THOR TH-SSM-CAT Instruction Manual

Thor small switch instruction manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Welcome to the THOR Family!
Thank you for purchasing a THOR Small Switch! We appreciate your business, and we think
you'll appreciate the many ways that your THOR system will save you money, time, and
effort.
The THOR Small Switch offers three fundamental uses:
As a Multiplex Repeater: the DVI signals (+optional audio) coming from a signal
•
source are equalized and distributed on up to 7 equivalent outputs. A control is not
necessary. Distributed display systems can be realized (Digital Signage).
As an 8-port Crosspoint Switch: each port can be switched optionally as an input or
•
output. You can, for example, switch and distribute the signals from 3 signal
sources on up to 5 displays (allowing simultaneous presentations on several
displays). Alternatively, signals coming from 7 signal sources can be switched in
turn to a single display. The changeover can be triggered remotely using the serial
interface (RS232) and/or by a push-button at the device.
As a 7-port KVM Switch: up to 7 Single-head ports (a "Single-head" extender
•
system supports 1x monitor, 1x keyboard, 1x mouse) or up to 3 Dual-head ports (a
Dual-head extender system supports 2x monitor, 1x keyboard, 1x mouse). The
changeover can be triggered remotely using the serial interface (RS232) and/or by a
push-button at the device.
Cascade multiple devices in two stages for all applications to give up to 49/1 connections.
The THOR Small Switch has the advantage that it can be positioned up to 140m away from
both your signal source and display device. This becomes possible by using the proven
THOR Extender technology for the transmission of DVI- Monitor and USB-Keyboard and
Mouse signals over CATx- cable.
The operation of a THOR Small Switch always requires at least one Local Unit and up to
seven Remote Units from the THOR Extenders range.
Rev. : 02/09/2012
DISCONTINUED
THOR-SSM
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TH-SSM-CAT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for THOR TH-SSM-CAT

Summary of Contents for THOR TH-SSM-CAT

  • Page 1 Cascade multiple devices in two stages for all applications to give up to 49/1 connections. The THOR Small Switch has the advantage that it can be positioned up to 140m away from both your signal source and display device. This becomes possible by using the proven THOR Extender technology for the transmission of DVI- Monitor and USB-Keyboard and Mouse signals over CATx- cable.
  • Page 2 (DVI+USB keyboard mouse + optional audio) available. The transmission of the signals requires connecting CATx cable. This manual will tell you all about your new THOR Small Switch, including how to install, operate and troubleshoot it. For an introduction to the Converter, see Chapter 2.
  • Page 3 THOR-SSM TH-E-KIT-1-SL-2-MM-A232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,MM,Fiber,Anal.Audio,RS232 TH-E-KIT-1-SL-2-MM-DA THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,MM,Fiber,Dig.Audio TH-E-KIT-1-SL-2-MM-V THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,MM,Fiber,VGA/IN THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber TH-E-KIT-1-SL-2-SM THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber,Anal.Audio,RS232 TH-E-KIT-1-SL-2-SM-A232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber,Dig.Audio TH-E-KIT-1-SL-2-SM-DA THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber,VGA/IN TH-E-KIT-1-SL-2-SM-V THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,CATx TH-E-KIT-1-SL-24-CAT THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,CATx,Anal.RS232 TH-E-KIT-1-SL-24-CAT- A232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,CATx,Dig.Audio TH-E-KIT-1-SL-24-CAT-DA THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,MM,Fiber TH-E-KIT-1-SL-24-MM TH-E-KIT-1-SL-24-MM-A232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,MM,Fiber,Anal.Audio,RS232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,MM,Fiber,Dig.Audio TH-E-KIT-1-SL-24-MM-DA THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,SM,Fiber TH-E-KIT-1-SL-24-SM TH-E-KIT-1-SL-24-SM-A232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,SM,Fiber,Anal.Audio,RS232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,4xUSB2,SM,Fiber,Dig.Audio TH-E-KIT-1-SL-24-SM-DA TH-E-KIT-2-SL-4-CAT THOR,E,EXTENDER,KIT,2Mon,SL,4xHID,CATx TH-E-KIT-2-SL-4-CAT-A232 THOR,E,EXTENDER,KIT,2Mon,SL,4xHID,CATx,Anal.Audio,RS232 TH-E-KIT-2-SL-4-CAT-DA THOR,E,EXTENDER,KIT,2Mon,SL,4xHID,CATx,Dig.Audio...
  • Page 4 THOR-SSM TH-E-KIT-4-SL-8-MM-A232 THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,MM,Fiber,Anal.Audio,RS232 TH-E-KIT-4-SL-8-MM-DA THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,MM,Fiber,Dig.Audio TH-E-KIT-4-SL-8-SM THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,SM,Fiber THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,SM,Fiber,Anal.Audio,RS232 TH-E-KIT-4-SL-8-SM-A232 THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,SM,Fiber,Dig.Audio TH-E-KIT-4-SL-8-SM-DA THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,CATx TH-E-KIT-4-SL-24-CAT THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,CATx,Anal.Audio,RS232 TH-E-KIT-4-SL-24-CAT- A232 THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,CATx,Dig.Audio TH-E-KIT-4-SL-24-CAT-DA THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,MM,Fiber TH-E-KIT-4-SL-24-MM TH-E-KIT-4-SL-24-MM-A232 THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,MM,Fiber,Anal.Audio,RS232 TH-E-KIT-4-SL-24-MM-DA THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,MM,Fiber,Dig.Audio THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,SM,Fiber TH-E-KIT-4-SL-24-SM TH-E-KIT-4-SL-24-SM-A232 THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,SM,Fiber,Anal.Audio,RS232 THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,SM,Fiber,Dig.Audio TH-E-KIT-4-SL-24-SM-DA Rev. : 02/09/2012...

