Summary of Contents for OneTouch PB60
- Page 1 PB60 Portable Power Bank User Guide CJB1890ALAAA...
-
Page 2: Table Of Contents
Catalog ..................Overview ..............3 Specifications ............. 4 Quick Start ..............5 Care and Maintenance ..........8 Declaration of Conformity ......... 8 Guarantee ..............10... -
Page 4: Specifications
Specifications Dimension 89x49x 27.7mm Weight About132g Capacity 5200mAh Input voltage Input current 1000mA Input port Micro USB Charge time About 7hours Output voltage Output current 1000mA Output port A type USB Discharge Temperature -10°C ~55°C Charge Temperature 0°C ~45°C Storage Temperature -15°C ~55°C... -
Page 5: Quick Start
Quick Start Application : Power Status Checking Before use the power bank, one has to understand the level of power stored in its battery. Simply press the button 1.5s open the power bank to see how the LED light indicates. Refer to the table below, you will know the status. - Page 6 Charging status Capacity LED1 LED2 LED3 LED4 0-25% Flash 25%-50% Light Flash 50%-75% Light Light Flash 75%-100% Light Light Light Flash Discharging status Capacity LED1 LED2 LED3 LED4 0-25% Light 25%-50% Light Light 50%-75% Light Light Light 75%-100% Light Light Light Light Power on/off: press button 1.5s...
- Page 7 1， Power on first（press button 1.5s） 。 2， insert the USB Micro-B plug from the power source into the charge-in port Prior to using the power bank for the first time, you are recommended to fully charge the battery. When the Power Bank is fully charged, Please disconnect the Micro USB cable with the Power Bank.
-
Page 8: Care And Maintenance
Hereby, TCT Mobile Limited declares that this product is in conformity with the following essential requirements. WEEE Approval This device PB60 is in compliance with the essential requirements and other relevant provisions of the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE Directive). - Page 9 RoHs Approval This device PB60 is in compliance with the restriction of the use of certain hazardous substances in electrical and electronic equipment Directive 2002/95/EC (RoHs Directive). EC DECLARATION OF CONFORMITY Manufacturer / Importer certifies that the following designated product Product Name: Power Bank Item No.: onetouch PB60...
-
Page 10: Guarantee
Federal Communications Commission (FCC) Statement PB60 complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Need help?
Do you have a question about the PB60 and is the answer not in the manual?
Questions and answers
What can i work with this item
The OneTouch PB60 is a power bank used to charge electronic devices. It stores electrical energy and can be used to recharge smartphones, tablets, or other USB-powered devices.
This answer is automatically generated
Haw is working
The OneTouch PB60 works as both a WiFi hotspot and a backup battery pack. It provides high-speed Internet access for up to 10 devices at the same time through a portable dongle. It also includes a powerbank that can charge any USB device. You can use it with a USB power adapter to create a WiFi zone at home or in a car, or use the battery pack to stay connected in open environments.
This answer is automatically generated
