INSTALLATION AND OPERATING INSTRUCTIONS
The following is intended to provide the basic instructions for installation and operation of the Wireless Remote Control
(WRC), and to assist in attaining the best possible performance from the unit. Read and understand these operating
instructions before use.
TOOLS REQUIRED
• Medium Phillips screwdriver
PRODUCT WARNINGS
!
WARNING: For fire fighting use only by trained fire fighters.
!
WARNING:
Although the enclosures for the controller and receiver are water-resistant, it is important to keep water
out of the enclosure. Prolonged exposure to water will cause damage. When the cover of the enclosure
is removed, make sure the O-ring under the cover is intact and free of dirt and debris.
!
WARNING:
Do not use the WRC when the override cranks are being used or are in position for use.
!
WARNING: Replace the identification tags if they should become worn or damaged.
!
WARNING: Do not stow the monitor when flowing water
PRODUCT SPECIFICATIONS
Handheld Controller
• Input power
• Battery life
• Output power
• Controller dimensions
• Controller weight
• Operating temperature range
• Controller power
• Operating Frequency
• FCC ID
• Range
NOTE: Enclosing the receiver in a compartment or behind the pump panel will reduce the effective range.
Receiver
• Input power
• Receiver dimensions
• Receiver weight
• Operating temperature range
• Receiver power
• Operating Frequency
• FCC ID
• Security Code
*Early models used one CR123 or equivalent Lithium Battery
STYLE 3600 WIRELESS REMOTE CONTROL
• Small flat screwdriver
Two – 1.5v Lithium AA batteries*
20 continuous hours
Meets FCC part 15 requirement for license free operation
6 1⁄4" x 3 1⁄2" x 13⁄4"
3⁄4 lb
-40°F to 140°F (-40°C to 60°C)
1mW
2.4GHz or 900MHz (see label for frequency)
OUR-XBEE
500 ft
12 or 24 VDC
4 1⁄2" x 3 1⁄2" x 2"
1⁄2 lb
-40°F to 140°F (-40°C to 60°C)
100mW
2.4GHz 900MHz (see label for frequency)
OUR-XBEE
64 bit code from serial number of module
120315
