HydroTherm 42 Installation Instructions

Kickspace heater types hw & hf recessed and surface mount wall kits recessed "hw" / surface mount "hf" wall kit

HWFII-4

KICKSPACE HEATER

INSTALLATION INSTRUCTIONS • TYPES HW & HF

RECESSED AND SURFACE MOUNT WALL KITS

RECESSED "HW" / SURFACE MOUNT "HF" WALL KIT

To be used in conjunction with Kickspace Heater • Type HK

Kickspace Heater Installation Instructions

For use with HK42/HK84/HK120 Kickspace Heaters

ATTENTION: READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL, OPERATE, OR

SERVICE THE HYDROTHERM KICKSPACE HEATERS! RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

INSPECT THE SHIPMENT IMMEDIATELY WHEN RECEIVED TO DETERMINE IF ANY DAMAGE HAS OCCURRED

DURING SHIPMENT.

PRIOR TO INSTALL, CHECK FOR ANY VISIBLE DAMAGE.

GENERAL DESCRIPTION

The Kickspace wall kits have been designed to accommodate a Hydrotherm Kickspace Model HK42, HK84, or HK120

Kickspace heater to deliver a comfortable stream of warmed air through the wall by a unit mounted in the wall, or on the

surface of the wall. Kits consist of front grille panels, back panel, and necessary mounting hardware. The Kickspace heater

is sold separately.

The recessed (HW kits) cabinet for the HW42 will ﬁ t between 16" center studs. The HW84/HW120 will require a small

amount of framing to suit the mounting.

Installation instructions should be read thoroughly IN CONJUNCTION WITH INSTALLATION INSTRUCTIONS AND

WIRING DIAGRAM SUPPLIED WITH KICKSPACE HEATER UNITS, prior to starting installation.

WARNING: DISCONNECT POWER BEFORE SERVICING UNIT,

POTENTIAL ELECTRICAL SHOCK HAZARD!

260 NORTH ELM STREET, WESTFIELD, MASSACHUSETTS 01085

www.hydrotherm.com

2/12

Table of Contents

Do you have a question about the 42 and is the answer not in the manual?

Page 1 GENERAL DESCRIPTION The Kickspace wall kits have been designed to accommodate a Hydrotherm Kickspace Model HK42, HK84, or HK120 Kickspace heater to deliver a comfortable stream of warmed air through the wall by a unit mounted in the wall, or on the surface of the wall.
Page 2 INSTALLATION OF KICKSPACE WALL MODELS - TYPE "HW" AND TYPE "HF" Figures D and F show exploded views of the wall models "HW" & "HF" Kickspace's. Figure E shows the "HW" type mounted in a wall with an air outlet at the top of the unit. Figure G shows the "HF" type mounted. The louvers of the front panel will direct the air ﬂ...
Page 3 24" (610) 18" (460) F42 22" (561) F84 CAT-55525A 22" (561) F120 4 3/8 (111) FIGURE F FIGURE G (Model 42 Shown) Model Description Part No. Figure F Parts List BMFR02165-001 Front Panel Assembly BMFR02165-002 BMFR02161-001 Back Panel Assembly BMFR02161-002...
Page 4: Limited Warranty
ANY PARTS THEREOF FOUND TO BE DEFECTIVE. THIS LIMITED WARRANTY GIVES THE ORIGINAL OWNER OF THE PRODUCT SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY BY EACH JURISDICTION. 260 NORTH ELM STREET, WESTFIELD, MASSACHUSETTS 01085 www.hydrotherm.com...
