if the alarm state is programmed as latching, it means that the zone will remain in alarm after the alarm condition has been removed from the circuit input, and must be reset by an operator.
  • Page 69 Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming 4.6.3 EXAMPLE 2 Continuing from example 1, perform the following keypad steps to select: Zone 6 - alarm latch, fault non-latch Zone 2 - alarm non-latch, fault non-latch Zone 5 - alarm non-latch, fault latch...

  • Page 70: Programming Zone Input Type

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming PROGRAMMING ZONE INPUT TYPE 4.7.1 FUNCTION This function programs each zone with an input type. The type determines the time delay before a true ALARM is recognised. 4.7.2 OPERATING STEPS Press the "SILENCE" key once.
  • Page 71 Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming 4.7.3 EXAMPLE 3 Continuing from example 2, perform the following keypad steps to program the zones as follows: Zone 3 as AVF/RAD Zone 4 as AS1688 AVF/SAD Zone 5 as AS1668 SAD Zone 6 as 20 sec flow switch.

  • Page 72: Enabling Or Disabling Zones

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming ENABLING OR DISABLING ZONES 4.8.1 FUNCTION This function selects which zone inputs will be disabled or enabled. If a zone is disabled it will not require an End Of Line, nor will it be able to be selected. To be used a zone must be Enabled.
  • Page 73 Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming 4.8.3 EXAMPLE 4 Continuing from example 3, perform the following keypad steps to program zones 7 and 8 as disabled. ┌───────────────────────────┐ │ Continued from Example 3 │ │ Zone 4 currently selected │...

  • Page 74: Programming Ancillary Relay Supervision

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming PROGRAMMING ANCILLARY RELAY SUPERVISION 4.9.1 FUNCTION This function enables or disables the "ANCILLARY RELAY" output supervision function. When enabled, the "ANCILLARY" output must be wired for supervision otherwise a fault will be detected.
  • Page 75 The panel will also be signalling Fault to the brigade (unless isolated) as all enabled zones will be isolated. After programming, the F08 FIP should be thoroughly checked to ensure that all programming was as desired and that all functions are operational.

  • Page 76: Programming Zone Auxiliary Output Mode

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming 4.10 PROGRAMMING ZONE AUXILIARY OUTPUT MODE 4.10.1 FUNCTION This function selects whether the zone auxiliary outputs (open collector outputs) are isolatable or not. When a zone is in alarm and not isolated, the zone auxiliary output will always be on.
  • Page 77 The panel will also be signalling Fault to the brigade (unless isolated) as all enabled zones will be isolated. After programming, the F08 FIP should be thoroughly checked to ensure that all programming was as desired and that all functions are operational.

  • Page 78: Exit Programming Checklist

    VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming 4.11 EXIT PROGRAMMING CHECKLIST The following checks are required to ensure that the system is correctly programmed and configured. All zones toggled between DISABLED and ENABLED are ISOLATED upon exit from the programming mode.

  • Page 79: Trouble Shooting In Programming Mode

    Document: LT0082 VIGILANT F08 Installation & Programming Manual Programming 4.12 TROUBLE SHOOTING IN PROGRAMMING MODE TABLE 4.3 TROUBLE-SHOOTING IN PROGRAMMING MODE CONDITION REASON ACTION UNABLE TO ENTER A System Test is being PROGRAMMING MODE performed A Zone Test is being...
  • Page 80 VIGILANT F08 Installation & Programming Manual Document: LT0082 Programming THIS PAGE INTENTIONALLY LEFT BLANK Page 4-24 24 March 2006 Issue 3.04...

  • Page 81: Application Considerations

    Document No: LT0082 F08 Installation & Programming Manual Application Considerations APPLICATION CONSIDERATIONS Issue 3.04 24 March 2006 Page 5-1...

  • Page 82: Sub-Panel Wiring

    Application Considerations SUB-PANEL WIRING The F08 can be used as a sub-panel or it can be used as the master panel to a number of sub-panels. The following information details how the F08 can be used as a master panel to monitor other panels.
  • Page 83 Fault on Standby Sub-Panel Circuit Wiring 5.1.2 ALARM ON STANDBY Figure 5.2 shows how one AZC input of an F08 can be used to monitor a sub-panel with both alarm and standby from the sub-panel producing alarm at the master panel. STANDBY is normally energised.
  • Page 84 ALARM ON STANDBY - SEPARATE INDICATION TO ALARM Figure 5.3 shows how two AZC inputs of an F08 can be used to monitor a sub-panel. AZC1 is used for the sub-panel’s Alarm and Fault signals, AZC2 is used for the Standby and Isolate signals (if required).

