Teleflex Marine KE-4 Installation/Operation Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

KE-4
FT033
Installation/Operation
Instruction Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KE-4 and is the answer not in the manual?

Questions and answers

Summary of Contents for Teleflex Marine KE-4

  • Page 1 KE-4 FT033 Installation/Operation Instruction Manual...
  • Page 3 Electronic Control System Trolling Module Handheld Control Engine Synchronization...

  • Page 5: Table Of Contents

    Electronic Control System TABLE OF CONTENTS Introduction .....................1 Basic Performance ..................2 Name Of Each Part ..................3 Components ....................4 Name And Function Of Control Unit Components .......... 5 Name And Function Of Control Head Components ........6 Name And Function Of Actuator Components ..........7 How To Operate ....................8 Initial operation after power ON ................
  • Page 6 Adjusting The Control Unit ................23 Setting the throttle actuator operation direction ..........Setting the forward throttle actuator stroke ............Setting the throttle actuator stroke opening ............Setting the reverse throttle actuator stroke ............Setting the shift actuator operation direction ............Setting the shift actuator stroke ................

  • Page 7: Introduction

    INTRODUCTION This manual has been prepared to ensure your correct operation of the KE-4 system. Be sure to read this manual thoroughly to understand the contents to prevent injury or damage to the property through abuse. Always keep the manual within your reach during operation.

  • Page 8: Basic Performance

    BASIC PERFORMANCE 1. Electric Performance a. Supply voltage For DC12V model:DC9V~16V For DC24V model:DC16V~3OV b. Max. current of actuator:16A or less(at 49N{5kgf}load) c. Current consumption at stop of actuator: 0.5A or less 2. Performance of Actuator a. Thrust Maximum operating thrust:147N{15kgf} Constraint load :343N{35kgf} b.

  • Page 9: Name Of Each Part

    NAME OF EACH PART The figure below shows an example of two engines/two control station system. : Indicates identification : Indicates the destination of connection Electronic Control System...

  • Page 10: Components

    COMPONENTS Required Single Engine Two Engines Note: No. of Station No. of Station No. Name Part No. Control Head NM0511-00 — — — — ➀ NM0510-00 — — — — Control Unit ➁ 24 V Model NM0478-00 12V Model NM0477-00 Actuator NM0165-00 ➂...

  • Page 11: Name And Function Of Control Unit Components

    NAME AND FUNCTION OF CONTROL UNIT COMPONENTS Note: The Control Unit is available in two types, one for 24V and the other for 12V. Select the appropriate one for your power supply. Electronic Control System...

  • Page 12: Name And Function Of Control Head Components

    NAME AND FUNCTION OF CONTROL HEAD COMPONENTS Electronic Control System...

  • Page 13: Name And Function Of Actuator Components

    NAME AND FUNCTION OF ACTUATOR COMPONENTS WARNING Never operate the Selector Knob except in case of emergency. Note: Actuator harness cannot be extended or changed. Electronic Control System...

  • Page 14: How To Operate

    HOW TO OPERATE Initial operation after power ON With power ON, the throttle actuator is fully closed and the shift actuator is set to neutral. When the control head connected to R/C-l is to be used first Set the hand lever to the neutral position. The neutral lamp goes ON and the control head becomes operative.

  • Page 15: Neutral Throttle Operation

    Neutral throttle operation How to set Set the hand lever to the neutral position. Open the switch cover and shift the hand lever to the forward position while pressing the selector switch. The neutral lamp flashes and the neutral throttle operation can be made. How to cancel Set the hand lever to the neutral position.

  • Page 16: Determination Of Cable Length

    DETERMINATION OF CABLE LENGTH CAUTION Do not bend the cable less than the specified radius. Otherwise, the cable or actuator may suffer early damage. Measure the distance from the shift and throttle actuator to the engine’s shift and throttle connection position, measuring as straight as possible while avoiding any obstruction which may cause bending of less than the specified radius.

  • Page 17: Installing The Control Head

    INSTALLING THE CONTROL HEAD CAUTION Install the control head in an accessible place where the engine can be stopped anytime. Select a flat place convenient for operation and installation. a. Drill mount holes by using an attached template. b. Install with attached washer and nut. Tightening torque: 2.9~4.4N•n {30~45kgf •...

