LEADWARRIOR LW 35027 Manual

LW 35027
R3 R4
R20
R21
R9
R20
Bench position is optional
R21
R9
R20
4
SPARE WHEEL
FRONT MOUNTING
( OPTIONAL )
R28
TAMIYA spare wheel
TAMIYA part B32
LW 35027
WWW.LEADWARRIOR.COM
R14
R14
R18
R16
R17
R21
R9
R13
R20
?
?
MAKE
R21
4
R9
R24 (R25)
R26
INFO@LEADWARRIOR.COM COPYRIGHT 2007
3 LW 35027
LEADWARRIOR
HISTORICAL MINIATURE
R14
STEYR Type 2000A
L.gl.Lkw
Light Cargo Truck
R19
CONVERSION KIT for
TAMIYA Steyr Type 1500A ( kit #35225 )
53 RESIN PARTS
R13
Austria's all wheel drive Steyr 1500A was one
of the many personnel/transport vehicles
which was designed to meet Whermacht
requirement for standard army 1,5 ton truck.
Presented in 1941, the Steyr was used as troop
transport in all the war theaters. A total of more
than 20,000 were built, in a wide range of
variants
Tamiya presents basic and command versions.
The chassis of Steyr 1500A and it's reinforced
variant Steyr 2000A were also used for Fire
trucks, Omnibus (Leadwarrior kit Lw35026),
Ambulance (Leadwarrior kit Lw35025),
universal "Funk-Koffer", and different types of
cargo carriers with opened, metal or wooden
cabins.
The initial variant of cargo truck on Steyr
1500A chassis had opened driver 's
compartment combined with wooden trunk
(Leadwarrior kit Lw35023).
LW 35027
WWW.LEADWARRIOR.COM
WWW.LEADWARRIOR.COM
INFO@LEADWARRIOR.COM
Ebay:
This conversion kit presents mid-war cargo truck on
Steyr 2000A shassis with full-metal cabin (by the end
of the war metal cabins were replaced by wooden
"Einheitsfahrerhaus" ones).
The rear springs were reinforced, and twin rear
wheels were mounted. The spare wheel was stored
infront of engine compartment.
This very type of truck was tested on railway drive
(Leadwarrior kit Lw35028).
Steyr 2000A L.gl.Lkw captured by americans.
INFO@LEADWARRIOR.COM COPYRIGHT 2007
LEADWARRIOR
