USER MANUAL

May 2010 Version 15.0

Models for Swimming

Pools using Hypo and

CO2 Gas

SC100WP

SC101

SC103

SC106

Models for Swimming

Pools using Electrolytic

Chlorinators and Acid

SE100WP

SE110

SE130

Models for

Swimming Pools using

Electrolytic Chlorinator

and CO2 Gas

SE100C

AQUARIUS

T E C H N O L O G I E S P T Y L T D

ATER

UALITY

ONTROL

Table of Contents

Need help?

Do you have a question about the SL100WP and is the answer not in the manual?

Questions and answers

Summary of Contents for AQUARIUS SL100WP

Page 1 Models for Swimming Pools using Pools using Hypo and Pools using Electrolytic Swimming Pools using Hypo and Liquid Acid CO2 Gas Chlorinators and Acid Electrolytic Chlorinator and CO2 Gas SL100WP SE100WP SE100C SC100WP SL111 SE110 SC101 SL113 SE130 SC103 SL136...
Page 2: Table Of Contents
Coopers Plains QLD 4108 (07) 3274 4736 PO Box 71 w: www.aquariustech.com.au Coopers Plains QLD 4108 e: info@aquariustech.com.au AUSTRALIA This document is subjected to Aquarius Technologies Pty Ltd trading terms and conditions which can be obtained from the following link http://www.aquariustech.com.au/terms.html...
Page 3 Aquarius Water Treatment Controllers Congratulations We know you will be happy with your decision Let us help you to learn about your new to purchase a new Aquarius Technologies Controller. This manual will take you through Controller. These units are now supplied with...
Page 4: Where To Find The Serial Number
Where to find the serial number Model SC110 Serial Identification Label Key data being: All Aquarius Technologies Controllers are manufactured with a Serial Identification Label Model e.g. SC110 (SIL). This is actual Controller model and indicates This will be affixed to the wall of the controller, the configuration.
Page 5: Section Contents
Water Usage Meter Read Screen System Configuration • Superchlorination Read Screen • LSI/FAH Read Screen • Protocol Read Screen Aquarius Control Systems Tank Alarm (with wiring instructions) Screen Data Logging & Communications Setup Buttons • Hyper Terminal Set Up • Default Screen •...
Page 6: Installation Guidelines
Check for, and time of installation. repair any leaks. The Aquarius Controller is Minimum system requirements now ready for use. Liaise with your chemical There are several minimum requirements that...
Page 7: C Leaning Flow/Conductivity/Temp Sensor
(AS9500) for about 5 minutes to completely dissolve any trace of inorganic Routine Testing foulants. The use of an Aquarius control system will automatically vary the dosages and maintain Remove and rinse thoroughly in fresh water good conductivity, pH, ORP and disinfection before replacing it in the manifold.
Page 8: Warnings
Installation Guidelines Installation Guidelines Warnings the complete operation of the controller system should be verified at least on a monthly basis. Chemicals used as part of the treatment All sensors should be inspected, cleaned and program may be hazardous. Refer to the Material Safety Data Sheets (MSDS) provided calibrated as necessary every month.
Page 9: Installation Guidelines - Section
Installation Guidelines     Typical Installation Schematic...
Page 10: System Configuration - Section
System Configuration Aquarius Control Systems Your new Aquarius controller system features a front panel that consists of:- Screen A 4x20 line alphanumeric display Buttons The six button key pad is the primary user interface. The buttons provide the means to navigate the screens and set the operational parameters for your desired treatment program.
Page 11: Default Screen
Combination Calibration Mode As both the pH and ORP sensors are contained within the one electrode it is possible to perform both pH calibration and ORP verification in one step. For this you will need Aquarius combination buffers. Part Number: AS7086 - pH 7.01 &...
Page 12: Orp Verification Mode
System Configuration ORP Verification Mode To verify ORP separately press ENT for ORP verification. Then place the probe in the requested solution and press ENT. The screen will display the message ‘PROBE STABILISING PLEASE WAIT’. Then rinse the probe in fresh water and place it in the second solution requested, press ENT when ready.
Page 13: Erase Calibration Mode
Panel Selection Mode While in calibration mode the user has the choice of viewing either the standard Aquarius default screen or having all sensor data displayed as the default screen. To make this selection press ENT and there will be a prompt to select the default option.
Page 14: Set Screens Menu
ORP, pH, Conductivity requirements. Once the program has been determined, it may be set in the Aquarius controller, as described in the following sections. The SET button gives access to the thirteen separate screens which may be used in setting a water treatment program as shown in the following graphic.
Page 15: Set Time & Date Screen
System Configuration Set Time and Date Screen TIME & DATE The current time, day, week, and date are important for managing CLK=01:50:36 DAY=Mon WEEK=2 the treatment program and timing of ORP, biocide control, and for DATE=21/03/2006 time stamping the data log. Only two values are adjustable but each contains several components.
Page 16: Set Alarms Screen - Name & Phone
System Configuration Set Alarm Screen - Name and Phone Allows the user to enter up to three names and contact phone numbers to receive notification of system alarms via mobile phone sms alerts. Only available when a Communications Kit is fitted to the controller Options: (three phone numbers) PH1/PH2/PH3 Use the arrow keys to cycle through these...
