CanTech Ether 4.1 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

CanTech s.r.o.
Potoční ul. č.p. 2173/40
787 01 Šumperk
Tel.: +420 583 250 991
E-mail: cantech@cantech.cz
Web: www.cantech.cz
IČ:64608557
DIČ: CZ64608557
zapsáno v OR KS Ostrava, oddíl C, vložka č 14112
ISO 9001:2008 a OHSAS 18001:2007
TAYLLOR & COX s.r.o.

Ethernet card

Ether 4.1
Instruction manual
CanTech
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ether 4.1 and is the answer not in the manual?

Questions and answers

Summary of Contents for CanTech Ether 4.1

  • Page 1: Ethernet Card

    CanTech Ethernet card Ether 4.1 Instruction manual CanTech s.r.o. Potoční ul. č.p. 2173/40 787 01 Šumperk Tel.: +420 583 250 991 E-mail: cantech@cantech.cz Web: www.cantech.cz IČ:64608557 DIČ: CZ64608557 zapsáno v OR KS Ostrava, oddíl C, vložka č 14112 ISO 9001:2008 a OHSAS 18001:2007...

  • Page 2: Table Of Contents

    CanTech CONTENT 1. Basic information.........................3 1.1 Description ..........................3 1.2 Properties ..........................3 1.3 Expandability .........................3 2. WEB interface - internal WEB site....................4 2.1 Status display .........................4 2.2 Network settings ........................5 2.3 Measurement settings......................6 2.4 Calibration..........................7 2.5 Alarm settings ........................7 2.6 Email settings.........................8 2.7 Other settings .........................9...

  • Page 3: Basic Information

    CanTech 1. Basic information 1.1 Description Ethernet card Ether4 allows you to monitor status of the four potential free inputs, measure the temperature and supply voltage and control two relay outputs. Measured values and input status are transmitted in digital form to master system via ethernet interface.

  • Page 4: Web Interface - Internal Web Site

    Using internal WEB site you can track inputs and measured values. It also allows you to view and configure. To save the settings, you need to log username and password. Default settings: Name: cantech Password: cantech IP address : 192.168.1.103 Mask : 255.255.255.0...

  • Page 5: Network Settings

    CanTech Table of values: … measurement is fine and if watching limits, is within … measurement is fine and the value is out of limits … measurement error Note: User alarms can not be set using the HTML. It is only possible using program Eth4_nastavení.exe...

  • Page 6: Measurement Settings

    CanTech After completing the reset, change text “Performing Reset“ to “Reset done” 2.3 Measurement settings Select value : select the value with which to work Text : description of value – maximum 24 symbols Serial number : number of the thermometer if it is used only one thermometer, a value is empty when using multiple thermometers, each must have its own address.

  • Page 7: Calibration

    CanTech 2.4 Calibration Calibration can be performed either single-point or two-point: Single-point calibration – value at MIN remains 0,0 and at button single-point to enter the current value and presses the button Single-point. Two-point calibration – sets the minimum value and this is entered at MIN and presses MIN.

  • Page 8: Email Settings

    CanTech Select alarm : select the alarm, with which to work Use : if the alarm is to be used Negation : checked – alarm is, when the contact is closed unchecked – alarm is, when the contact is open...

  • Page 9: Other Settings

    CanTech 2.7 Other settings Title : text displayed in the page header Signature : text at the end of the window Status Dec. Separator. : decimal separator Period : period for refresh site Status in milliseconds. If 0, then the refresh does not...

  • Page 10: Xml

    CanTech Time of status : determines the lenght of the switching relay (if I need to restart the switch, on which hangs Ether4). If 0, the relay switches permanently. - mark for the internal relay – displays the status of auxiliary relay contacts - mark for the transistor output–...

  • Page 11: Snmp Protocol

    CanTech 3. SNMP protocol MIB file (Ether4.mib) is stored in the Ethernet card and is available in Download section. Note: The analog values are converted to an integer value, by multiple according to number of decimal places. 4. Modbus TCP Card communicates with Modbus protocol on port 502.

