Summary of Contents for DNF Controls ST300-SRP
- Page 1 12843 Foothill Blvd. Suite C Sylmar, California 91342 V: 818.898.3380 F: 818.898.3360 sales@dnfcontrols.com Model No. ST300-SRP and ST300-SRP-T DDRs With Simultaneous Record/Playback Capability SLOW MOTION CONTROLLER USER MANUAL V 1.41...
-
Page 2: Table Of Contents
REFERENCE . . . SETUP MENU FUNCTION TABLE SPECIFICATIONS RS422 SERIAL CONNECTOR POWER CONNECTOR AUX PORT RS422 SERIAL CONNECTOR GPI IN/OUT CONNECTOR KEY LAYOUT DNF CONTROLS LIMITED WARRANTY Manual Version:..………........1.41 091906 Document ID:..….….……..ST300-SRP_User_Manual.doc ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 3: Revision History
Added GOTO LIVE Section. Added Video Standard Selection and INPUT Video Delay Entry to SETUP MENU. 102605 Rev. 1.4 Update to current manual convention 091906 Rev. 1.4 1 Update to include Create New Clip function. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 4: Getting Started
Getting Started . . . SYSTEM DESCRIPTION The ST300-SRP Slow Motion Controller combines the power of the ST300 Slow Motion Controller with the power of DDRs that have simultaneous record/playback capability. In the ST300 Setup Menu, disable S-RP Mode to access standard ST300 Slow Motion functions. -
Page 5: Installation
VAC. Select REMOTE mode on the DDR’s front panel. Check the SETUP MENU prior to using the Slow Motion Controller to confirm proper Record mode, SLO-MO speed range, and other User settable modes. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... - Page 6 ST300-SRP & ST300-SRP-T, Slow Motion Controller Page...
-
Page 7: Operation
The VTR will not go into Record mode if “Record Inhibit” is enabled on the VTR or tape cassette. Check SETUP MENU prior to using the SLOW MOTION CONTROLLER to confirm proper Record mode and other User settable modes. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 8: Cue Points
When the VTR reaches the Cue Point time, the GOTO indicator will turn off. Press [PREROLL] to preroll to the Cue Point. The PREROLL indicator will turn on. When the VTR reaches the Cue Point time, the PREROLL indicator will turn off. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 9: Goto/Preroll To A Manually Entered Time
The Softkeys are located just below the display. Follow the line graphic from the bottom of the display to the Softkey. Press [ESC] to exit the MENU. The MENU indicator will turn off. Turn the Wheel for other setup options. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 10: Simultaneous Record/Playback Functions
The Record LED turns ON. Press [SHIFT] + [REC] on VTR 2 to start recording on the Record channel connected to VTR4 connector on the rear of the ST300. The Record LED turns ON. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 11: Stop Record
Press [EE] key to go to Live video on the corresponding Playback Channel. The EE LED turns on. f) GOTO LIVE Press [REC] key. The Player searches to the current Recorder time minus user-defined INPUT Video Delay (see SETUP MENU). The Player starts playing. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 12: Advanced Features
Connect the VTR4 connector on the back of the ST300 to one of the COM ports on the PC using a RS422 to RS232 adapter. Repeat steps a) thru g) of “To Transmit Cue Points to Another ST300,” Section 6.a.1). ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 13: Receive Cue List Function
The RECEIVE CUE LIST function allows you to receive a list of Cue Points from a PC or from another ST300. Transfer to a PC requires OpSuite 3.0 software, which runs on a Windows-based computer. Contact DNF Controls for more information. To Receive Cue Points From Another ST300... -
Page 14: Reference
Connect ST300 to DDR using Simultaneous Record/Playback Mode ON Connection Diagram. WIND MODE Press Softkey to select: {HOLD} (Fast wind is maintained only while key is pressed.) {LATCH} (Fast wind is initiated and maintained with momentary key press.) ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... - Page 15 The Preset Speed register is NOT updated when exiting SLOMO mode. It is only changed by [SHIFT] + [SLOMO] (PRESET SLOMO). TBAR Press Softkey {ON} to enable slomo to be engaged by moving the TBAR. AUTOENABLE ST300-SRP & ST300-SRP-T, Slow Motion Controller Page...
- Page 16 The default value is 5 seconds. TRANSMIT Transmits Cuelist to another ST300 or to a PC. CUELIST See section 6a. RECEIVE Receives Cuelist from another ST300 or a PC. CUELIST See section 6b. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page...
-
Page 17: Function Table
LAST GOOD timecode is within 6 frames of the last Record Out point VIDEO (memorized automatically upon exiting Record mode). Enable, disable, or clear the FREEZE point from SETUP MENU. See FREEZE ENABLE. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... - Page 18 For T-BAR ONLY – HOLD key to play video in reverse. RELEASE key to play forward. PLAY REWIND [RWD] Press and HOLD to rewind. Release key to stop. Set WIND Speed in MENU. SHUTTLE [SHUTTLE] Select SHUTTLE mode and enable the Wheel. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page...
- Page 19 (Generator Press [ENTER] to load Time Generator with 00:00:00:00. Preset) OR enter the time desired via the numeric keypad and press [ENTER] to load that time. OR press [ESC] to exit without saving. ST300-SRP & ST300-SRP-T, Slow Motion Controller Page...
-
Page 20: Specifications
Receive B Transmit B Transmit A Transmit Common Frame Ground Spare POWER CONNECTOR 9-Pin D-Type, Male (DB9M) Pin # +5v DC +5 VDC +5v DC Ground Ground Ground +12 VDC Ground –12 VDC ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 21: Aux Port Rs422 Serial Connector
REWIND tally out GPI 4 In REWIND GPI 5 Out FFWD tally out GPI 5 In FFWD GPI 6 Out SLOMO tally out GPI 6 In SLOMO GPI 7 Out GPI 7 In STILL Ground ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 22: 10. Key Layout
10. KEY LAYOUT ST300-SRP & ST300-SRP-T, Slow Motion Controller Page... -
Page 23: 11. Dnf Controls Limited Warranty
11. DNF CONTROLS LIMITED WARRANTY DNF Controls warrants its product to be free from defects in material and workmanship for a period of one (1) year from the date of sale to the original purchaser from DNF Controls. In order to enforce the rights under this warranty, the customer must first contact DNF’s Customer Support Department to afford the opportunity of identifying and fixing the problem without sending the unit in for repair.
