E Instruments KIRAY 100 User Manual

Distance from the target
Distance
254
12.7
Diameter
YES
Make sure that the target is larger than the size of the laser sighting.
KIRAY 100
Infrared thermometer
260 508 mm
13 mm
25.4
D:S=20:1
13 mm at 260 mm
NO
Infrared thermometer KIRAY 100 equipped with a dual
laser sighting is a key instrument to diagnose, inspect
and check any temperature, with the advantage of using
a "no-contact" technology. You can measure safely
surfaces temperatures of warm and dangerous objects
or objects with uneasy access. It's the perfect tool for
measurements in a house, a garage, a workshop, a
kitchen, etc...
Technical features
Spectral response..................8 - 14 µm
Optical.....................................D.S : 20:1 (13 mm at 260 mm)
Temperature range.................From -50 to +800°C
Accuracy*...............................From -50 à +20°C : ±2.5°C
Infrared repeatability..............From -50 to +20°C : ±1.3°C
Display resolution..................0.1°C
Response time.......................150 ms
Emissivity...............................Adjustable from 0.10 to 1.0 (pre-set at 0.95)
Over range indication............Display indication : « ---- »
Dual laser sighting.................Wave length : from 630 nm to 670 nm
Positive or negative
temperature indication................
Display....................................4 digits with LCD backlighted display
Auto-extinction.......................Automatic after 7 seconds of inactivity
High/low alarm.......................Flashing signal on display and beep signal
Power supply..........................Alkaline 9V battery
Autonomy...............................105 h (inactive laser and backlight)
Use temperature.....................From 0 to +10°C for a short period
Storage temperature..............From -10°C to +60°C
Relative humidity...................From 10 to 90%HR in operating mode
Dimensions.............................145 x 95 x 40 mm
Weight.....................................180 g (included battery)
From +20 to +300°C : ±1% of reading ±1°C
From +300°C to +800°C : ±1.5%
From -20 to +800°C : ±0.5% or ±0.5°C
Output < 1mW, Class 2 (II)
Automatic (no indication for a positive
temperature)
(-) sign for a negative temperature
with adjustable thresholds
20 h (active laser and backlight)
From +11 to + 50 °C for a long period
and > 80%RH in storage