  • Page 18: Installing The Control Unit

    INSTALLING THE CONTROL UNIT CAUTION Ingress of water into the unit may cause failure 1. Install so that the harness comes from the bottom side. 2. Install in a place free from effect of the sea breeze and seawater. Avoid a place where the ambient temperature rises above 75°...

  • Page 19: Installing The Actuator

    INSTALLING THE ACTUATOR CAUTION Ingress of water into the unit may cause failure. Install in a place free from effect of the sea breeze and seawater. Avoid a place where the ambient temperature rises above 75°. Install the actuator in a place convenient for operation of manual selector knob. The actuator harness is 2m in length.

  • Page 20: Connecting The Control Head And Control Unit

    CONNECTING THE CONTROL HEAD AND CONTROL UNIT CAUTION Connect the coupler firmly. These units may fail to operate when the coupler is not connected firmly. Connection of the first control head • Connect the harness remote control to the red-taped harness of the control head and connect it to the R/C-l of the port control unit.

  • Page 21: Connecting The Actuator And Control Unit

    CONNECTING THE ACTUATOR AND CONTROL UNIT Connect a 12 - pole coupler of the actuator to that of the control unit. Electronic Control System...

  • Page 22: Connecting The Neutral Switch Harness

    CONNECTING THE NEUTRAL SWITCH HARNESS Connect the neutral switch harness between the starter circuit. Note: Use a thick (2mm or more) and short extension for the neutral switch harness. Long extension may cause voltage drop, resulting in failure of engine start. Electronic Control System...

  • Page 23: Connecting The Harness Power Supply

    CONNECTING THE POWER SUPPLY HARNESS CAUTION To ensure safety, the duplex power line system is provided. Be sure to connect both lines. The display panel shows an alarm message when only one power line is connected. Do not disconnect the power harness from the control unit after connected the power harness with battery (power supply).

  • Page 24: Connecting The Communication Harness

    CONNECTING THE COMMUNICATION HARNESS CAUTION Turn off circuit breaker or battery switch before connecting or disconnecting the communication harness to the control unit. Connect the two control units by the communication harness, which has 10-pole couplers at both ends, in dual engine system. Electronic Control System...

  • Page 25: Connecting The Dim Harness

    CONNECTING THE DIM HARNESS Connect the Dim Harness yellow line to the (+) wire of navigation light. Connect the Dim Harness green line to the (-) wire of navigation light. Note: The Dim Harness connection is not mandatory. Electronic Control System...

  • Page 26: Overall Wiring Diagram

    OVERALL WIRING DIAGRAM The diagram below shows a case with two engines operated from two control heads. Electronic Control System...

  • Page 27: Cable Installation

    CABLE INSTALLATION Cable installation to the actuator Cable installation method is similar for both shift and throttle. Install an attached rod end to the rod and fix with lock nut. Tightening torque:2. 9~4. 4N • m {30~45kgf • cm} Remove eight actuator screws shown with arrow and remove the cover. Install waterproof grommet to the cable.

  • Page 28: Cable Installation To The Engine

    Cable installation to the engine CAUTION Install the cable first to the actuator, then to the engine. Note: Carry out cable installation when connection of all harnesses is completed. Carry out positioning of the actuator as follows: Positioning the actuator •...
  • Page 29 ADJUSTING THE TROLLING UNIT CAUTION Turn OFF the power and remove the cable from the trolling valve. Then, carry our positioning of the actuator. (See page 22) After adjustment, install the cover. Tightening torque: 1.0~.7N•m When the actuator operation is not matched with the trolling valve, adjust by the switch in the trolling unit as follows.

  • Page 30: Setting The Forward Throttle Actuator Stroke

    Setting the throttle actuator operation mode Set whether the trolling valve is shifted to the disengage by pushing out the cable or by pulling in the cable. (Confirm on the rolling valve side). Set with SW2-1. SW2 — 1 FUNCTION Pull to open Throttle Push to open Throttle * Before shipment, the switch is set to OFF (Pull to open throttle).

  • Page 31: Setting The Reverse Throttle Actuator Stroke

    Setting the reverse throttle opening Set with SW2-3. SW2—3 FUNCTION Reverse throttle opening 1 Reverse throttle opening 2 * Before shipment, the switch is set to OFF (Opening 1). Setting the reverse throttle actuator stroke Set the throttle actuator stroke when the hand lever is operated from the reverse detent to the reverse full open position.