Page 17: Set Orp Screen
System Configuration Set ORP Screen Not Available on all Controllers. Refer to table 2. Adjacent. Allows the user to set the ORP options for the controller. Table 2. SET: C [x] A & P [value from Table 2] Options: Models - ORP Series Series Series...
Page 18: Set Ph Screen
System Configuration Set pH Screen Refer to Table 3. Adjacent. Allows the user to set the pH options. This screen should never require changing whilst in a monitoring mode. pH is a read only value generated by the controller and is not a value that can be set from this screen.
Page 19: Set Water Usage Meter Screen
System Configuration Set Water Usage Meter (WUM) Screen Allows user to set amount of water per impluse. Use the ENT key to switch between the items. Then use the arrow keys to cycle these selections. Value for Makeup/Bleed/Bkwash can be set from Disabled to 1 Plse = 0.25l would be used if 1000 ltr per Pulse.
Page 20: Set Calcium Hardness Screen
Options: Aquaguard/MODBUS. Use arrow keys to cycle these selections. The Read Status Mode: Aquarius controllers offer a number of read–only screens that show the status of the current treatment program. These are read–only screens and cannot be used to modify a program.
Page 21: Alarm Read Screen
System Configuration Alarm Read Screen The alarm read screen shows the configuration of the system alarms. The second line of the display shows how often alarms will be retransmitted. The third line displays current active alarm. Note: where multiple alarms are active the screen will briefly rotate each alarm into view.
Page 22: Orp Read Screen
System Configuration System Configuration ORP Read Screen This screen displays the ORP status. RL (relay): OFF/ON ORP: The current value of the ORP in millivolts SET: the current control setting for ORP in millivolts DUTY: The current dose pump duty set MODE: ORP/FLOW/CON/OFF Will flash a value if alarmed...
Page 23: Water Usage Meter Read Screen
System Configuration Water Usage Meter (WUM) Read Screen This screen displays the total water usage readings for Makeup, Bleed & their Difference. These values can be reset in the Calibration menu. The corresponding screens display the Makeup, Bleed and BackWash water-meter readings. It also shows the usage as a Month to Date (MTD) &...
Page 24: Lsi/Fah Read Screen
System Configuration LSI/FAH Read Screen This screen displays calculated values for Langelier Saturation Index and Free Available Halogen. LSI: Current calculated value for LSI CAL. H: Value entered for calcium hardness FAH: Current calculated value of FAH For descriptions and information on entering user data, refer to the relevant Set Screen sections.
Page 25: Data Logging & Communications Setup
System Configuration Data Logging and Communications Set up HyperTerminal Setup Data logging facilities are a standard in all “C” series controllers, and with the Data Log interval set to 30 mins - over 4 weeks of data 1. Start Programs, Accessories, Communi- logged on a 24/7 basis, can be stored before it cation, HyperTerminal to start the program is over written.
Page 26: Gsm Modem Set Up
Set up the communications program for direct Provider connection to your serial port (COM1, COM2, 1. Aquarius recommends using Telstra as a at 9600 Baud, 8 Data & 1 Stop Bit, with no Parity Service Provider for Data Communications or Flow Control. The AT&V command (+ENTER)
Page 27: Using Aquaguard 2 Software
AquaGuard will operate in all situations. The Supply Aquarius with the site details to ascertain greatest problem facing new installations is to if a connection can be made from another PC.
Page 28: Bms 4 - 20 Ma Interface
System Configuration BMS 4 - 20 mA. Interface Introduction Flow and all available relay outputs. The Building Management System output option Relay numbering is consistent within each family for your controller provides a local BMS/PLC/ of controllers, but dynamic across the full range, SCADA system with 4-20 mA signals proportional so relay numbers may change depending on your to measured values, along with ON/OFF, clean...
Page 29: Po Box 71
Alarm in the controller (remove sensor, alter SET point etc.) and look for an Alarm indication at the BMS. Useful Contact Information Aquarius Technologies Pty Ltd Record details of your controller here: ABN 94 010 393 254 Controller: Technical Support: Serial Number: .........
Page 30: Manufacturer's Product Warranty
2. If within twelve (12) months (from either the (vi) replace the Product. date of purchase by the Buyer or the date 3. The Buyer will be liable to Aquarius for all of installation, whichever is the earliest) reasonable costs incurred by Aquarius in...
Page 31: Commissioning & Warranty Registration
This form should be completed by the Equipment OWNER promptly after installation & commissioning. When signed is should be faxed to Aquarius Technologies Pty Ltd on +617 3274 4736. This will ensure the equipment details are logged to our confidential Warranty Database to activate your warranty registration and assist our ability to process any future service inquiries.
Page 32 Warranty Registration Faxing Instructions for Registration Fax this form immediately to Aquarius Technologies Pty Ltd +617 3274 4736 Upon receipt your controller will be regis- tered in our equipment database. This will provide a ready confirmation of the actual equipment installed, and the configuration characteristics at your specific installation.

This manual is also suitable for:
