Wahlberg PROJECTOR SHUTTER User Manual

THE PROJECTOR SHUTTER.
DMX controlled.

Contents of the projector shutter.

1 motor box with transformer.
1 small disc without motor clamp.
1 big disc with motor clamp.
1 small screwdriver.
1 red washer
DMX output
DMX Input
DMX ok lamp.
User manual // DMX
1 Setting of DMX address. The DMX address is set on the 3 DMX wheels mounted inside the
motor box. The red lamp flashes when addresses outside 1 to 512 are chosen.
2 Connecting of DMX . The DMX signal is applied with a standard 5-pole XLR-plug.
The red lamp shows a constant light when a good signal is found and flashes if the DMX signal
is bad or missing.
3 Mounting of the disk. The disk is mounted on the motor axle. When the desired angle has
been found, the disc can be tightened with the small black screw. For this you may use the
small screwdriver included with the projector shutter.
4 Use of the projector shutter. When 220 volts and the DMX have been connected, the
projector shutter is ready for use. By changing the percentage of the chosen DMX address, the
motor axle can be made to turn forward and backward following the DMX percentage. The
motor axle can turn from 0 to 180 degrees, 0% equalling 0 degrees and 100% being 180
degrees.
WWW.WAHLBERG.DK · TELEPHONE +45 86 18 14 20 · CELL PHONE +45 40 52 20 88 · EMAIL: mads@wahlberg.dk
Aluminum cabinet
DMX address setting.
Jægergårdsgade 152/05A
DK-8000 Aarhus C
DENMARK
WWW.WAHLBERG.DK
Motor axe with screw
for mounting the disc.
Use the small
screwdriver here.