  • Page 5: Copyrights And Trademarks

    THOR-SSM Copyrights and Trademarks ©2009. All rights reserved. This information may not be reproduced in any manner without the prior written consent of the manufacturer. Information in this document is subject to change without notice and the manufacturer shall not be liable for any direct, indirect, special, incidental or consequential damages in connection with the use of this material.

  • Page 6: Ec Declaration Of Conformity

    THOR-SSM EC DECLARATION OF CONFORMITY The products listed in this manual in the form as delivered are in conformity with the provisions of the following European Directives: 2004/108/EG Council Directive on the approximation of the laws of the Member States...
  • Page 7 Try not to route a CATx- link cable alongside power cables. • The THOR Small Switch Unit, Remote Unit, Local Unit and any power supplies can get • warm. Do not locate them in an enclosed space without any airflow.
  • Page 8 THOR-SSM Rev. : 02/09/2012...

  • Page 9: Table Of Contents

    CONTENTS Contents 1. Quick Setup 2. Overview 2.1 Introduction 2.2 Glossary 16 2.3 Example of a THOR Small Switch System 2.4 Features 18 2.5 Product Range 2.6 Compatibility Interface Compatibility 2.7 How to Use This Guide Connection & Compatibility DDC Information...

  • Page 10: Operating Modes

    5.3 THOR Media/ KVM Extender 6. Service Setup 6.1 THOR Small Switch for CATx Operating Mode Selection Connection of THOR Control External Switching Device (Accessories) 6.2 THOR Media/ KVM Extender 6.3 Setup at the Local Unit DDC / color depth...

  • Page 11: Restore Factory Defaults

    CONTENTS Operation a) By push-button: b) By serial interface Control commands Examples: c) By the attached keyboard User commands Call of the command mode (till firmware dated Nov-20, 2009) Change of the initialization-string (till Nov-20, 2009) Call of the command mode (since Nov-20, 2009) Change of the initialization-string (since Nov-20, 2009) Instructions within the command mode Examples:...
  • Page 12 Glossary: Commands, switching functions Appendix F: Calling Technical Support Appendix G: List of supported USB devices Appendix H: Specifications THOR Media/KVM Local/ Remote Unit Power Supply Interface (depending on type of device) Audio Interface Serial Interface Maximum Length of Interconnection Cable...
  • Page 13 CONTENTS Power Supply THOR Small Switch Unit Serial Interface All THOR Devices Power Supply CATx- Interfaces Appendix J: Connection Cable Serial cable to connect the THOR Small Switch to CPU Rev. : 02/09/2012...

  • Page 14: Quick Setup

    THOR-SSM 1. Quick Setup This section briefly describes how to install your THOR Small Switch system. Unless you are an experienced user, we recommend that you follow the full procedures described in the rest of this manual. Installation of the system...

  • Page 15: Overview

    (master/slave). The THOR Small Switch and the Local/ Remote Units are attached by CATx cables. The operation of a THOR Small Switch always requires (at least) one Local Unit of a THOR Extender and up to seven Remote Units of THOR Extenders.

  • Page 16: Glossary

    (www.ddwg.org) R, G, B, CLOCK in a data stream with up to 3x1,6 Gbit/sec. Signals are TMDS Level. The desktop power supply connected to the THOR Small Switch or to the Local/ Remote Unit. Human Interface Devices are units, which are used for human access to the CPU: keyboard and mouse, touch-screen, light pen, fingerprint sensor, graphic tablets etc.

  • Page 17: Example Of A Thor Small Switch System

    THOR-SSM 2.3 Example of a THOR Small Switch System CPU with DVI graphic card and audio output Local monitor THOR Extender (Local Unit) THOR Small Switch THOR Extender- (Remote Units) Up to 7 remote monitors and audio outputs Example application for a THOR Small Switch System (Multiplex-Repeater or Crosspoint-Switch) Rev.

  • Page 18: Features

    ONLY; use with other HID devices (Human Interface Device) such as touch screens, graphics tablets, barcode readers or similar may be successful – but there is no guarantee for this! The THOR KVM is NOT suitable for use with other USB- devices such as scanners, web- cams, data sticks etc.

