EzwatchPro 480ZOOM SKU# 480ZOOM User Manual

DIGITAL VIDEO CAMERA
User's Manual
SKU# 480ZOOM SKU# 480ZOOM
Indoor High Resolution Color Camera
WARNING WARNING
Attention:
To reduce the danger of electric shock, please do not open the case (or back
cover) of camera; everything needed for user operation is on the surface of
the camera; please seek help from a qualified professional for repair. the camera; please seek help from a qualified professional for repair.
Attention items:
• Do not touch CCD or lens
• Do not use any unidentified power supply
• Avoid installation in unstable places • Avoid installation in unstable places
• Do not use camera in the following conditions,
Temperature: -20⁰C/+50⁰C
AI: Auto Iris AI: Auto Iris
BLC: Back Light Compensation
ATW: Auto Trace White
MWB: Manual White Balance
AWB: Auto White Balance
SL: Slow-Shutter SL: Slow-Shutter
AES: Auto Electronic Shutter
AGC: Auto Gain Control
MIR: Mirror
Y/C: Luminance(Y) & Chrominance
• Suggested mounting height 8'-12'
• Do not mount camera directly to a metal surface
• Do not point camera directly into light sources • Do not point camera directly into light sources
Image Sensor 1/3" SONY High Resolution CCD
Effective Pixels PAL:795(H)x596(V) NTSC:811(H)x508(V)
Sensor area 4.9mmx3.7mm
Signal system PAL/NTSC
Horizontal resolution
Minimum illumination Minimum illumination
Electronic shutter Auto:1/2(3/5)-1/120,000Sec
S/N ratio
Gamma
Lens 3.6-8mm Manual Zoom
Video output 1.0Vp-p, 75Ω
Power supply Power supply DV 12V±10% DV 12V±10%
Power consumption less than 3.0W
480TVL
0.1Lux 0.1Lux
>55dB
0.45