  • Page 12: Program For Setting - Eth4_Setting.exe

    CanTech 5. Program for setting – Eth4_setting.exe 5.1 Introduction window and description of menu Menu: File Open – load the settings file Save – saves the settings to a file Save as – saves the settings to a new file Setting Load –...

  • Page 13: Html - Setting Texts

    CanTech Login(Logout) – used to log on to enable the save settings IP address – IP address of card you want to set In this window you can set the parameters of network. In addition you can enter: SNMP trap IP(1,2) – target server for a trap and community NB name –...

  • Page 14: Config. - Measurement Setup

    CanTech 5.3 Config. – measurement setup Sets the AD converters and their calibration, setings thermometers, power consumption and alarm inputs. AD converters can be used only for the first eight values (default is fitted only measuring voltage converter). Type - 1xAD – simple AD converter 2xAD 1.
  • Page 15 CanTech 0..1 – number of binary input which generates a pulse 2.hrs – if the type Energy 0..7 – 2.value of multiple if the type Pulse 0 – measure time between pulses 1 – measure performance Description of the calculation of energy: DC energy(consumption) Assigned Type=Energy, 1.hr=(0..7), 2.hrs=(0..7)
  • Page 16 CanTech Work with pulses: The time between pulses Assigned Type=Pulse, 1.hr=(0..1), 2.hrs=0 Pulse lenght is calculated as follows <Value> = <n> / <Constant> where <n> is the number of CPU ticks ( 1s = 125*10^6/(3*2^8) ticks ) Constant = 40690,104 specifies delay in seconds Measurement of immediate consumption Assigned Type=Pulse, 1.hr=(0..1), 2.hrs=1...
  • Page 17 CanTech Version, Type, Status – not used yet Period AD – time in 10ms between reading AD converters Period DS – time in 10ms between reading thermometers Address MUX – address I2C multiplexer Separator – character of separator of decimal places Period HTML –...

  • Page 18: Mail - Mail Settings

    CanTech perform the same with the maximum value Calculation – calculate the value of offset and constant Copy – calculated values are copied into the corresponding fields on the card Values 5.4 Mail – mail settings Same as in HTML.

  • Page 19: Custom Alarms - Set Custom Alarms

    CanTech 5.6 Custom alarms – set custom alarms Limits are used to monitor values like limits on measurement. Use for setting thermostat, that enter into user alarms. Type : select the type of thermostat Value1 : input value to the thermostat...
  • Page 20 CanTech Each user alarm consists of logical operations between individual operands. Using the timer function, signals can be delayed (it used max. 8 timers). Based on the evaluation of the user alarm sends a trap, mail or switches associated output. Alarm is evaluated from left to right and parentheses indicate priority.

  • Page 21: Discoverer - Search Device In Network

    CanTech 5.7 Discoverer – search device in network Finds all Ether4 in network and displays their IP address , NB name and MAC address.

  • Page 22: Program Ether4.Exe

    CanTech 6. Program Ether4.exe Program used to monitor one or more devices Ether4 in the network. Displays the status of inputs, outputs, user alarms and measured values. Status changes can be saved to a log file. Measured values can be saved to files and plot their graph.

  • Page 23: Panel Of Device List

    CanTech Device states are also displayed in the icon of the program: All devices are within normal Was captured the trap Somewhere there is alarm Appeared measurement fault or communication 6.1 Panel of Device list Column: # - serial number, color of field specifies the communication status...

  • Page 24: Alarms Panel

    CanTech 6.2 Alarms panel In left column are shown the status of digital inputs, the right displays the users alarm. If there is no defined user alarm, so does not appear The green LED in left upper corner appears when List of devices is hidden and displays the communication status.

  • Page 25: Upgrade Firmware

    CanTech After clicking on the switch, the output switches. Before switching will ask for a name and password. Login data are stored and the second time to them without asking. 7. Upgrade firmware Program Ether4_FW.exe used to store the new firmware to Ether4.

  • Page 26: Connection

    : +420 583 250 991, +420 583 250 995 CanTech s.r.o. Potoční ul. č.p. 2173/40 787 01 Šumperk : www.cantech.cz E-mail : cantech@cantech.cz Firma CanTech si vyhrazuje právo pro případné změny. Prosím, kontaktujte obchodního zástupce firmy CanTech pro další informace.