  • Page 19: Product Range

    TH-SSM-MM THOR Small Switch for MultiMode TH-SSM-SM THOR Small Switch for SingleMode TH-SU THOR Switching Unit TH-SSM THOR Small Switch for fiber (w/o GBIC) SFP-MM MultiMode GBIC for TH-SSM SFP-SM SingleMode GBIC for TH-SSM Media-Extender Kits - CATx TH-E-KIT-1-SL-4-CAT THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,CATx TH-E-KIT-1-SL-4-CAT- THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,CATx,Anal.Audio,R...
  • Page 20 THOR-SSM TH-E-KIT-2-SL-24-CAT- THOR,E,EXTENDER,KIT,2Mon,SL,2xHID,4xUSB2,CATx,Anal. A232 Audio,RS232 TH-E-KIT-2-SL-24-CAT- THOR,E,EXTENDER,KIT,2Mon,SL,2xHID,4xUSB2,CATx,Dig. Audio TH-E-KIT-4-SL-8-CAT THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,CATx TH-E-KIT-4-SL-8-CAT- THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,CATx,Anal.Audio,R A232 S232 TH-E-KIT-4-SL-8-CAT-DA THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,CATx,Dig.Audio TH-E-KIT-4-SL-24-CAT THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,CATx TH-E-KIT-4-SL-24-CAT- THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,CATx,Anal. A232 Audio,RS232 TH-E-KIT-4-SL-24-CAT- THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,CATx,Dig. Audio Media-Extender Kits – Fiber MutiMode TH-E-KIT-1-SL-4-MM THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,MM,Fiber TH-E-KIT-1-SL-4-MM- THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,MM,Fiber,Anal.Audi A232 o,RS232 TH-E-KIT-1-SL-4-MM-DA THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,MM,Fiber,Dig.Audio TH-E-KIT-1-SL-2-MM THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,MM,Fiber TH-E-KIT-1-SL-2-MM- THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,MM,Fiber,Anal.Audi...
  • Page 21 THOR-SSM Dig.Audio TH-E-KIT-4-SL-8-MM THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,MM,Fiber TH-E-KIT-4-SL-8-MM- THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,MM,Fiber,Anal.Audi A232 o,RS232 TH-E-KIT-4-SL-8-MM-DA THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,MM,Fiber,Dig.Audio TH-E-KIT-4-SL-24-MM THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,MM,Fiber TH-E-KIT-4-SL-24-MM- THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,MM,Fiber, A232 Anal.Audio,RS232 TH-E-KIT-4-SL-24-MM-DA THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,MM,Fiber, Dig.Audio Media-Extender Kits – Fiber SingleMode TH-E-KIT-1-SL-4-SM THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,SM,Fiber TH-E-KIT-1-SL-4-SM-A232 THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,SM,Fiber,Anal.Audi o,RS232 TH-E-KIT-1-SL-4-SM-DA THOR,E,EXTENDER,KIT,1Mon,SL,4xHID,SM,Fiber,Dig.Audio TH-E-KIT-1-SL-2-SM THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber TH-E-KIT-1-SL-2-SM-A232 THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber,Anal.Audi o,RS232 TH-E-KIT-1-SL-2-SM-DA THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber,Dig.Audio TH-E-KIT-1-SL-2-SM-V THOR,E,EXTENDER,KIT,1Mon,SL,2xHID,SM,Fiber,VGA/IN...
  • Page 22 THOR-SSM TH-E-KIT-4-SL-8-SM-A232 THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,SM,Fiber,Anal.Audi o,RS232 TH-E-KIT-4-SL-8-SM-DA THOR,E,EXTENDER,KIT,4Mon,SL,8xHID,SM,Fiber,Dig.Audio TH-E-KIT-4-SL-24-SM THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,SM,Fiber TH-E-KIT-4-SL-24-SM- THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,SM,Fiber,A A232 nal.Audio,RS232 TH-E-KIT-4-SL-24-SM-DA THOR,E,EXTENDER,KIT,4Mon,SL,2xHID,4xUSB2,SM,Fiber,D ig.Audio Rev. : 02/09/2012...

  • Page 23: Compatibility

    You can extend a USB hub but this does not raise the number of supported devices. Fiber / CATx devices: It is possible, to equip a THOR fiber device with fiber and CATx • GBIC’s. So it is possible to switch both topologies within a single device.

  • Page 24: How To Use This Guide

    THOR Small Switch for CATx: includes the device and power supply. • THOR KVM/ Media Local Unit: includes the device, power supply and all the cables • required to connect the THOR KVM/ Media Local Unit to your CPU/ Signal source.

  • Page 25: Installation

    This will allow you to identify and solve any cabling problems and experiment with the THOR System more conveniently. 3.1 Package Contents You should receive the following items in your THOR Small Switch for CATx package: THOR Small Switch •...
  • Page 26 • 2 audio cables 1.8m • Additionally with THOR KVM Dual-Head and Media devices with Audio: 1x Serial link/ audio ZIP-type cable (1.8m) with one side DSUB9pin female connector + • 2x 3.5mm stereo plugs – other side miniDIN8pin male connector...
  • Page 27 THOR-SSM The following parts should be in your THOR KVM/ Media Remote Unit package: THOR KVM/ Media Remote Unit • 1x 5V DC universal power supply for the THOR KVM/ Media Remote Unit • 1x power cord • If anything is missing, please contact Technical Support (see Appendix F: Calling Technical Support Rev.

  • Page 28: Interconnection Cable Requirements

    THOR-SSM 3.2 Cable Connection Requirements To connect the THOR Media Local Unit to your CPU/signal source you will need (Please ensure that the connection is tension-free!): DVI: Connect the supplied DVI- cable 1.8m (DVI-I male to DVI-I male) to your CPU (KVM- Switch, DVI- signal source, etc.).
  • Page 29 Power Supply: Connect the supplied 5V/DC power supplies to the Plug terminal on the rear of THOR Local Unit, THOR Small Switch or THOR Remote Unit. Rev. : 02/09/2012...

  • Page 30: System Setup

    Connect the CPU/signal source to the Local Unit using the supplied cable(s). Connect the devices with INTERCONNECT cables (fiber or CATx) Take the THOR Small Switch out of the packaging and also the sheet with the product stickers. According to your application, peel the corresponding sticker from the sheet and stick it...
  • Page 31 Information for the DIP switch set-up can be found under Operating Mode Selection 10. Attach the connection cables (CATx- cable) between the THOR Small Switch and Local Unit and between the THOR Small Switch and Remote Unit. Use the provided crossover CATx- cable or insert the provided crossover cable with the provided CATx- coupler before/after your CATx- wiring.
  • Page 32 THOR-SSM 12. Connect the 5V power supplies to the units. Only use the power supply originally supplied with this equipment or a manufacturer-approved replacement. 13. For a dual access system, connect the monitor for the local console to the appropriate port on the Local Unit.

