Save This Manual for Future Reference
Original Instruction
All Terrain Mini Hauler
Operator's Manual
MODEL NUMBER : P K 9 7 1 5
SERIAL NUMBER :
Both model number and serial number may be found on the main label.
You should record both of them in a safe place for future use.
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING
MACHINE
Advertisement
Table of Contents
Summary of Contents for Pow’R’kraft PK9715
- Page 1 Save This Manual for Future Reference Original Instruction All Terrain Mini Hauler Operator’s Manual MODEL NUMBER : P K 9 7 1 5 SERIAL NUMBER : Both model number and serial number may be found on the main label. You should record both of them in a safe place for future use. FOR YOUR SAFETY READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING MACHINE...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Specifications Introduction Item No. PK9715 Specifications 196cc, 6.5HP Engine 3F+1R Symbols Transmission Load Capacity 300 kg Safety Box Length 860 mm General Safety Rules Box Width 630 mm Specific Safety Rules Box Depth 290 mm Contents supplied... -
Page 4: Safety
Dress properly. Wear heavy long pants, boots and gloves. Do not wear loose clothing, short pants, and jewelry of any kind. Secure long hair so it is Do not smoke or have open flames. above shoulder level. Keep your hair, clothing and gloves away from moving parts. - Page 5 When refilling or draining the fuel tank, use an the job better and safer at the rate for which it approved fuel storage container while in a clean, was designed. well-ventilated outdoor. Do not smoke, or allow Do not change the engine governor settings or sparks, open flames or other sources of ignition over-speed the engine.
-
Page 6: Specific Safety Rules
Have your machine serviced by qualified repair Pay the utmost attention when working on frozen personnel using only identical replacement parts. ground as the machine may tend to skid. This will ensure that the safety of the machine If possible, avoid driving on pebbly river bed, maintained. -
Page 7: Contents Supplied
CONTENTS SUPPLIED 6. Hardware Bag, including The all terrain mini hauler comes partially assembled and is shipped in carefully packed package. After all the parts have been removed from the package, you should have: ASSEMBLY Following the assembly directions below, you will assemble the machine in a few minutes. - Page 8 Position the bottom panel inside the mounting bracket. Align the holes with the mounting bracket. Insert a long pin through holes and secure each side with a flat washer and cotter pin. Engine oil Oil has been drained for shipping. Failure to fill engine sump with oil before starting engine will result in permanent damage and will void...
-
Page 9: Know Your Mini Hauler
KNOW YOUR mini hauler Features and Controls Engine Switch Throttle Control Right Steering Lever Clutch Control Lever Left Steering Lever Dump Box Gear Selection Lever Tipping Handle Track Gearbox Engine switch Throttle control The engine switch enables and disables the ignition It controls engine speed. -
Page 10: Mini Hauler Operation
Tipping handle Set the throttle lever on the handlebar at half- way position. It controls tipping of the dump box. Pull the tipping handle up to release the dump box's locking device 2. Hold the start handle firmly and pull rope out and raise the dump box. -
Page 11: Maintenance
If the machine is stopped on a steep slope, a wedge Adjusting clutch should be placed against one of the tracks. As clutch wears out, the same lever could have a wider opening, being so uneasy to use. This means Idle speed that it is necessary to adjust the cable, setting Set throttle control lever to its “... -
Page 12: Storage
If the distance is greater, proceed as follows. Loosen the locknut A and bolt B shown in above figure to let the tracks loose enough. Use the tipping handle to tip the dump box and set it on blocks or supports rated for the weight of the box. -
Page 13: Trouble Shooting
Use clean cloths to clean off the outside of the Store your unit on flat ground in a clean, dry machine and to keep the air vents free of building that has good ventilation. obstructions. Do not store the machine with fuel in a non-ventilated area where fuel fumes Do not use strong detergents or may reach flame, sparks, pilot lights or... -
Page 14: Parts Schedule
PARTS SCHEDULE All terrain mini hauler... - Page 15 Dump Box Gear Box All terrain mini hauler...
- Page 16 Please contact us at Support@powrkraft.com or go online to www.PowRkraft.com. Thank you for allowing us to serve you. Betst Products Family 83371 Melton RD Creswell OR 97426 Contact Information: Telephone: Local 541-895-3083 Toll Free: 1-877-876-7895 Fax Number: 541-895-2756 Efax Number: 904-216-2059 To Place Order: Ext.
