Degauss Labs Noir Owner's Manual

NOIR
OWNERS MANUAL
About Noir balanced earphones
Thank you for purchasing a Degauss Labs product. The Noir balanced
earphones with an aluminium housing and balanced armature dual hybrid
speakers, delivers an exceptional clear sound with a resonant bass boost, yet
a warm and clear mid's and a perfect level of treble. The twisted pair cable is
made in a high quality and rubber coated material that improves the ultimate
sound experience.
Specifications Noir balanced Earphones
Housing: Aluminium
Speakers: 10 mm Balanced Armature
Frequency response: 20 - 20 000 Hz
Sensitivity: 96 dB SPL @ 1kHz
Isolation: -42 dB @ 2 kHz
Impedance: 16 Ohm
Remote: 3 button
Microphone: MEMS
Cord type: TPU Twisted Pair, Rubber coated
Cord length: 125 cm (49.2 in) 2x1.5 mm thick
Plug: L.-Shaped, Gold plated 3.5 mm (1/8 in)
Weight: 15.6 grams (0.55 oz)
Product box: - weight and dimensions
- H x W x D: 16 x 12 x 4 cm
- 110 grams (3.9 oz)
Eartips: 5 Sizes - S / M / L / XL / XXL
Accessories: Cable clip, Flight adapter
Warranty: 1 year manufacturer
Remote functions - 1 or 3 button
Degauss Labs, Noir balanced earphones comes with a microphone and 3-button
remote. You can pick up / hang up or reject phone calls and play / pause your
music, with clicks on the button remote
Apple phones with remote
Apple phones comes with built in functions for pick up / hang up or reject
phone calls and music commands from the remote.
Apple – Music Players
One click
Play / pause song
Two clicks
Play next song
Three clicks
Play previous song
Two clicks + hold
Fast forward
Three clicks + hold
Rewind
Apple - Phone calls
One click Answer / Hang up call
Two clicks Reject call
Handle Earphone & Eartips
The earphones are shipped with 5 different sizes of eartips and the size "L"
is mounted from factory. Eartips can be removed and changed by carefully
sliding them off the earphones. When replacing, check that the eartips rubber
notches are securely fastened to the notch on the audio tube.
Cleaning earphone and eartips
Before cleaning your earphone and eartips, remove the eartips from the
earphones. This to ensure that moist from the cloth will not damage the
earphones. Use an antiseptic cloth or wipe to clean the earphones and
eartips. Remove wax and dirt from the eartips, since it will affect the sound
quality of your earphones. Ensure that no moisture penetrates the sound
tube when cleaning as this may damage the speakers inside the earphones.
Cleaning the sound tube filter
If the filter on the front of the sound tube shows signs of wax, use a needle to
carefully clean it.
Android phones with remote
Android has limited functions on remote clicks. Degauss Labs app allows you
to configure your choice of actions on button clicks. To get more features to
your earphones and music players, download the Headset Control App from
Google Play with this QR code.
Android - Music Players - Headset Control App
One click
Two clicks
Three clicks
Four clicks
Five clicks
One click + hold
Two clicks + hold
Android – Phone Call
One click
Two clicks
Three clicks
* NOTE:
Android v2.2 - 4.0.4 due to limitations in Android v4.1
Jelly Bean, where Hold button press, starts Google Now.
Using your earphones
Be careful with your earphones at all times and protect them from external
damage. Do not expose the earphones to heat, magnetism or cold, damp
environments. Avoid dropping or strong impact, since it might damage the
delicate speakers.
Insert your earphones by holding the earphone at the rear. Carefully insert
the eartip into the ear.
The earphone should seal deeply and comfortably in the ear canal to get the
best bass sound.
If the bass frequency response seems to low, try inserting the earphone
deeper into the ear canal to obtain a better seal or try a different eartip size.
After use, remove the earphone from the ear by holding the speaker at the
rear - avoid pulling the cable.
Avoid winding the cable too tightly. Do not expose the cables and plugs to
abnormal wear and tear, e.g. by bending or pulling them.
Play / pause song
Play next song
Play previous song
Your command
Your command
Volume up *
Volume down *
Answer / Hang up call
Reject call
Your command
Click + Hold commands are available only on