  • Page 33: Installation Instructions

    Please ensure that the THOR Small Switch has sufficient ventilation space by ensuring the following distances between the unit and other devices and/or mounting parts: In 19" rack cabinets: the area to the right and left from the THOR Small Switch must be kept free!

  • Page 34: Device Views

    Remote Units A Media Local Unit A Push-button, no function in this operating mode Connect to the THOR Media Connect to the THOR Remote Units B Media Local Unit B THOR Small Switch – as 2x 2-to-3 Multiplex-Repeater Rev. : 02/09/2012...

  • Page 35: Configuration 'Multiplex-Repeater' - 4 Sources On 4 Displays

    Media Local Units supply this operating mode Connect to the THOR KVM/ Media Remote Units THOR Small Switch – as 4x 1-to-4 Multiplex- Repeater Configuration ‘Crosspoint-Switch’ 1 Input / 7 Outputs Connect to the THOR Push-button; for the Connect to 5V power...

  • Page 36: Configuration 'Crosspoint-Switch' 2 Inputs / 6 Outputs

    Local Units supply programmed configurations Connect to the THOR Media Remote Units THOR Small Switch – as Crosspoint-Switch 2x6 Configuration ‘Crosspoint-Switch’ 3 Inputs / 5 Outputs Connect to the THOR Media Push-button; for the Connect to 5V power Local Units...

  • Page 37: Configuration 'Crosspoint-Switch' 4 Inputs / 4 Outputs

    Local Units supply configurations Connect to the THOR Media Remote Units THOR Small Switch – as Crosspoint-Switch 4x4 Configuration ‘Crosspoint-Switch’ 5 Inputs / 3 Outputs Connect to the THOR Media Pushbutton; for the sequential Connect to 5V power Local Units...

  • Page 38: Configuration 'Crosspoint-Switch' 6 Inputs / 2 Outputs

    Connect to the THOR Media Remote Units THOR Small Switch – as Crosspoint-Switch 6x2 Configuration ‘Crosspoint-Switch’ 7 Inputs / 1 Output Connect to the THOR Media Push-button; for the Connect to 5V power sequential selection of pre-...

  • Page 39: Configuration 'Single-Head Kvm-Switch

    Connect to the THOR KVM Connect to the THOR KVM Remote Unit (Console) Local Units (CPU) THOR Small Switch – as Single-head KVM-Switch Configuration ‘Dual-head KVM-Switch’ Connect to the THOR KVM Connect to the THOR KVM Local Units (Console) –...
  • Page 40 THOR-SSM Operating Mode Serial Interface (DIP switch) (RS232) THOR Small Switch rear view Rev. : 02/09/2012...

  • Page 41: Thor Media Extender

    Connect to local DVI- To CPU: DVI monitor THOR Media Local Unit Connect to remote DVI- monitor THOR Media Remote Unit To CPU: Connect to local DVI- To CPU: monitor Audio/serial THOR Media (+ Audio) Local Unit Rev. : 02/09/2012...
  • Page 42 Connect to 5V power and data signals – connect to Local/ supply Remote Unit with CATx- cable THOR Media Local/ Remote Unit – rear view INTERCONNECT – carries video Connect to 5V power and data signals – connect to Local/...

  • Page 43: Thor Kvm Extender

    THOR-SSM 4.3 THOR KVM Extender To CPU: Connect to local Connect to CPU: DVI- graphic card DVI- monitor THOR KVM Local Unit Remote DVI- monitor port– Remote keyboard/ Connect to remote console mouse port monitor THOR KVM Remote Unit Rev. : 02/09/2012...
  • Page 44 – connect to Local/ Connect to 5V power Remote Unit with CATx- cable supply THOR KVM Local/ Remote Unit – rear view INTERCONNECT – carries video Connect to 5V power and data signals – connect to Local/...
  • Page 45 THOR-SSM To CPU: DVI Audio In To CPU: Serial Connect to local Connect to CPU: DVI- monitor THOR KVM Local Unit with audio Audio Out Serial Out Remote keyboard/ Remote DVI- monitor port– mouse port Connect to remote console monitor THOR KVM Remote Unit with Audio Rev.
  • Page 46 THOR-SSM Connect to CPU: secondary USB To CPU: DVI Connect to local Connect to CPU: DVI- monitor THOR KVM Local Unit with 4x USB-HID Remote secondary USB-HID port Program Remote keyboard/ Remote DVI- monitor port– mouse port Connect to remote console...
  • Page 47 THOR-SSM Connect to local Connect to CPU: DVI- monitor THOR KVM Local Unit with DVI-I Input (DVI-D + VGA) Rev. : 02/09/2012...
  • Page 48 – Connect to Local/ Connect to 5V power Remote Unit with CATx- cable supply THOR KVM Local/ Remote Unit with audio – rear view INTERCONNECT – carries video and data signals – Connect to Local/ Connect to 5V power...
  • Page 49 Connect to CPU: Local DVI- monitor Connect to CPU: DVI- graphic card port- Connect to local console monitor THOR KVM Dual-head Local Unit remote DVI- monitor port- Connect to remote console 2 monitor remote DVI- Remote keyboard/ monitor port– connect...
  • Page 50 Connect to CPU: Local DVI- monitor Connect to CPU: DVI- graphic card port- Connect to local console monitor THOR KVM Dual-Head Local Unit with 4x USB-HID remote DVI- monitor Remote secondary port- Connect to remote USB-HID ports console 2 monitor...
  • Page 51 THOR KVM-Dual-head Local Unit with audio remote DVI- monitor port- Connect to remote Audio Out Serial Out console 2 monitor remote DVI- monitor port– Connect to remote Remote keyboard/ console 1 monitor mouse port THOR KVM Dual-head Remote Unit with audio Rev. : 02/09/2012...
  • Page 52 Connect to CPU: To CPU: DVI secondary USB Connect to local Connect to CPU: DVI- monitor THOR KVM Local Unit with 2x USB-HID + 4x USB-2.0 4x Remote secondary USB-2.0 port Remote keyboard/ Remote DVI- monitor port– mouse port Connect to remote console monitor THOR KVM Remote Unit with 2x USB-HID + 4x USB-2.0...
  • Page 53 Connect to 5V power and data signals – Connect to Local/ supply Remote Unit with CATx- cable THOR KVM Dual-head, Local/ Remote Unit, with optional audio – rear view INTERCONNECT – carries 2 video – Connect to Local/ Remote Unit with fiber- cable INTERCONNECT –...

