- Page 1 Palomino BATTERY CHARGERS Installation and Operating Instructions One Technology Place Caledonia, New York 14423 The Power of Excellence FM1320 REV - B...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS INSTRUCTIONS IMPORTANTES CONCERNANT LA SECURITE *********************************************************************************************************** SAVE THESE INSTRUCTIONS. THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS; CONSERVER CES INSTRUCTIONS. CE MANUEL CONTIENT DES INSTRUCTIONS IMPORTANTES CONCERNANT LA SECURITE ET LE FONCTIONNEMENT; *********************************************************************************************************** WORKING IN THE VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS. BATTERIES GENERATE EXPLOSIVE GASSES DURING NORMAL BATTERY OPERATION.
- Page 3 OWNERS MANUAL INSTALLATION: READ AND FOLLOW ALL SAFETY INSTRUCTIONS ON THE FOLLOWING PAGE. All Palomino chargers are for indoor use only. Charging areas must be clean, dry and free from combustible materials, open flames. Charging areas must be properly ventilated and smoking should never be allowed in or near the charging area. The temperature of...
-
Page 4: Troubleshooting Guide
INPUT VOLTAGE CHANGEOVER: The Input Voltage CAN NOT be changed on the Palomino chargers. These units can only be operated at one input voltage, which was specified at time of order. - Page 5 1.7 volts per cell. 2) HIGH VOLTS/CELL: If this indicator is on, then the Palomino CONTROL measured the average volts/cell to be greater than 2.8 volts. a) Verify that the Battery connected to the Palomino charger has the correct number of cells.
-
Page 6: Cable Disconnection
3) CABLE DISCONNECTION: The CABLE DISCONNECTION indicator will be on whenever the battery to charger charging cable is disconnected while the battery is charging. Always make sure to manually shut-down (press the stop button) the charge before disconnecting the cables. 4) CHARGE TIME EXCEEDED: This indicates that the battery did not reach 80% of full charge within nine hours or that the battery did not charge from 80% charged to full charge within six hours. - Page 7 TABLE 1 Branch Circuit Input Branch Circuit Input Protection Model Number Voltage Protection Required Model Number Voltage Required 06B0510ALB 24B0475BHB 06B0600ALB 24B0600BHB 12B0510ALB 24B0750BHB 12B0600ALB 24B0875BHB 12B0750ALB 24B1050BHB 12B0875ALB 12B0540BJC 18B0600ALB 12B0600BJC 18B0750ALB 12B0750BJC 24B0475ALB 12B0875BJC 06B0510AMC 12B1050BJC 06B0600ALB 18B0540BJC 12B0510AMC 18B0600BJC 12B0600AMC...
