Trueful Electronics 600VA User Manual

UPS
600VA～1000VA
USER`S GUIDE
INTRODUCTION.......................................................................1
FEATURES...............................................................................1
SAFETY INSTRUCTIONS............................................................2
GETTING STARTED...................................................................3
THE DISPLAY PANEL................................................................3
SPECIFICATIONS.....................................................................4
SOFTWARE INSTALLATION.......................................................5
UPS TROUBLESHOOTING......................................................... 5
INTRODUCTION
＊Thanks for buying one of these UPS Series. This Guide can use on:
600VA ~ 1000VA
＊Reading this USER`S GUIDE first before you start.
＊Attached Warranty Card that service person can keep record of the UPS`s status.
UPS (Uninterruptible Power Supply) Series Introduction
All UPS insist the quality on all of products, which is designed for PC and other
peripherals only. Our UPS`S have various kinds of capacity for each equipment.
These Series are compact, low noise and easy-to-use UPS which can solve different
power problems. They provide stable, clean power, and prevent data loss caused by
outages and brownouts.
FEATURES
SELF TEST:
Self test each time switched on.
When UPS is turned on, it makes self-test to provide a reliable operation and prevent
any damage caused.
BATTERY PROTECTION:
Auto self-test and discharge protection.
DC START CAPABILITY:
The UPS can be activated without utility power.
UPS POWER SUPPLIED OUTLETS:
Line-Interactive UPS+AVR
Allows 75% to 125% input voltage range-best protection for computer equipment.
With AVR function (boost & buck), UPS provides a stable power to the loads as the
input voltage fluctuates.
ELECTRICAL PROTECTION:
Automatic cut off on short circuit or Input Circuit Fuse. If UPS is overload, this circuit
Fuse will trip to disconnect the unit from utility power.
MODEM/NETWORK PROTECTION:
RJ45 JACK (option) : Simultaneous protection for network, telephone, fax & modem.
AUDIBLE ALARM:
Battery Back-up: slow beeping (10 seconds) Battery Low and Overload or AC
Overload: Rapid beeping (1 Second)
INTERFACE AND SOFTWARE:
RS-232 Interface: Software for MS-Win98/ME/2000/XP,Novell, and Linux
CPU MICRO PROCESS CONTROL, USE WITH STABILITY.
1