  • Page 54: Diagnostic

    5. Diagnostic 5.1 THOR Small Switch for CATx Each THOR Small Switch is fitted with two indicator LEDs: Power and Link Status: The Power LED is next to the Power socket. The Link Status LEDs are at the upper CATx- connectors in the left and right upper corner.
  • Page 55 THOR-SSM 5.2 THOR Small Switch for CATx Each THOR Small Switch is fitted with two indicator LEDs: Power and Link Status: The Power LED is next to the Power socket. The Link Status LED is located between the lower and upper fiber connector. The LED shows the status for the lower interconnection, the ____LED for the upper interconnection.

  • Page 56: Thor Media/ Kvm Extender

    THOR-SSM 5.3 THOR Media/ KVM Extender Each THOR Extender is fitted with four indicator LEDs: Power, Video OK, Data Error, and Link Status: The Power LEDs are next to the power socket. The location of the LEDs is shown below:...

  • Page 57: Service Setup

    Normally, it is only necessary to make adjustments during installation. In order to make these adjustments, you do not have to open the THOR Small Switch. All settings can be made from the outside using the Operating Mode Selector (DIP switch).

  • Page 58: Operating Mode Selection

    THOR-SSM Operating Mode Selection Operating Mode Selector Switch setting Switch setting Switch setting Down Extraneous Operating Mode Operating Mode Selector Multiplex- Repeater: The signal(s) coming from the Local Unit is (are) equalized (and distributed) and extended over further 140m. An incoming DVI...
  • Page 59 (up to 9 with cascaded application) can be operated from one console. Standard operating mode Reset the THOR Small Switch to default settings (Factory Reset): switch power off set the DIP- switch switch power on, the device is resetting...

  • Page 60: Connection Of Thor Control External Switching Device (Accessories)

    CPU or the number of the last processed macro. THOR Control External Switching Device with related Infrared Remote Control This device is powered from the THOR. To provide power, an internal jumper must be set accordingly.
  • Page 61 To set the jumper for powering the THOR Control External Switching Device, you need to open the THOR Small Switch Device. To open the unit, unscrew the Philips screws at the bottom of the device. Carefully remove the lower and upper shells of the case.

  • Page 62: Thor Media/ Kvm Extender

    THOR-SSM 6.2 THOR Media/ KVM Extender For standard applications, you shouldn't need to make any adjustments to your THOR Small Switch Media/KVM Extender. However, in certain circumstances, you may need to open the Local Unit and/or the Remote Unit. To open one of the units, unscrew the Philips-type screws at both sides at the bottom of the device.

  • Page 63: Setup At The Local Unit

    THOR-SSM 6.3 Setup at the Local Unit After unscrewing and opening the upper shell, please place the device with the CATx- connectors to the right and the monitor connectors to the left. The main PCB then will look like this: JP1, JP2, JP3 Use the diagram to locate jumpers.

  • Page 64: Loading The Ddc Information From The Remote Monitor Into The Internal Ddc Table

    THOR-SSM Loading the DDC Information from the Remote Monitor into the internal DDC Table To load the DDC Information from the Remote Monitor into the internal DDC Table, please proceed with the following steps: Power up the CPU, the Local Unit, the Remote (cables to the CPU connected) and the •...

  • Page 65: Setup At The Remote Unit

    THOR-SSM 6.4 Setup at the Remote Unit After unscrewing and opening the upper shell, please place the device with the CATx- connectors to the right and the monitor connector to the left. The main PCB then will look like this: JP1, JP2, JP3 Use the diagram to locate jumpers.

  • Page 66: Operating Modes

    – depending on the configuration – on up to 7 equivalent outputs. The signals of the CPU (signal source) are transmitted to a Local Unit which is attached to the THOR Small Switch by CATx cables. The transmission between the THOR Small Switch and up to 7 Remote Units is also done by CATx cables.

  • Page 67: Configuration 'Multiplex-Repeater' – 2 Sources, Each Up To 3 Displays

    THOR-SSM Configuration ‘Multiplex-Repeater’ – 2 Sources, each up to 3 displays Connect to 5V power Outputs to the THOR Media Input to the THOR Media supply Remote Units A Local Unit A Pushbutton, no function in this operating mode Outputs to the THOR Media...

  • Page 68: Example Applications

    THOR-SSM Example Applications: A video/audio source is switched over the THOR Small Switch to 4 different screens/loudspeakers. Additionally a control monitor can be attached at the Local Unit. Rev. : 02/09/2012...
  • Page 69 THOR-SSM Three cascaded THOR Small Switches each with a local second screen and 13 screens for presentations. Rev. : 02/09/2012...

  • Page 70: Indicator Leds

    THOR-SSM Indicator LEDs The following indicator LEDs are used in the ‘Multiplex-Repeater’ operating mode: Diagnostic LED Diagnostic LED Link Status Link Status Upper connector Lower connector Meaning of the diagnostic LEDs: Appearance Diagnostics Power LED Device not ready (Red LED)

  • Page 71: Control Commands

    THOR-SSM Setup There are no other setups available in ‘Multiplex-Repeater’ operating mode. Operation In operating mode ‘Multiplex-Repeater’ the following operations are possible: By serial interface Serial Interface (RS232) You can find the allocation of the serial interface under “Serial Interface” on page 145. A standard cable (RJ45 / DB9) to the CPU is included in delivery.

  • Page 72: Crosspoint- Switch

    THOR-SSM 7.2 Crosspoint- Switch In “Crosspoint- Switch" operating mode, each port of the THOR Small Switches can be used either as an input (to a Local Unit) or as an output (to a Remote Unit). Thus any combinations between 1x input/7x output and 7x input/1x output are possible. The device offers no channel monitoring in this mode so you must ensure the correct connection of the CATx- cables.

  • Page 73: Inputs / 6 Outputs

    Remote Units The signal of a Local Unit is switched on up to 7 outputs and transmitted over CATx- cables on up to 7 Remote Units. Optionally, a further THOR Small Switch can be inserted for a second switching stage.

  • Page 74: Inputs / 4 Outputs

    Remote Units The signals of 3 Local Units are switched on up to 5 outputs and transferred over CATx- cables to 5 Remote Units. Optionally, an additional THOR Small Switch can be inserted for a second switching stage. Configuration ‘Crosspoint-Switch’...

  • Page 75: Inputs / 2 Outputs

    The signals of 5 Local Units can be switched on up to 3 outputs (also on several) and be transferred over CATx- cables on up to 3 Remote Units. Optionally, an additional THOR Small Switch can be inserted for a second switching stage.
  • Page 76 Remote Unit The signals of 7 Local Units can be switched to one output and be transferred over CATx- cables to one Remote Unit. Optionally, an additional THOR Small Switch can be inserted for a second switching stage. Rev. : 02/09/2012...

  • Page 77: Example Application

    THOR-SSM Example Application: Three video sources are switched over the THOR Small Switch on four different screens. Rev. : 02/09/2012...

  • Page 78: Setup

    THOR-SSM Setup The following configurations are possible in the ‘Crosspoint-Switch’ operating mode: Operating mode after Reset/Power ON After a reset the respective DEFAULT- Mode is selected: 1x7: Input I1 is switched to Output O1 2x6: I1 to O1 and I2 to O2...

  • Page 79: Indicator Leds

    THOR-SSM Indicator LEDs The following indicator LEDs are used in the ‘Crosspoint-Switch’ operating mode: Diagnostic LED Diagnostic LED Link Status Link Status Upper connector Lower connector Meaning of the diagnostic LEDs: Appearance Diagnostics Power LED Device not ready (Red LED)

  • Page 80: Operation

    THOR-SSM Operation The following operations are possible in the ‘Crosspoint-Switch’ operating mode: a) By push button: Push-Button With the first key press, the macro display is switched on. The LED with the number of the active selected macro flashes green. With each key press, the display will switch to the next LED.
  • Page 81 THOR-SSM For communication please set up the format of the serial data communication to: 115.2K, 8, 1, NO (115.2 KBAUD, 8 Data bit, 1 Stop bit, NO parity) Control commands In the ‘Crosspoint- Switch’ operating mode the following control commands are allowed:...
  • Page 82 THOR-SSM c) By the attached keyboard Since Firmware Revision dated Nov-20, 2009 you can also switch the Console 1 (which is connected to Remote Unit 1) using the attached keyboard. Rev. : 02/09/2012...

  • Page 83: Single-Head Kvm- Switch

    The switching between the CPUs can be carried out at the attached keyboard, push-button at the device or over the serial interface. Cascading of the THOR KVM- Switch in two stages allows up to 49 CPUs to be addressed. In addition to the DVI- signals and USB for keyboard/mouse, bi-directional stereo-audio + serial (RS232/V24) data can be transferred by appropriate Local/ Remote Units.

  • Page 84: Example Application

    THOR-SSM Example Application: Four CPUs are switched over the THOR Small Switch to one console. Rev. : 02/09/2012...

  • Page 85: Setup

    Master/Slave function The device is Master (default status: it is either the exclusive device in the system, or if THOR KVM Switches are cascaded, it is on the highest level (directly after the console). The device is Slave: if THOR KVM Switches are cascaded, it is on second level (directly after the Local Units).
  • Page 86 THOR-SSM Indicator LEDs These are the indicator LEDs in the ‘Single-head- KVM- Switch’ operating mode: Diagnostic LED Diagnostic LED Link Status Link Status Upper connector Lower connector Meaning of the diagnostic LEDs: Appearance Diagnostics Device not ready Power LED (Red LED)

  • Page 87: Operation

    THOR-SSM Operation The following operations are possible in the operating mode ‘Single-head KVM- Switch’: a) By push-button: Push-button The device switches to the next channel with each key press. The changeover will only be executed if the push-button is not operated for longer than 2 seconds. With each key press, the display will switch to the next channel as indicated by a rapidly blinking LED.

  • Page 88: Control Commands

    THOR-SSM Control commands In Single-head KVM- Switch operating mode, the following control commands are allowed: STX, 0x40, 0x80, ETX Acknowledgement of the system info • STX, 0x45, ETX Reset on factory settings • STX, 0x54, ETX Reset the Crosspoint- Switch •...

  • Page 89: C) By The Attached Keyboard

    THOR-SSM c) By the attached keyboard By executing a ‘hot-key-sequence', the system is shifted into a command mode. Now CPUs can be selected from the attached keyboard. Access to a switch in the second level (slave) is also possible. To show that the command mode is active, all three status LEDs on the keyboard flash rapidly.

