DVD Player
Service
This service manual is for DVP1013/37.
Second Generation model, which is different form the
OPU TYPE: Sanyo
previous generation DVP1013/37 models.
For Second Generation model, the serial number begins
with xx 2A xxxxxxxxxx.
( OPU Type: Sanyo)
Service Manual

TABLE OF CONTENTS

. Technical Specifications.............................................................
. Safety Instruction, Warning & Notes............................................1-3
. Mechanical and Dismantling Instructions........................................
. Region Code, Software Version& Upgrades...................................
. Trouble Shooting Chart...........................................................
. Wiring Diagram......................................................................
. Electrical Diagrams and Print-layouts...........................................6-1
. Set Mechanical Exploded View & Electrical Part list.......................
. Electrical Parts List..................................................................8-1
. Revision List..........................................................................9-1
┬ęCopyright 2007 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by KC-0749 Service Audio
Version 1.0
Second Generation
Printed in The Netherlands
Subject to modification
Page
1-2
.
2-1
.
3-1
.
4-1
.
5-1
.
7-1
.
CLASS 1
LASER PRODUCT
GB
3139 785 33200
PHILIPS
DVP1013
DVP1013/37
