LEGACY

• Read, understand and follow

these instructions for safe

installation and operation.

WARNING

If the information in these instructions

is not followed exactly, a fire or explo-

sion may result causing property dam-

age, personal injury or death.

WARNING

1. Do not store or use gasoline or other

flammable liquids or vapors in the vi-

cinity of this or any other appliance.

2. An LP cylinder not connected for

use shall not be stored in the vicin-

ity of this or any other appliance.

If you smell gas:

Shut off gas to the appliance.

Extinguish any open flame.

Open lid.

If odor continues keep away from the ap-

pliance and immediately call your gas

supplier or your fire department.

CONVECTION RANGE

CAUTION: DO NOT DISCARD THIS MANUAL

NOTICE TO INSTALLER AND CONSUMER

DANGER

Fire Stone Home Products • Legacy Gas Grill • Rev. D

OWNER'S MANUAL

•

Assembly

•

Operation

•

Maintenance

Models: JAG24c (shown)

JAG24

LG24c

LG24i

JAG36c

JAG36

LG36c

LG36i

• These instructions must be left with the

consumer and the consumer should

retain them for future reference.

Read the following instructions care-

fully and be sure your grill is properly in-

stalled, assembled and maintained.

Failure to follow these instructions may

result in serious bodily injury and/or

property damage. If you have questions

concerning assembly or operation, con-

sult your dealer, gas appliance service

person or your LP gas company.

This outdoor cooking gas appliance is

not intended to be installed in or on recre-

ational vehicles and/or boats.

Installation and service must be performed

by a qualified installer, service agency, or

the gas supplier. In the Commonwealth of

Massachusetts installation must be per-

formed by a licensed plumber or gas fitter.

GAS-FIRED

LISTED

760-920D

12/07

Table of Contents

Need help?

Do you have a question about the JAG24c and is the answer not in the manual?

