Summary of Contents for Lathem LTR-RBR
- Page 1 LTR-RBR REMOTE BELL RINGER Installation & User’s Guide...
- Page 2 THIS EQUIPMENT COMPLIES WITH FCC CLASS-B REQUIREMENTS PURSUANT SUBPART J OF PART-15 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 3 OPERATION, INSTALLATION AND MAINTENANCE MANUAL “REMOTE BELL RINGER” LATHEM TIME CORP Doc #USG0027A “LTR8-512” and “MasterLink” are Registered Trademarks of Lathem Time Corp., Atlanta, GA, USA ©2003 LATHEM TIME CORP...
- Page 4 Welcome to the LTR-RBR (Remote Bell Ringer) Lathem’s LTR8-512 Master Controller for Clocks and Bells is capable of storing up to eight (8) Schedules for Bells and Control Zones, each of which may contain up to sixty-four (64) multi-function ‘Events’. An ‘Event’...
- Page 5 select and activate one (1) of the eight (8) possible Bell Circuits or all Bell Circuits (those circuits not defined as Clock Control Circuits) in the Master Controller. The selection made will execute when the push button on the Remote Bell Ringer’s Panel is pressed, and those circuits will remain activated until the button is released.
- Page 6 Installing the LTR-RBR To install the Remote Bell Ringer, simply set the hidden Address Selector switch / jumpers to match the Master’s Programmed Address (default = Code 65) and attach the Communication Cable wire-pair (with proper polarity) and the low-voltage Power Pair to the Terminal Block, then secure the cover-plate to the electrical box with four 6-32 FH screws.
-
Page 8: Operational Description
Operational Description To use the Remote Bell Ringer, the Operator will first select, via the Rotary Switch, which of the Bell Circuits are to be made active. Selected Circuits that are not configured as Bell Circuits in the Master Controller will be ignored The ‘OFF’... - Page 9 Master Control/Remote Bell Ringer...
- Page 11 Lathem or from an authorized Lathem reseller. The conditions of this warranty and the extent of the responsibility of Lathem Time Corporation (“Lathem”) under this warranty are listed below.
- Page 12 No warranties are given with respect to products purchased other than from Lathem or an authorized Lathem reseller and any such products are purchased "as is, with all faults." In no event will Lathem be liable for any direct, indirect,...
- Page 13 Lathem Time 200 Selig Drive, SW, Atlanta, GA 30336 404-691-0405 www.lathem.com Copyright © 2003 Lathem Time Corporation. All rights reserved.