  • Page 90: Call Of The Command Mode (Till Firmware Dated Nov-20, 2009)

    THOR-SSM Call of the command mode (since firmware dated Nov-20, 2009) <CTRL> + <SHIFT> + <I> • Enter the command mode(default-setting) <ESC> • Exit the command mode Change of the initialization-string (since Nov-20, 2009) <CTRL> + <SHIFT> + <C>, <x>, <RETURN>...

  • Page 91: Instructions Within The Command Mode

    THOR-SSM Instructions within the command mode Selection of the control level <M> or <m> • The following commands are executed by the ‘Master’ (default after call of the command mode) <S> or <s> • The following commands are executed by the actively connected ‘Slave’...

  • Page 92: Examples

    THOR-SSM < > (arrow key down) • Switch the console (bypassing unoccupied ports) to the previous port. After reaching the first port, the last port will be selected <BACKSPACE> • Switches back to the last viewed channel. Allows you to switch rapidly between two channels.

  • Page 93: Dual-Head Kvm- Switch

    The switching between the CPUs can be carried out from the attached keyboard, push-button at the device, or over the serial interface. You can cascade THOR KVM- Switches in two stages for all applications, allowing up to 9 dual-head CPUs to be addressed.

  • Page 94: Example Application

    THOR-SSM Example Application: Three CPUs with dual-head graphic cards and local consoles switched over the THOR Small Switch to one console. Rev. : 02/09/2012...

  • Page 95: Setup

    Master/Slave function The device is master (default status): it is either the exclusive device in the system, or if THOR KVM Switches are cascaded, it is on highest level (directly after the console). The device is slave: if THOR KVM Switches are cascaded, it is on second level (directly after the Local Units).

  • Page 96: Indicator Leds

    THOR-SSM Indicator LEDs In the ‘Dual-head- KVM- Switch’ operating mode, the following indicator LEDs are used: Diagnostic LED Diagnostic LED Link Status Link Status Upper connector Lower connector Meaning of the diagnostic LEDs: Appearance Diagnostics Power LED Device not ready...

  • Page 97: Operation

    THOR-SSM Operation The following operations are possible in the ‘Dual-head KVM- Switch’ operating mode: a) By push-button: Push-Button The device switches to the next channel with each key press. The changeover will only be executed if the push-button is not operated for longer than 2 seconds. With each key press, the display will switch to the next channel indicated by a rapidly blinking LED.

  • Page 98: Control Commands

    THOR-SSM Control commands In the Dual-head KVM- Switch operating mode, the following control commands are allowed: STX, 0x40, 0x80, ETX Acknowledgement of the system info • STX, 0x45, ETX Reset on factory settings • STX, 0x54, ETX Reset the KVM- Switch •...

  • Page 99: C) By The Attached Keyboard

    THOR-SSM c) By the attached keyboard By executing a ‘hot-key-sequence' the system is shifted into a command mode from which CPUs can be selected using the attached keyboard. Access to a switch in a second level (slave) is also possible. To show that the command mode is active, all three status LED's on the keyboard flash rapidly.

  • Page 100: Call Of The Command Mode (Till Firmware Dated Nov-20, 2009)

    THOR-SSM Call of the command mode (till firmware dated Nov-20, 2009) <CTRL> + <SHIFT> + <I> • Enter the command mode(default-setting) <ESC> • Exit the command mode Change of the initialization-string (till Nov-20, 2009) <CTRL> + <SHIFT> + <C>, <x>, <RETURN>...

  • Page 101: Instructions Within The Command Mode

    THOR-SSM Instructions within the command mode Selection of the control level <M> or <m> • The following commands are executed by the ‘master’ (default after call of the command mode) <S> or <s> • The following commands are executed by the actively connected ‘slave’...

  • Page 102: Examples

    THOR-SSM < > (arrow key down) • Switch the console (bypassing unoccupied ports) to the previous port. After reaching the first port, the last port will be selected. <BACKSPACE> • Switch back to the last viewed channel. Use to switch rapidly between two channels.

  • Page 103: System Info

    THOR-SSM 7.5 System info System information can be read out over the serial interface in all four operating modes. The location of the serial interface is shown below: Serial Interface (RS232) You can find the allocation of the serial interface under “Serial Interface” on page 145. A standard cable (RJ45 / DB9) to the CPU is included in delivery.

  • Page 104: Restore Factory Defaults

    Use DIP- switch 6 to reset the device. In the “Crosspoint Switch” operating mode, all macros in memory are reset. Standard operating mode Reset the THOR Small Switch to default settings (Factory Reset): switch power off set the DIP switch...

  • Page 105: Troubleshooting

    THOR-SSM 8. Troubleshooting Monitor There isn’t a picture. Check the power supply connection at the Local and Remote Unit. Is the Power LED at the Local and Remote Unit illuminated? If not, the internal power supply may be damaged or there may be an internal error.

  • Page 106: Usb- Keyboard/ Mouse

    THOR-SSM USB- Keyboard/ Mouse Your USB-keyboard/USB-mouse does not work Although we tried to design the devices as transparent as possible, we can’t ensure that all devices are supported. Please check Appendix G: List of supported USB devices on page 135.

  • Page 107: Usb-Hid-Devices

    If you have any compatibility problems, please contact our technical support. Other USB-devices Your USB- device does not work You have connected a non-HID device. The extender system supports HID devices only. All other devices are incompatible with the THOR Small Switch system. Rev. : 02/09/2012...

