Nexa LEST-701 Operating Manual

Wireless extender device
Hide thumbs
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual
Operating manual
Model: LEST-701
Wireless Extender Device

Characteristics:

a. LEST-701 is an extender of RF remote control device.
b. LEST-701 extends RF transmission distance (between transmitter and receiver) at least 30 meters in open field.
c. Suitable for remote receiving in the corner or longer transmitting and receiving distance.
d. IP 56 waterproof certified plastic enclosure housing.
e. DC type battery operated. Long battery life (12 months).

Installation:

1. Use"ㄧ＂minus type screwdriver to take off the hook.
2. Use screwdriver to open the battery compartment door (8 screws off).
3. Put in 2 * AA 1.5V Alkaline battery (excluded ex-factory).
4. LED light on for 1 sec. then light off entering STAND BY mode.
5. Learn the code with transmitter. (Code learning, please refer to Program paragraph).
6. Close the battery compartment door with screws (waterproof concern).
7. Mount back the hook.
8. Hang LEST-701 to the wall or stand on the desk where it is as an extender for lengthening transmission distance between transmitter and
receiver.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEST-701 and is the answer not in the manual?

Questions and answers

Related Manuals for Nexa LEST-701

Summary of Contents for Nexa LEST-701

  • Page 1 6. Close the battery compartment door with screws (waterproof concern). 7. Mount back the hook. 8. Hang LEST-701 to the wall or stand on the desk where it is as an extender for lengthening transmission distance between transmitter and receiver.
  • Page 2 Program: Code Setting 1. Insert battery, LEST-701 LED will light on for1 sec. then light off entering STAND BY mode. 2. Press “Learn” button, LEST-701 LED will blink (quicker). 3. Press transmitter “ON” key which is going to be programmed.
  • Page 3 3. LEST-701 LED blinks twice (slower) for confirmation of deletion. All memories 1. Press “Learn” button of LEST-701 for 6 sec., LED blinks (quicker). 2. Release “Learn” button. 3. Press again “Learn” button, LED blinks twice (slower) for confirmation of deletion of all 6 memories.
  • Page 4 IP 56 Notice: 1. More than 1 piece LEST-701 with same learned code is restrict in an environment to prevent more than 1 piece LEST-701 sending code to each other continuously. 2. LEST-701 LED continuously blinking each 3 sec. is low battery till drained of battery current for at least 7 days then LED stops blinking.