  • Page 32: Setting The Throttle Delay

    Setting the throttle delay This is to delay the opeartion start of the throttle actuator when the hand lever is shifted suddenly from neutral to throttle operation range. Delay time: 1 second Set with SW4-4. SW 4 - 4 FUNCTION No throttle delay Throttle delay * Before shipment, the switch is set to OFF (no throttle delay).

  • Page 33: Operation Check

    OPERATION CHECK Carry our operation check as follows when the installation work is over. Idle Forward 25° Forward full Reverse full throttle throttle CAUTION Never operate the hand lever with the engine stopped. Otherwise, the actuator, cable and engine may be damaged. Shift and throttle operation check Step Hand Lever Operation...

  • Page 34: Manual Operation Method

    MANUAL OPERATION METHOD (OPTIONAL MECHANICAL BACK-UP) WARNING Never attempt manual operation unless in case of emergency. The actuator can be operated manually when there is an optional mechanical control head and 33C cable. Install the mechanical control head and 33C cable according to the instruction manual of the mechanical control head.

  • Page 35: Alarm Indication

    ALARM INDICATION In the case of a system fault, the failure point is indicated with forward/neutral/reverse lamp flashing frequency and optional buzzer. All of forward, neutral and reverse lamps flash simultaneously. Flashing Frequency Cause Countermeasure Reference Once 1. Shift actuator and control unit are 1.
  • Page 36 Flashing Frequency Cause Countermeasure Reference Four 1. Cable installed without positioning 1. Install cable after positioning of page 22 Times of the shift actuator. the actuator. 2. Shift actuator stroke exceeding 2. Reduce the stroke of shift page 23 the stroke of clutch. actuator.
  • Page 37 Flashing Frequency Cause Countermeasure Reference 1. One of duplex power lines is 1. Connect both lines. page 17 Times disconnected. 2. Either circuit breaker is OFF. 2. Turn ON both breakers. page17 3. Harness power supply coupler 3. Reconnect the coupler of page 17 not connected correctly.

  • Page 38: Check Points In Case Of Trouble

    CHECK POINTS IN CASE OF TROUBLE Always consult this table first if any trouble is observed during operation. Symptom Cause Countermeasure Not operating even 1. Harness power not connected 1. Connect the harness power when power supply correctly. correctly. (See page 17) is ON.

  • Page 39: Maintenance And Service

    MAINTENANCE AND SERVICE Repair or replace any damaged part. Control Head After use, wash with fresh water to prevent corrosion. Never use grease because this contains electronic components. Control Unit After use, wash with fresh water to prevent corrosion. Never use grease because this contains electronic components. Actuator After use, wash with fresh water to prevent corrosion.
  • Page 40 Electronic Control System...

  • Page 41: Control Head Template

    CONTROL HEAD TEMPLATE Actual Size Electronic Control System...
  • Page 42 Electronic Control System...

  • Page 43: Control Unit Template

    CONTROL UNIT TEMPLATE Actual Size Electronic Control System...
  • Page 45 Trolling Module TABLE OF CONTENTS Introduction .....................1 Applicable Control Unit ..................1 Basic Performance ..................2 Name Of Each Part ..................3 Components ....................4 Name And Function Of Trolling Unit Components .......... 5 Name And Function Of Trolling Switch Components ........6 Name And Function Of Trolling Actuator Components ........6 How To Operate ....................7 Determination Of Cable Length ...............8 Installing The Trolling Switch ................8...
  • Page 46 Operation Check ..................22 Manual Operation Method ................23 Alarm Indication ....................24 Check Points In Case Of Trouble ..............26 Maintenance And Service ................27 Trolling Switch Template ................29 Trolling Unit Template ..................31...

  • Page 47: Introduction

    Always keep the manual within your reach during operation. This module is to be a part of the KE-4 engine control system. It is recommended therefore to read the manual of KE-4 Electronic Control System.

  • Page 48: Basic Performance

    BASIC PERFORMANCE 1. Electric Performance (1) Supply voltage For DC12V model:DC9VN16V For DC24V model:DC16VN3OV (2) Max. current of actuator:16A or less(at 49N{5kgf}load) (3) Current consumption at stop of actuator: 0.5A or less 2. Performance of Actuator (1) Thrust Maximum operating thrust:147N{15kgf} Constraint load :343N{35kgf} (2) Stroke Max.

  • Page 49: Name Of Each Part

    NAME OF EACH PART The figure below shows an example of two engines/two control station system. : Indicates identification : Indicates the destination of connection Trolling Module...

  • Page 50: Components

    COMPONENTS Required Single Engine Two Engines Note: No. of Station No. of Station No. Name Part No. Trolling Switch NM0228-00 ➀ Trolling Unit ➁ 24V Model NM0480-00 12V Model NM0479-00 Trolling Actuator NM0170-00 ➂ Harness NM0170-01 — — — — ➃...

  • Page 51: Name And Function Of Trolling Unit Components

    NAME AND FUNCTION OF TROLLING UNIT COMPONENTS Note: The Trolling Unit is available in two types: one for 24V and the other for 12V. Select the appropriate one for your power supply. Trolling Module...

  • Page 52: Name And Function Of Trolling Switch Components

    NAME AND FUNCTION OF TROLLING SWITCH COMPONENTS NAME AND FUNCTION OF TROLLING ACTUATOR COMPONENTS WARNING Never operate the Selector Knob except in case of emergency. Trolling Module...

  • Page 53: How To Operate

    HOW TO OPERATE Set both the hand lever(s) of the Control Head in use to the neutral position and press and release the Trolling Switch beside the Control Head. The Lo-Idle lamp goes ON and the trolling valve goes to the disengage position.

  • Page 54: Determination Of Cable Length

    DETERMINATION OF CABLE LENGTH CAUTION Do not bend the cable more than the specified radius. Otherwise, the cable or actuator may suffer premature damage. Measure the distance from the trolling actuator to the valve connection position, as straight as pos- sible, avoiding any obstruction which may cause bending of greater than the specified radius.

  • Page 55: Installing The Trolling Unit

    INSTALLING THE TROLLING UNIT CAUTION Ingress of water into the unit may cause failure. 1. Install so that the harness comes from the bottom side. 2. Install in a place free from effect of the sea breeze and seawater. Avoid a place where the ambient temperature rises above 75°.

  • Page 56: Installing The Trolling Actuator

    INSTALLING THE TROLLING ACTUATOR CAUTION Ingress of water into the unit may cause failure. Install in a place free from effect of the sea breeze and seawater. Avoid a place where the ambient temperature rises above 75°C. Install the actuator in a place convenient for operation of manual selector knob.
  • Page 57 CONNECTING THE TROLLING SWITCH & TROLLING UNIT CAUTION Connect the coupler firmly. These units may fail to operate when the coupler is not connected firmly. Connection of the first trolling switch. Connect the trolling harness of the trolling switch and connect it to the R/C-l of the Trolling Unit.
  • Page 58 CONNECTING THE TROLLING ACTUATOR & TROLLING UNIT 1. Connect a 12-pole coupler of the Trolling Actuator Harness to the Trolling Unit 2. Connect a 6-pole coupler of the Trolling Actuator Harness to the Trolling Actuator. Trolling Module...

  • Page 59: Connecting The Com./Power Harness (Single Engine System)

    CONNECTING THE COM./POWER HARNESS CAUTION Turn off circuit breaker or battery switch before connecting or disconnecting the Com./Power Harness with the Trolling Unit. To ensure the safety, the duplex power line system is provided. Be sure to connect both lines. The display panel shows an alarm message when only one power line is connected.

  • Page 60: Connecting The Com./Power Harness (Dual Engine System)

    CONNECTING THE COM./POWER HARNESS CAUTION Turn off circuit breaker or battery switch before connecting or disconnecting the Com./Power Harness with the Trolling Unit. To ensure the safety, the duplex power line system is provided. Be sure to connect both lines. The display panel shows an alarm message when only one power line is connected.

  • Page 61: Connecting The Dim Harness

    CONNECTING THE DIM HARNESS Connect the Dim Harness yellow line to the (+) wire of the navigation light. Connect the Dim Harness green line to the (-) wire of the navigation light. Note: The Dim Harness connection is not mandatory. Trolling Module...

  • Page 62: Overall Wiring Diagram

    OVERALL WIRING DIAGRAM The diagram below shows a case with two engines operating from two Trolling Switches. Trolling Module...

  • Page 63: Cable Installation

    CABLE INSTALLATION 1. Cable installation to the actuator a. Install an attached rod end to the rod and fix with lock nut. Tighten torque: 2.9~4.4N.m b. Remove from actuator screws shown with arrow and remove the cover. c. Install waterproof grommet to the cable. Install the rod end, rod clamp, hub and waterproof grommet to the actuator mount groove as shown below.

  • Page 64: Cable Installation To The Trolling Valve

    2. Cable installation to the trolling valve. CAUTION Install the cable first to the actuator, then to the trolling valve. Note: Carry out cable installation when connection of all harnesses is completed. a. Turn power ON, the trolling actuator automatically becomes engaged. b.

  • Page 65: Adjusting The Trolling Unit

    ADJUSTING THE TROLLING UNIT CAUTION Turn OFF the power and remove the cable from the trolling valve. (See page 18) After adjustment, install the cover. Tightening torque: 1.0~.7N.m When the actuator operation is not matched with the trolling valve, adjust by the switch in the trolling unit as follows.

  • Page 66: Setting The Port Actuator Operation Mode

    Setting the port actuator operation mode Set whether the trolling valve is shifted to the disengage by pushing out the cable or by pulling in the cable. (Confirm on the trolling valve side). Set with SW2-1. SW2 — 1 FUNCTION Pull to disengage a trolling valve Push to disengage a trolling valve * Before shipment, the switch is set to OFF (Pull to disengage a trolling valve).

  • Page 67: Setting The Starboard Actuator Stroke

    Setting the starboard actuator stroke The starboard actuator stroke can be set from 31mm to 73mm in a 3mm interval and 80mm. Set with SW3-1 • 2 • 3 • 4. SW3-1 SW3-2 SW3-3 SW3-4 STROKE 31mm 34 mm 37mm 40mm 43mm 46mm...

  • Page 68: Operation Check

    OPERATION CHECK Carry out operation check as follows when the installation work is over. Disengage Forward 25° Engage Engage Trolling operation Step Operation (Lever or Switch) Description Press the trolling switch Trolling valve goes to the disengage Lo-Idle lamp ON Neutral ⇒...

  • Page 69: Manual Operation Method

    MANUAL OPERATION METHOD WARNING Never attempt manual operation except in the case of an emergency. 1. The actuator can be operated manually. METHOD a. Tilt the selector knob in the arrow direction to the end. b. The actuator can be manually operated by using the emergency handle. NOTE: Reset the knob to the original position after end of manual operation.

  • Page 70: Alarm Indication

    ALARM INDICATION In the case of a system fault, the failure point is indicated by Hi -Idle and Lo - Idle lamps flashing. The Hi -Idle and Lo - Idle lamps flash simultaneously. Flashing Frequency Cause Countermeasure Reference Once 1. Starboard Trolling Actuator and 1.
  • Page 71 Flashing Frequency Cause Countermeasure Reference Four 1. Cable installed without positioning 1. Install cable after positioning page 18 Times of the starboard Trolling Actuator. of the actuator. 2. Starboard Trolling Actuator stroke 2. Reduce the stroke of starboard page 19 exceeding the stroke of trolling valve.

  • Page 72: Check Points In Case Of Trouble

    Flashing Frequency Cause Countermeasure Reference 1. One of duplex power lines is 1. Connect both lines. page13 Times disconnected. 2. Either circuit breaker is OFF. 2. Turn ON both breakers. page 13 3. Harness power supply coupler 3. Reconnect the coupler of page 13 not connected correctly.

  • Page 73: Maintenance And Service

    MAINTENANCE AND SERVICE Repair or replace any damaged part. Trolling Switch After use, wash with fresh water to prevent corrosion. Never use grease because this contains electronic components. Trolling Unit After use, wash with fresh water to prevent corrosion. Never use grease because this contains electronic components. Actuator After use, wash with fresh water to prevent corrosion.
  • Page 74 Trolling Module...

  • Page 75: Trolling Switch Template

    TROLLING SWITCH TEMPLATE Actual Size Trolling Module...
  • Page 76 Trolling Module...

  • Page 77: Trolling Unit Template

    TROLLING UNIT TEMPLATE Actual Size Trolling Module...
  • Page 79 Handheld Control TABLE OF CONTENTS Introduction .....................1 Name Of Each Part ..................2 Components ....................3 Name And Function Of Handheld Control Components ........4 How to Operate 1. Initial Operation After Power On ................2. When The Handheld Control Connected To R/C-1 Is To Be Used First ....3.

