Summary of Contents for Magic Control Technology USB 2.0 DUAL DISPLAY HUB

  • Page 1 USB 2.0 D ISPLAY USER MANUAL...

  • Page 2: Table Of Contents

    ONTENTS ................3 ................3 EATURES ............3 YSTEM EQUIREMENTS ............... 4 ACKAGE ONTENTS ..........4 ARDWARE RIVER ETUP ROCESS : ....... 5 UPPORTED OMMON ISPLAY ESOLUTION ......6 ..........6 EVICE RIVER NSTALLATION ......10 ERIFYING EVICE RIVER NSTALLATION ........

  • Page 3: I N T R O D U C T I On

    ANUAL Thank you for purchased the USB 2.0 Dual Display HUB! USB 2.0 Dual Display HUB, this brilliant solution enables connection to any display device such as LCD monitor and attachment of any two USB 2.0 devices, simply through a universal USB 2.0 cable.

  • Page 4: Package Contents

    Dual Display Hub and switch it on. 3. Connect the AC power adapter to USB 2.0 Dual Display Hub. 4. After reboot the PC / laptop, plug the USB 2.0 Dual Display Hub into an available USB 2.0 port of your PC/laptop.

  • Page 5: Upported Ommon Isplay Esolution

    USB 2.0 D ISPLAY ANUAL UPPORTED OMMON ISPLAY ESOLUTION Refresh Rate USB-VGA USB-DVI Resolution Frequency 800 * 600 16bit, 32bit 16bit, 32bit 60Hz,75Hz 1024 *768 16bit, 32bit 16bit, 32bit 60Hz,75Hz 1152 * 864 16bit, 32bit 16bit, 32bit 60Hz 1280 * 720 16bit, 32bit 16bit, 32bit 60Hz...

  • Page 6: I N S T A L L A T I O N O N W I N D O W S 2 / X P / V I S T A

    USB 2.0 D ISPLAY ANUAL EVICE RIVER NSTALLATION Installing the device driver enables your computer‟s operating system to recognize the once it‟s connected. Please check your operating system USB 2.0 D ISPLAY and refer to the appropriate installation procedure to begin installing the device driver. This section illustrates the simple device driver installation procedure for computer running Windows XP operating system.
  • Page 7 USB 2.0 D ISPLAY ANUAL Step 3. License Agreement; please read it and select “I accept the terms of the license agreement.” Click “Next” to accept the License Agreement. Step 4. Setup is searching for installed features….. ※ You may notice the screen flashes during hardware installation. It is part of the normal process.
  • Page 8 Step 5. Click “Finish” to complete the software installation. Step 6. Plug the USB 2.0 Dual Display Hub into an available USB port of your computer. The device driver will be configured automatically, and you will see below notification balloons.
  • Page 9 USB 2.0 D ISPLAY ANUAL When the Hardware Installation Wizard dialog appears, please select “No, not this time” ※ and click “Next” to continue. Click “Continue Anyway” when the Microsoft Software warning dialogue box appears. Then, click “Finish” to complete the Hardware Wizard. Step 7.

  • Page 10: Verifying Device Driver Installation

    USB 2.0 D ISPLAY ANUAL ERIFYING EVICE RIVER NSTALLATION The following procedure allows you to verify the device driver installation. Please right click “My Computer” → “Properties” → “Hardware” → “Device Manager”. , then double click “Display adapters”, and Plug-in the USB 2.0 D ISPLAY “Universal Serial Bus controllers”.

  • Page 11: Device Driver U N - Installation

    USB 2.0 D ISPLAY ANUAL EVICE RIVER INSTALLATION Step 1. Click “Start” → “Control Panel” → “Add or Remove Programs” Select “ Trigger External Graphics Family 12.xx.xxxx.0179” (driver version). Click “Uninstall” button. and click “OK” to continue. Step 2. Unplug the USB 2.0 D ISPLAY Step 3.

