Hedman HF100 Operating & Service Manual

Paper folding machines hedman hf100
Hide thumbs

Advertisement

Table of Contents

Enlarged version
NOTICE
Proprietary Information - this material is not to be reproduced by
any means or disclosed in any way without prior written approval by
THE HEDMAN COMPANY.
Disclaimer - this material is subject to change without notice and
should not be construed as a commitment by THE HEDMAN
COMPANY. Neither express nor implied warranty is made regarding
the procedures herein, their merchantability, or fitness for any
specific application.
These procedures are provided solely on an "as-is" basis, and the
customer agrees to assume any costs arising from use or misuse of
the material, including all correction and damages consequential or
incidental.
HEDMAN
THE
COMPANY - ALL RIGHTS RESERVED.
©
2001 The Hedman Company
Printed in U.S.A.
Form No. 198557HF
HEDMAN
THE
COMPANY
189 Gordon St.
Elk Grove Village, IL 60007
800-872-2788
HEDMAN
The HEDMAN Company • 189 Gordon St. • Elk Grove Village, IL 60007 • 800-872-2788
HF100 FOLDER
OPERATING & SERVICE MANUAL
®
Form No. 198557HF

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HF100 and is the answer not in the manual?

Questions and answers

Related Manuals for Hedman HF100

Summary of Contents for Hedman HF100

  • Page 1 HEDMAN ® The HEDMAN Company • 189 Gordon St. • Elk Grove Village, IL 60007 • 800-872-2788 NOTICE Proprietary Information - this material is not to be reproduced by any means or disclosed in any way without prior written approval by THE HEDMAN COMPANY.

  • Page 2: Table Of Contents

    TROUBLESHOOTING TABLE OF CONTENTS 1. FOLD QUALITY A. Documents skew - crooked folds 1. As folder runs, adjust PAPER GUIDES slightly to correct the skew. Page 2. Re-position paper in HOPPER. Hold HOPPER LEVER open and load paper squarely and centered. Slowly release HOPPER LEVER. SPECIFICATIONS 3.
  • Page 3 392/EEC, based on its design and type. In case of alteration of the machine, not agreed to by the manufacturer, this declaration will lose its validity. Equipment Type: Paper Folding Machine Model Designation: HF100-IN, HF100-UK. Description: Rated Voltage - 15 VDC (Output of stand-alone power supply) Rated Input Power - 1.4A...

  • Page 4: Specifications

    COVERS & KNOBS SPECIFICATIONS POWER: 15V, D.C.(14.8)/1.4 amp/external; wall mountable; power pack with internal circuit breaker UL, CSA & FCC approved 120/220/240 V.A.C., 50/60 HZ International approvals TUV, GS, CE WEIGHT: 20 lbs. (9.0 kg) / 26 lbs. shipping (11.8 kg) SPEED: up to 200 sheets per minute PAPER SIZE: 8.5"...

  • Page 5: Components & Controls

    COVERS & KNOBS COMPONENTS & CONTROLS FEED PAPER GUIDES TABLE FEED ROLLER PAPER WIDTH SCALE GUIDE FINGERS RECEIVING RACK OPERATING MANUAL HOPPER HOPPER LEVER POWER SWITCH GUIDE ROLLERS POWER CORD WARNING SEPARATOR The outlet socket is the ADJUSTMENT main power. It must be HOLE located near the equipment and easily...

  • Page 6: Automatic Folding

    AUTOMATIC FOLDING DRIVE ASSEMBLIES (Stack of sheets up to 5/8" (16 mm) high) Hold HOPPER LEVER Center paper on open (right) and load FEED TABLE and neatly stacked and release HOPPER squared paper into LEVER. HOPPER. Slide PAPER GUIDES snugly against stack.

  • Page 7: Manual Folding

    DRIVE ASSEMBLIES MANUAL FOLDING (1 to 3 sheets stapled or loose) Close FEED TABLE onto top of folder. Slide PAPER GUIDES as far apart as possible. Insert sheet(s) squarely into SLOT and let them rest on your finger as shown. Do not hold sheet(s).

  • Page 8: Removing Cartridge

    FOLD PLATES MAINTENANCE Removing CARTRIDGE INNER CARTRIDGE COVER PRESSURE LEVER RUBBER ROLLER WARNING: Turn POWER SWITCH off and unplug POWER CORD before removing CARTRIDGE. To Remove CARTRIDGE: Open TOP and INNER COVERS. Pull back RED PRESSURE LEVERS. Remove CARTRIDGE by sliding it up and out of the folder in the slot. When installing CARTRIDGE, the RUBBER ROLLER must be held at a 45°...

  • Page 9: Cleaning Feed Roller

    SERVICE MAINTENANCE Replacing FEED ROLLER Cleaning FEED ROLLER If the FEED ROLLER is visibly worn or is chunking apart, it must be replaced. When changing the SEPARATOR, replace the FEED ROLLER as well. To change the FEED ROLLER: FEED ROLLER Turn POWER SWITCH off and unplug POWER CORD.

  • Page 10: Adjusting Separator

    MAINTENANCE SERVICE Adjusting SEPARATOR Replacing SEPARATOR The SEPARATOR must be set to feed one sheet of paper at a time. The SEPARATOR (located below the FEED ROLLER) is a very important part of the automatic feeding system. Keeping the SEPARATOR adjusted as it wears (see Page WARNING: Turn POWER SWITCH off and unplug POWER CORD before making adjustment.
