Summary of Contents for Animated Lighting HHIAB
-
Page 1: Operating Instructions
Assembly and Operating Instructions Animated Lighting, Inc. 13848 Wyandotte Kansas City, MO 64145 (816) 941-0400 www.animatedlighting.com... - Page 2 Overview Congratulations! You have purchased the Haunted House in a Box (HHIAB). It is a plug-and-play light controller from Animated Lighting that enables you to quickly build an exciting Halloween light show with your lights on bushes and trees, black lights, strobes, spot lights or just about anything spooky that lights up or you can shine a light on.
- Page 3 Extra Prop B. Looks best placed behind channels 10 and 11. They work hand and hand with the channels in auxiliary Band 2. Extra Prop C. Looks best placed behind channels 10 and 11. They work hand and hand with the channels in auxiliary Band 2. Strobe Light. Strobe Light. Animated Lighting, Inc PAGE 2...
- Page 4 There are between one to four 120 volt cords coming out of each lighting controller you have purchased. Plug each cord into different wall plugs to distribute the power. In some cases you will have to find wall plugs fed by different circuit breakers from your master power panel. Animated Lighting, Inc PAGE 3...
- Page 5 Do not plug the transformer into the wall outlet yet. Your light controller enclosure can be located outside but make sure the access holes are pointing down so rain water cannot enter the unit. Animated Lighting, Inc PAGE 4...
- Page 6 Locate the two dials on the same board as the RJ45 (8-pin) jacks that say A1 2) ADDRESSING: and A0 on them. These dials will be changed based on the size of your display (the number of light controllers that are used). Animated Lighting, Inc PAGE 5...
- Page 7 (One power cord per two-hole, over-under outlet.) ALWAYS REMOVE POWER FROM CONTROLLERS BEFORE OPENING THE LID COVER TO THE CONTROLLER. DO NOT ATTEMPT TO PLUG IN OR REMOVE CORDS FROM CHANNEL OUTLETS UNTIL POWER TO THE CONTROLLER HAS BEEN REMOVED. Animated Lighting, Inc PAGE 6...
-
Page 8: Warranty And Disclaimer
Support Issues or for More Details CALL: 816.941.0400 (9 a.m. to 5 p.m. CST, M-F excluding holidays) EMAIL: support@animatedlighting.com Warranty and Disclaimer Please consult www.animatedlighting.com for product warranty and disclaimer information. Animated Lighting, Inc PAGE 7...