  • Page 12: Evice River Nstallation

    USB 2.0 D ISPLAY ANUAL EVICE RIVER NSTALLATION Installing the device driver enables your computer‟s operating system to recognize once it‟s connected. Please check your operating the USB 2.0 D ISPLAY system and refer to the appropriate installation procedure to begin installing the device driver.
  • Page 13 USB 2.0 D ISPLAY ANUAL Step 3. License Agreement; please review it and check “I accept the terms of the license agreement.” Click “Next” to accept the License Agreement. Step 4. Setup is searching for installed features..*You may notice there a screen flashes during hardware installation. It is part of the normal process.
  • Page 14 After the driver is configured, you also could click “Show hidden icon” and will see the “Super Utility” icon on taskbar. The extended display will be shown on the attached display device. You may begin to use the USB 2.0 Dual Display Hub with your display device.
  • Page 15 USB 2.0 D ISPLAY ANUAL If the extended display come out with the duplicate or blind screen, please right click on the desktop of your system, it will pop up a screen and select “Screen resolution” (a), or go to “START”→ “Control Panel”→ “Appearance and Personalization”→...
  • Page 16 USB 2.0 D ISPLAY ANUAL After reboot the computer, the USB extended display will be shown on the attached display device.

  • Page 17: Verifying Device Driver Installation

    USB 2.0 D ISPLAY ANUAL ERIFYING EVICE RIVER NSTALLATION The following procedure allows you to verify the device driver installation. Please right click “Computer” → “Properties” → “Device Manager”. , then double click “Universal Serial Bus Plug-in the USB 2.0 D ISPLAY controllers”.

  • Page 18: Device Driver U N - Installation

    USB 2.0 D ISPLAY ANUAL EVICE RIVER INSTALLATION Step 1. Access Program Uninstall: Click “Start” →“Control Panel” →“Programs”. Click “Uninstall a program” Look for “ Trigger External Graphics Family 12.xx.xxxx.0179” (driver version). Click “Uninstall” button. and click “OK” to continue. Step 2.

  • Page 19: F U N C T I O N D E S C R I P T I On

    TV display, projector…. USB 2.0 D CCESS ISPLAY TILITY Make sure the USB 2.0 Dual Display Hub is attached to the PC. Look for the two icons on the lower right toolbar on Windows 2000/XP/Vista or an icon ”Super Utility” under the “Shown hidden icons”...

  • Page 20: Display Rotation

    USB 2.0 D ISPLAY ANUAL ISPLAY OTATION 4 options available: “0°, 90°, 180°, 270° under the Extended or Primary display modes. It is a useful function for some rotatable display device. ISPLAY ODES  “E ” XTENDED DISPLAY MODE EFAULT A default display mode;...

  • Page 21: Identify Monitors

    A unique feature to allow USB Display enabled device to act as the main working display. The USB 2.0 Dual Display Hub will work as the main graphics adapter of the system. The on- board screen will work as the extended display.

  • Page 22: Multi -Display Control Panel

    USB 2.0 D ISPLAY ANUAL ULTI ISPLAY ONTROL ANEL An unique feature to allow much quicker and simpler working experience under multi- display environment. A series of hotkey to quickly move active window or cursor to the desired display device (either on-board or each USB Display enabled devices).

  • Page 23: Q & A

    This may damage your monitor. You can also try to reset/refresh/resynchronize your monitor. Q: Direct3D does not work? A: This is a limitation of the USB 2.0 Dual Display Hub on Windows 2000/XP/Vista except for Windows 7.

  • Page 24: T R O U B L E S H O O T I N G T I Ps

    USB 2.0 D ISPLAY ANUAL This section describes the general troubleshooting tips regarding to the installation or operation of the USB D ISPLAY EVICE Known Issues Direct 3D is not supported under 2000/XP/Vista. It supported under Windows 7 Aero mode. Please set the Aero mode to play DVD on Windows 7.

  • Page 25: Others

    USB 2.0 D ISPLAY ANUAL - Your PC may be lack of certain video codec to support playback of certain video format. Please use the link below to install license free media codec. K- Lite: http://www.free-codecs.com/download/K_Lite_Codec_Pack.htm Video/Media players have different decoding capability under different display modes. For better performance on watching DVD or certain video format on the USB graphics device attached display, it is recommended to use the following license free software.

  • Page 26: Regulatory Compliance

    Copyright© 2012 Magic Control Technology Corporation. All rights reserved. All trade names are registered trademarks of their respective owners. Features and specifications are subject to change without notice. Product may not be exactly as shown in the diagrams.
