Makisolar DR-0433-G Instruction Manual

Solar Light
READ THE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND INSTALLATION
FIRST TIME USE: Remove the protective film (if have) from the solar panel before the first use
CHARGING: the product must be left to charge 2 sunny days on OFF position before best
results are achieved.
STEP1. Charge the solar product by placing it under direct sunshine for at least 8 hours.
STEP2. Switch the knob to "AUTO" position and solar product will now work
automatically, charge under direct sunshine in the day time and illuminate at night.
NOTE: In order to verify that the knob is correctly switched to "AUTO" position, cover
the solar panel with your hand and light will turn on automatically.
MPORTANT:
1. Install the solar product in an area where it can get
direct sunshine free from cover or shade.
2. DO NOT switch the knob to "OFF" anymore.
3. Select an outdoor location not near to night light
sources, such as street lights, which may cause the light
to turn "OFF" automatically.
4. Duration of light depends on solar product's level of sunshine exposure, geographical
locations, weather conditions and the hours of daylight.

Assembly Instructions

Ground mounting (If stake provided)
1) Carefully remove the solar light and all the fittings out of the box.
2) Assemble the body and stakes by plastic joints and ; Push the stake directly into
the ground (DO NOT hammer the light or the stakes).
3) Slot the lamp head on the upper part of the mounting body carefully.
4) Sensor detection (If functioned): when the sensor detects movement, all LEDs
will be turned on and keep working for 10-30 seconds and turn off automatically;
the sensor detects an area of about 90 degrees vertically and about 90 degrees
horizontally, with a range about 5 meters.
Instructions Manual
For DR-0433-G
1