  • Page 81: Introduction

    Always keep the manual within your reach during operation. This product works as an additional control station for KE-4/KE-4a electronic control system. It is recommended therefore to read the manual of KE-4/KE-4a electronic control system together. The specifications may be subject to change without notice in view of improvement, resulting in more or...

  • Page 82: Name Of Each Part

    NAME OF EACH PART The figure below shows an example of two engines/two control station system. : Indicates identification : Indicates the destination of connection Handheld Control...

  • Page 83: Components

    COMPONENTS REQUIRED Single Name Part No. Engine Engine Note ➀ Handheld Control Kit NM0906-00 — NM0907-00 — ➁ Remote Control NM0616-04 Harness NM0616-06 NM0616-08 NM0616-10 NM0616-12 NM0616-14 NM0616-16 Sold NM0616-18 Separately NM0616-20 NM0616-24 NM0616-30 NM0616-38 NM0616-40 NM0616-50 ➂ Relay Kit NM0542-42 NM0542-43 Option...

  • Page 84: Name And Function Of Handheld Control Components

    NAME AND FUNCTION OF HANDHELD CONTROL COMPONENTS • The lamp ON during the hand- held control in use. • The lamp flashes slow during neutral throttle operation. • The lamp flashes fast during warnings. • To select the stations. • To set or cancel the neutral throttle operation.

  • Page 85: How To Operate

    HOW TO OPERATE Initial Control Operation After Power Is Applied “ON”. 1. With power “ON”, and the hand lever in the “Neutral” position, the system will be in the neutral idle condition. 2. The handheld control connected to remote control connector one (R/C-l) is considered the master control station and will become operational first.

  • Page 86: Neutral Throttle Operation

    Neutral Throttle Operation 1. Set the hand lever to the “ NEUTRAL” position. 2. Move the hand lever to the forward gear position while pressing the select switch. 3. The select lamp flashes (slow flash) and the neutral throttle operation is activated. Neutral throttle operation will remain active until properly deactivated.

  • Page 87: Installing The Socket Harness

    INSTALLING THE SOCKET HARNESS CAUTION Ingress of water into the unit may cause failure 1. Install in a place free from effect of the sea breeze and seawater. 2. Cover the socket when the Handheld Control is removed. Drill mount holes by using an attached template. Install with attached tapping screws.

  • Page 88: Installing The Holder

    INSTALLING THE HOLDER Drill mount holes by using an attached template. Install with attached tapping screws. Installation plate thickness: 10mm Min. Pilot hole dia: ∅4mm Min. Cut Out Dimensions Handheld Control...

  • Page 89: Connecting The Handheld Control And Control Unit

    CONNECTING THE HANDHELD CONTROL AND CONTROL UNIT CAUTION Connect the coupler firmly. These units may fail to operate when the coupler is not connected firmly. Connect the remote control harness to the red-taped harness of the socket harness and con- nect it to one of the R/C-1, 2, 3 or 4 of the port unit.

  • Page 90: Connecting The Relay

    WIRING THE EMERGENCY STOP SWITCH USING THE RELAY (CONNECTING THE RELAY) NOTE: 1. Consult with the engine manufacturer for which type of engine stop switch is equipped for your engine, “Normal Open Type” or “Normal Close Type”. 1.25mm (AWG16) lead wire is recommended for wiring. Connect the white lead wire of the Socket Harness with the port A of the relay connector using the attached bullet terminals and flat terminals.
  • Page 91 b. In the case that the engine is equipped with “Normal Close Type” engine stop switch. Connect the port N.C and COM of the relay connector with the engine stop circuit so as to be parallel with the engine stop switch. Connect the relay connector to the relay.

  • Page 92: Operation Check

    Shift arm shifted from reverse to neutral When the correct operation cannot be made, change the operation mode. (See “Adjusting the control Unit” of the KE-4/KE4a manual. When the lamp flashes fast, refer to “Alarm Indication” of the KE-4 manual. Confirmation of the engine stop Step...

  • Page 93: Alarm Indication

    ALARM INDICATION In the case of system fault, the failed point is indicated with the lamp fast flashing frequency. Please refer to “Alarm Indication” of a KE-4 control system instruction manual. CHECK POINTS IN CASE OF TROUBLE Always consult this table first when any operationa problems are observed.
