Regalo Home Accents 0310 Owner's Manual

Regalo Home Accents 0310 Owner's Manual

Extra wide walk thru gate
Hide thumbs Also See for Home Accents 0310:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
01/06/2014_EV
Home Accents
Extra Wide Walk Thru Gate
MODEL NO: 0310
Owner's Manual
READ ALL INSTRUCTIONS BEFORE ASSEMBLY
AND USE OF GATE.
KEEP INSTRUCTIONS FOR FUTURE USE.
www.regalo-baby.com
...........................................................................
Regalo International, LLC.
3200 Corporate Center Drive, Suite 100
Burnsville, MN 55306-9803, USA
Toll Free: 866-272-5274
Made in China

Advertisement

loading
Need help?

Need help?

Do you have a question about the Home Accents 0310 and is the answer not in the manual?

Questions and answers

Related Manuals for Regalo Home Accents 0310

Summary of Contents for Regalo Home Accents 0310

  • Page 1 MODEL NO: 0310 Owner’s Manual READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE OF GATE. KEEP INSTRUCTIONS FOR FUTURE USE. www.regalo-baby.com ................Regalo International, LLC. 3200 Corporate Center Drive, Suite 100 Burnsville, MN 55306-9803, USA Toll Free: 866-272-5274 Made in China...

  • Page 2: Assembly And Installation Instructions

    Never leave child unattended. Use only with the locking/latching mechanism securely engaged. Contact Regalo for questions and replacement parts. For questions about the use of your gate, call our customer care line 866-272-5274 Regalo International, LLC. 3200 Corporate Center Drive, Suite 100...
  • Page 3 Check to make sure you have all of the parts shown: Gate Frame 4 Wall Cups 4 Screws ( requires a Phillips/crosshead screwdriver 4 Threaded Spindle Rods...
  • Page 4 Extensions List NOTE Item NO. MAX Size 0310 29--44 inches NOTE: When installing any gate at its maximum width use Wall Mounting Cups to ensure stability and safety.
  • Page 5 Assembling and Installing Your Gate **Note: IMPORTANT!! You will notice a slight gap between the gate door latch and the frame. THIS IS NOT A DEFECT. Your gate is a pressure mounted gate and this gap will disappear once you tighten your gate in its opening. Step 1.
  • Page 6 Step 3. Position the gate so that it is level and centered within your doorway or opening. Rotate the adjustment wheels on the threaded spindle rods in the opposite direction at in Step 1, expanding the gap between the rubber foot and the adjustment wheel. Expand each of the 4 Threaded Spindle Rods until they make contact with the doorway or opening.
  • Page 7 Step 4. When you are satisfied with the general placement of your gate, fully tighten the Threaded Spindle Rods attached to the lower corners of the gate by further rotating the Adjustment Wheels. Continue by tightening the upper Threaded Spindle Rods. As you tighten the upper Threaded Spindle Rods, you will notice the gap between the Door Frame and the Easy Slide Latch begin to narrow.
  • Page 8 Positioning and Attaching the Wall Cups Your gate is a pressure mounted gate. Therefore, it is not necessary to use the screw attached Wall Cups in your door opening if you choose not to. However, IF YOU ARE USING THE GATE AT THE TOP OF STAIRS YOU MUST USE THE WALL CUPS. Using the Wall Cups will affix your gate more firmly in the doorway or opening.
  • Page 9 Step 3. With the gate fully removed, you can now use the circles you marked during Step 1 as guides for screwing in your 4 Wall Cups. Center each of the Wall Cups within the guide circles and use the provided self-tapping screws to fasten them in place via the hole through the center of each Wall Cup.
  • Page 10 Operating the Door Latch Step 1. Squeeze one or both of the Circular Buttons on the Easy Slide Latch while simultaneously pulling back on one or both of the Locking Slides. These two actions combined will disengage the lock and allow the gate to open freely. Circular Button Easy Slide Latch Locking Slide...
  • Page 11 finish and assembly, Regalo International LLC will replace or repair it at Regalo’s option. PROOF OF PURCHASE REQUIRED.
  • Page 12 Replacement Parts Available In the event of any damage or breakage, the following replacement parts are available for order by contacting Regalo Customer Service. Threaded Spindle Rods Easy Slide Latch with Adjustment Wheel with all Internal Components (#11016) (#11017) Wall Cups (#11015) 1”...
  • Page 13 Regalo International, LLC. 3200 Corporate Center Drive, Suite 100 Burnsville, MN 55306-9803, USA Toll Free: 866-272-5274 Made in China 01/06/2014_EV...