Questions and answers

Summary of Contents for Firestone JAG24c

Page 1 LEGACY CONVECTION RANGE OWNER’S MANUAL • Assembly • Operation • Maintenance Models: JAG24c (shown) GAS-FIRED JAG24 LG24c LG24i JAG36c LISTED JAG36 LG36c LG36i CAUTION: DO NOT DISCARD THIS MANUAL NOTICE TO INSTALLER AND CONSUMER • Read, understand and follow • These instructions must be left with the...
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY .................. 3 SAFETY INSTRUCTIONS ............. 4 SERVICE PARTS LIST ..............6 ASSEMBLY INSTRUCTIONS ............10 LIGHTING INSTRUCTIONS ............16 COOKING INSTRUCTIONS ............18 CLEANING AND MAINTENANCE INSTRUCTIONS ....19 CONTACT INFORMATION ............21 Fire Stone Home Products • Legacy Gas Grill • Rev. D...
Page 3: Warranty
WARRANTY Legacy - JAG24c / JAG24 / LG24c / LG24i / JAG36c / JAG36 / LG36c / LG36i Gas Grills Limited Lifetime Warranty Fire Stone extends the following warranty for Legacy Series Gas Grills used in the United States of America or Canada.
Page 4 Read These Safety Instructions The LPG cylinder must be constructed and marked in ac- WARNING cordance with the Specifications for LP-Gas Cylinders of the U.S. Department of Transportation (DOT) or the National Fire Risk Standard of Canada, CAN/CSA-B339, Cylinders, Spheres and Tubes for Transportation of Dangerous Goods: and Explosion Risk Commission, as applicable.
Page 5: Safety Instructions
• If the hose appears damaged do not use gas grill. Call WARNING your dealer for a factory authorized replacement hose. Fire Risk • Keep the gas regulator hose away from hot grill surfac- Explosion Risk es and dripping grease. Avoid unnecessary twisting of hose.
Page 6 LG24i Service Parts Beginning Manufacturing Date: ____ (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: ______ Remove all components from the packing carton and place within easy reach. Do not throw the shipping carton away; in- stead use it as an elevated assembly surface. Fire Stone Home Products •...
Page 7 How to Order Replacement Parts LG24i Service Parts List IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. To order replacement parts, contact the deal- ITEM DESCRIPTION PART NUMBER...
Page 8: Service Parts List
LG36i Service Parts Beginning Manufacturing Date:_____ (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: ______ Remove all components from the packing carton and place within easy reach. Do not throw the shipping carton away; in- stead use it as an elevated assembly surface. Fire Stone Home Products •...
Page 9 How to Order Replacement Parts LG36i Service Parts List IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. To order replacement parts, contact the deal- ITEM DESCRIPTION PART NUMBER...
Page 10: Assembly Instructions
Assembly Instructions Carton A Before beginning to assemble the grill, remove all parts cartons from inside the lower cart cabinet, and the vapor- 2 - Front Swivel Caster with Brakes izer plate and the searing deck inside the grill hood. (See 2 - Rear Swivel Casters Figure 1).
Page 11 Step 2. Assemble Casters Carton D 1 - Stainless Steel Warming Grid Parts/Items Needed: Two front swivel castors with 2 - Warming Grid Legs brakes, two rear swivel castors, and the 3/4 inch open 1 - Searing Plate end wrench (from parts Carton A). See Figure 7. Searing Plate Wrench Stainless Steel...
Page 12 Step 5. Install Grease Drawer A 3/8 inch gas flexible tube is factory installed from the bulkhead fitting under the vaporizer plate to the TOP fitting on the manifold. Gas flows from the cylinder/reg- Parts/Items Needed: Grease Drawer (from parts Car- ulator through this flex tube to the manifold.
Page 13 Step 7. Install Searing Deck and Vaporizer Plate 1. Parts/Items Needed: Searing deck, vaporizer plate, and box cutter or small sharp knife. Note: These parts were inside the grill compartment PRESSURE REGULATOR and removed to complete previous assembly steps. Open the grill hood and use a box cutter or small sharp knife to cut the nylon tie-straps securing the burner to its bracket and securing the flexible gas tubes to one another.
Page 14 Step 8. Install Searing Plate and 4. Place the assembled warming grid to the rear of the grill compartment above the searing plate. The legs will rest Warming Grid on ledges along each side of the grill compartment. See Figure 15. 1.
Page 15 Step 11. Install Side Tables Step 10. Assemble Side Tables 1. Parts/Items Needed: Two side table assemblies (from 1. Parts Needed: Two side tables (left and right), two con- Step 10), eight Philips head mounting screws, (from diment trays, two handles, eight Philips head mounting screws, six grilling tool hooks, (from parts Carton E), parts Carton E), and Philips head screwdriver (not sup- plied).
Page 16: Lighting Instructions
Lighting Instructions Basic Lighting Procedures WARNING 1. Familiarize yourself with the safety guidelines at the front of this manual. Do not smoke while lighting grill or Fire Risk checking gas supply connections. Explosion Risk 2. Be sure the LPG cylinder is filled. A strong gas smell, or the hissing sound of gas indi- cates a serious problem with the gas grill or the LPG 3.
Page 17 If the grill fails to light properly: • Problem: Disconnected Ignition Wires Correction: Inspect the Ignitor junction box found be- 1. Turn gas off at the cylinder and turn both control knobs neath the Control Panel. Connect loose Ignitor wires to to OFF.
Page 18: Cooking Instructions
Cooking Instructions Electronic Operation Important: Before cooking on the grill for the first time, wash the cooking grids and sear plates with warm, soapy Step 1. Select the type of food being cooked. water. Rinse and dry thoroughly. Step 2. Use the temperature control knob to select tem- Burn-off perature.
Page 19: Cleaning And Maintenance Instructions
Cleaning and Maintenance Instructions As with all appliances, proper care and maintenance will keep correctly placed inside the end of the burner tube. Also this grill in top operating condition and prolong its life. By fol- check the position of the spark electrode. See Figure 23. lowing these cleaning procedures on a timely basis, the grill will stay clean and work properly with minimum effort.
Page 20 CAUTION: Be sure the grill is OFF and cool before cleaning. WARNING Annual Cleaning of The Grill Interior Fire Risk Burning-off the grill after every cookout will keep it ready Explosion Risk for instant use. However, once a year you should give the entire grill a thorough cleaning to keep it in top operating Do not line the bottom of the grill housing with alumi- condition.
Page 21: Contact Information
Contact Information Fire Stone Home Products Please contact your Fire Stone Home Products dealer 12400 Portland Ave. So. with any questions or concerns. Burnsville, Mn 55337 For the number of your nearest Fire Stone Home www.firestonehp.com Products dealer, please call 952-358-7410. Model No.:_________________________________ Serial No.:_________________________________ - NOTES -...
