Sharp LC-39LE650E Service Manual

Led lcd colour television
Hide thumbs Also See for LC-39LE650E:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
50mm
40mm
1st Edition
Wi-Fi & 3D Ready / DVB-T / T2 / C / S / S2 PAL
31.5mm
25mm
20mm
ELECTRICAL SPECIFICATIONS ........................................................................................ 2
IMPORTANT SERVICE SAFETY PRECAUTIONS ......................................................................... 3
OPERATION MANUAL ....................................................................................................................
DIMENSIONS .................................................................................................................... 22
REMOVING OF MAJOR PARTS ..................................................................................................... 23
SERVICE ADJUSTMENTS ............................................................................................................. 33
PUBLIC MODE .................................................................................................................................... 44
SOFTWARE UPGRADING ............................................................................................................. 47
MAJOR ICs INFORMATION ..................................................................................................... 48
BLOCK DIAGRAMS ..................................................................................................................... 63
SCHEMATIC DIAGRAMS ....................................................................................................... 66
PRINTED WIRING BOARDS ......................................................................................................... 114
REPLACEMENT PARTS LIST ....................................................................................................... 121
CABINET AND MECHANICAL PARTS ............................................................................................ 141
PACKING OF THE SET ....................................................................................................................... 145
SERVICE MANUAL
In the interests of user safety (required by safety
regulations in some countries) the set should be re-
stored to its original condition and only parts identical
to those specifi ed should be used.
CONTENTS
LED LCD
COLOUR TELEVISION
/ SECAM
B/G
B/G, D/K, L/L'
MODELS
LC-39LE650E/RU/V
LC-39LE651E/K/RU/V
LC-39LE652E/RU/V
LC-50LE650E/RU/V
LC-50LE651E/K/RU/V
LC-50LE652E/RU/V
1
LC-39/50LE650
LC-39/50LE651
LC-39/50LE652
S1stLC39LE650
Issued: 14
th
SYSTEM COLOUR TELEVISION
This document has been published to
be used for after sales service only.
The contents are subject to chage without notice.
June 2013
6
