SPLIT-TYPE AIR CONDITIONERS
OUTDOOR UNIT
SERVICE MANUAL
Models
MUZ-HJ25VA
MUZ-HJ35VA
MUZ-HJ25VA
MUZ-HJ35VA
NOTE:
RoHS compliant products have <G> mark on the spec name plate.
-
E1
-
E1
CONTENTS
1. TECHNICAL CHANGES ··································· 3
2. PART NAMES AND FUNCTIONS ····················· 3
3. SPECIFICATION ················································ 4
4. NOISE CRITERIA CURVES ······························ 5
5. OUTLINES AND DIMENSIONS ························ 6
6. WIRING DIAGRAM ············································ 7
7. REFRIGERANT SYSTEM DIAGRAM ··············· 8
8. PERFORMANCE CURVES ······························· 9
9. ACTUATOR CONTROL ··································· 18
10. SERVICE FUNCTIONS ···································· 19
11. TROUBLESHOOTING ····································· 19
12. DISASSEMBLY INSTRUCTIONS ···················· 33
PARTS CATALOG (OBB648)
No. OBH648
HFC
utilized
R410A
Indoor unit service manual
MSZ-HJ•VA Series (OBH647)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mitsubishi Electric MUZ-HJ25VA-E1
Summary of Contents for Mitsubishi Electric MUZ-HJ25VA-E1
-
Page 1: Table Of Contents
SPLIT-TYPE AIR CONDITIONERS OUTDOOR UNIT No. OBH648 SERVICE MANUAL utilized R410A Models MUZ-HJ25VA MUZ-HJ35VA Indoor unit service manual MSZ-HJ•VA Series (OBH647) CONTENTS MUZ-HJ25VA MUZ-HJ35VA 1. TECHNICAL CHANGES ··································· 3 2. PART NAMES AND FUNCTIONS ····················· 3 3. SPECIFICATION ················································ 4 4. - Page 2 Use the specifi ed refrigerant only Never use any refrigerant other than that specified. Doing so may cause a burst, an explosion, or fire when the unit is being used, serviced, or disposed of. Correct refrigerant is specified in the manuals and on the spec labels provided with our products. We will not be held responsible for mechanical failure, system malfunction, unit breakdown or accidents caused by failure to follow the instructions.
-
