TM
Split a serial data
stream to serial and IP
Ethernet-to-Serial Device Server / Pass-Through Port
APPLICATION: POS Surveillance
surveillance camera
ECR/POS
terminal
LAVA DataTap-IP Application:
Connect a POS station to a DVR for text overlay
onto surveillance video. The LAVA DataTap-IP taps into
the receipt printer's data stream, making POS transaction
data a security tool.
2 Vulcan St., Toronto, ON
Tel
: 416.674.5942
Canada, M9W 1L2
Fax:
416.674.8262
Serial 2
LAVA DataTap-IP's
serial port pass-through
operates as the functional
equivalent of a direct serial
connection between POS
terminal and printer.
Toll Free (US & Canada): 800.241.LAVA
www.lavalink.com
LAVA DataTap-IP
LAVA: Connect Simply
Ethernet
LAVA
DataTap-IP
The LAVA DataTap-IP's
Serial 1
Ethernet port provides an IP connection
between the RS-232 serial port
on the POS station
and the Ethernet port on the DVR.
DVR software handles printer output
text overlay.
POS printer
Easy set-up: Configure the LAVA DataTap-IP using a web
browser. Then connect the POS terminal and printer to the LAVA
DataTap-IP and connect the LAVA unit to your network, and
you're done.
Digital Video Recorder
Advertisement
Summary of Contents for Lava Lava DATATAP-IP
- Page 1 DVR software handles printer output text overlay. POS printer Easy set-up: Configure the LAVA DataTap-IP using a web browser. Then connect the POS terminal and printer to the LAVA DataTap-IP and connect the LAVA unit to your network, and you're done.
- Page 2 For splitting a serial data stream to both a serial pass-through port and to IP. The LAVA DataTap-IP provides serial port splitting and routing. This capability can enable a POS station to both print to a serial printer and to send transaction information to a DVR (which can then overlay that information onto a video stream).
