Page 1: Operating Instructions
® ® /e-S Lood ™ ™ (Rechargeable) Operating Instructions 99 Washington Street Melrose, MA 02176 Phone 781-665-1400 Toll Free 1-800-517-8431 Visit us at www.TestEquipmentDepot.com... - Page 2 The LiteBox is available in three basic systems: the Standard model, the Vehicle Mount model and the ® Power Failure model. All come with a convenient charging rack that does not require LiteBox disassembly ® for charging. The battery is capable of being recharged up to 500 times.
- Page 3 The charging rack supplied with the lantern is meant for permanent installation, depending on the model, either indoors or in a vehicle. All three models can be charged without racks. The Standard and Power Failure models (LiteBox only) include cigarette lighter adapter for temporary non-rack charging in most ®...
- Page 4 The recommended mounting positions are from vertical to horizontal, but with the lamp end facing up. Allow enough extra space above the rack for removing and replacing the LiteBox®/FireBox®. VEHICLE MOUNTED, DIRECT WIRE CHARGE RACK The 12V DC Direct Wire Charge Cord (#22050) is offered for those who would like to permanently mount a Streamlight charger in their vehicle.
-
Page 5: Battery Replacement
(red) terminal nearest to the circuit board. Connect the red wire to the positive (+) tab of the battery and the black wire to the negative (-) tab. Reversing these connections will damage the LiteBox /FireBox .