  • Page 85: Fire Detection In Hazardous Areas

    Document No: LT0082 F08 Installation & Programming Manual Application Considerations FIRE DETECTION IN HAZARDOUS AREAS 5.2.1 REFERENCES AS2380 Electrical Equipment for Explosive Atmospheres - Explosion Protection Techniques. AS 2381 Electrical Equipment for Explosive Atmospheres - Selection, Installation and Maintenance. AS 2430 Classification of Hazardous Areas.
  • Page 86 Document No: LT0082 Application Considerations 5.2.4 ISOLATING REPEATERS Two isolating repeaters are specified for use with F08: Pepperl & Fuchs' KFDO-CS-Ex 1.51P and Pepperl & Fuchs' KFDO-CS-Ex 2.51P For these isolating repeaters the total capacitance and inductance of the detectors and cables on the IS circuit must be less than that specified in Table 5.2.1.
  • Page 87 Figure 5.2.1 shows the wiring of the approved isolating repeaters with F08. Note: Do not connect 15V MCPs onto detection circuits that are connected to the F08 through an isolating repeater. To use MCPs in an IS area, short circuiting MCPs (not 15V type) must be connected onto their own circuit through a separate isolating repeater channel to F08.
  • Page 88 I.e. circuit length is from the isolating repeater to the EOL when the length is limited due to cable capacitance/inductance, or from the F08's terminal through the isolating repeater to the EOL when the limit to due to resistance.
  • Page 89 5.2.6 PROGRAMMING & LIMITATIONS When using the F08 with IS Isolators the 13-17V region must be programmed as detector alarm, i.e. Type 1 (non-AVF) or Type 4 (AVF). With circuit type 4 the zone must be programmed as latching to cancel any out-of-alarm delay. This allows the higher alarm voltage of the detector and isolator to be used.

  • Page 90: Prevention Of Non "Fire" Alarms

    F08 Installation & Programming Manual Document No: LT0082 Application Considerations PREVENTION OF NON “FIRE” ALARMS All fire detection systems rely on their ability to identify atmospheric or environmental changes brought about by the presence of fire. They employ various types of sensors to monitor specific conditions.

  • Page 91: Trouble Shooting

    F08 Installation & Programming Manual Application Considerations TROUBLE SHOOTING In addition to the trouble-shooting guide contained in the F08 Operator Manual, Table 5.4.1 gives a quick reference to the typical problems, reasons and possible corrective action for faults experienced with the F08 FIP.
  • Page 92 F08 Installation & Programming Manual Document No: LT0082 Application Considerations TABLE 5.4.1 TROUBLE-SHOOTING (CONTINUED) ZONE IN CONTINUOUS WIRING FAULT Check wiring FAULT OR ALARM EOL FAULT Check if resistor fitted - Cannot clear by zone reset Fitted at last detector?

  • Page 93: Appendix A1 - Compatible Batteries

    Document No: LT0082 F08 Installation & Programming Manual Appendix A1 - Compatible Batteries APPENDIX A1 COMPATIBLE BATTERIES ┌─────────────────────────────────────────────────────────────────┐ │ SONNENSCHIEN RANGE │ ├─────────────┬───────┬─────┬──────────┬────────┬────────┬────────┤ │ Type │Voltage│ AHr │ Approved │ Width │ Length │ Height │ ╞═════════════╪═══════╪═════╪══════════╪════════╪════════╪════════╡ │ A212/5.7S │...
  • Page 94 F08 Installation & Programming Manual Document No: LT0082 Appendix A1 - Compatible Batteries THIS PAGE LEFT INTENTIONALLY BLANK Page A1-2 24 March 2006 Issue 3.04...

  • Page 95: Appendix A2 - Compatible Actuating Devices

    Document No: LT0082 F08 Installation & Programming Manual Appendix A2 - Compatible Actuating Devices APPENDIX A2 COMPATIBLE ACTUATING DEVICES OLSEN RANGE MAX NO. OF DETECTORS TYPE DESCRIPTION PER ZONE C23BEx * Ionisation Smoke Detector (IS Version) C24B Ionisation Smoke Detector...
  • Page 96 # Heat Detector Types A, B, C, D Z500N Base MS302Ex # IS InfraRed Flame Detector Short Circuit Device With Pepperl & Fuchs KFDO-CS-Ex 1.51P (or 2.51P) Isolating Repeater. # F08 Input type must be programmed as Type 1 or Type 4. MAX NUMBER OLSEN RANGE TYPE DESCRIPTION...
  • Page 97 Refer to Section 5.2. For IS applications with the listed isolating repeaters there are special programming requirements for the F08. Refer to Section 5.2. The maximum detector quiescent current allowed is 4 mA.
  • Page 98 F08 Installation & Programming Manual Document No: LT0082 Appendix A2 - Compatible Actuating Devices THIS PAGE LEFT INTENTIONALLY BLANK Page A2-4 24 March 2006 Issue 3.04...

  • Page 99: Appendix A3 - Installation Drawings

    F08 FIP Brigade Wiring Diagram for Randata Deltec A3/696-037 F08 FIP Brigade Wiring Diagram for Minimux Deltec A3/696-038 F08 FIP Brigade Wiring Diagram for MFB Alarm Interface Unit. A3/696-039 F08 FIP Brigade Wiring Diagram for Torrens Transponder A4/1899-10 Zone Naming Label.
  • Page 100 F08 Installation & Programming Manual Document No: LT0082 Appendix A3 - Installation Drawings THIS PAGE LEFT INTENTIONALLY BLANK Page A3-2 24 March 2006 Issue 3.04...