  • Page 108: Appendix A: Example Applications

    THOR-SSM Appendix A: Example Applications This section illustrates some specific applications using the THOR: THOR as Multiplex- Repeater with audio option Rev. : 02/09/2012...
  • Page 109 APPENDIX A: EXAMPLE APPLICATIONS Three cascaded THOR as Multiplex- Repeater and a total of 13 screens for presentations Rev. : 02/09/2012...
  • Page 110 THOR-SSM THOR as Crosspoint- Switch (here: 3x Input/ 4x Output) Rev. : 02/09/2012...
  • Page 111 APPENDIX A: EXAMPLE APPLICATIONS THOR as Single-head KVM- Switch (to 7:1) optional with a local console and/ or serial/ audio option Rev. : 02/09/2012...
  • Page 112 THOR-SSM THOR as Dual-head KVM- Switch (to 3:1) with a local console Rev. : 02/09/2012...

  • Page 113: Appendix B: Rack Mount Options

    APPENDIX B: RACK MOUNT OPTIONS Appendix B: Rack Mount Options Mounting Instruction Rack Mount Kit TH-ACCS-130 Using the rack mount kit TH-ACCS-130, up to 4 devices of the device size 103x143x29mm (single-head devices) can be mounted into a 19” server rack. The rack mount kit requires 1U rack space.
  • Page 114 THOR-SSM The rack mount kit TH-ACCS-130 allows mounting of up to 4 devices: In the left-hand position, you can mount a rack mountable p.s.u. type TH-ACCS-132 instead of a regular device. This p.s.u. is capable of powering up to three devices.
  • Page 115 APPENDIX B: RACK MOUNT OPTIONS Mounting Instruction Rack Mount Kit TH-ACCS-131 Using the rack mount kit TH-ACCS-131, up to 4 devices of the device size 103x143x42mm (dual-head devices) can be mounted into a 19“- server rack. The rack mount kit requires 1U rack space.
  • Page 116 The rack mount kit TH-ACCS-131 allows mounting of up to 4 devices: In the left hand position you can mount a rack mountable p.s.u. type TH-ACCS-132 instead of a regular device. This p.s.u. is capable of powering up to three devices. Mounting instructions THOR Small Switch Rev. : 02/09/2012...

  • Page 117: Appendix C: Devices With Serial/Audio Option

    APPENDIX C: DEVICES WITH SERIAL/AUDIO OPTION Appendix C: Devices with serial/audio option The audio/serial option consists of daughter boards which allow bi-directional stereo audio and a full-duplex serial data link to be sent across the regular interconnection cable in addition to keyboard, mouse and VGA/DVI video. • To set up your video, keyboard, mouse, follow the instructions in the user guide.

  • Page 118: Serial Interface - Handling Multiple Serial Devices

    THOR-SSM Serial Interface – Handling Multiple Serial Devices The serial interface transmits/receives six signals (3 signals in each direction). Normally, four of these signals are used for hardware handshaking (in addition to Tx & Rx). However, because each handshaking line can support signals up to 19, 200 Baud, it is possible to configure the serial interface to handle up to three simple 2-wire (Tx/Rx only) serial links.

  • Page 119: Appendix D: Setup Dvi-I Local Units

    APPENDIX D: SETUP DVI-I LOCAL UNITS Appendix D: Setup DVI-I Local Units OSD (On Screen Display) The following table summarizes the remote control button sequences used in system configuration and video tuning on the local unit. Infrared Remote Control (IR-RC) Exit OSD Select next position / increase parameter...
  • Page 120 THOR-SSM If you are using a VGA input stored in the internal table, no adjustment should be required. In other cases, you may need to optimize the output using the VGA to DVI Converter’s on- screen display (OSD). Version information...

  • Page 121: Opening The Osd

    APPENDIX D: SETUP DVI-I LOCAL UNITS Opening the OSD You can access the OSD by using the equipped Infrared Remote Control (IR-RC). Using the IR-RC For direct brightness adjust For direct contrast adjust more brightness more contrast less brightness less contrast Reset to factory defaults Reset to factory defaults (from flash)

  • Page 122: Using The Osd

    THOR-SSM Using the OSD The OSD is an icon-based utility. The top line of symbols shows the main menu categories: Input Select Specify whether the input is RGB, RGBS, RGBHV (VGA), EGA, CGA, Scale Mode Select the screen resolution of the attached display and select one of four scaling modes.
  • Page 123 APPENDIX D: SETUP DVI-I LOCAL UNITS In many cases, after you have chosen a new setting, the OSD displays the following confirmation message (or similar): 10. Highlight the Yes button and press the Enter key to confirm your choice. Alternatively, highlight the No button and press the Enter key to discard the new setting and restore the previous value.

  • Page 124: Input Select

    THOR-SSM Input Select Choose the type of the connected graphic source Select VGA source Select DVI source Return to main menu Input Select menu Brightness/Contrast Use this menu to adjust the brightness and contrast of the video image or to adjust the black level of a display.

  • Page 125: Scaling

    APPENDIX D: SETUP DVI-I LOCAL UNITS Scaling Use the Output Scaling submenu to specify the best match between screen size and user requirements. Neither transparent conversion nor conversion with scaling alters the refresh rate! No scaling: picture displayed in original size, output refresh rate = input refresh rate Choice of 3 output resolutions for scaling (output refresh rate = input refresh rate)

  • Page 126: Select Colors And Color Temperatures

    THOR-SSM Select Colors and Color Temperatures Use the Colors menu to adjust the color balance of the video image. The menu provides a number of options including automatic calibration, manual adjustment in RGB or CMY color space, hue and saturation adjustment and the setup of flesh/skin tones.

  • Page 127: Image

    APPENDIX D: SETUP DVI-I LOCAL UNITS Image Use the Image menu to adjust the vertical and horizontal screen position, picture size and to set the pixel clock and phase. Doing some tunings on SYNC problems. Automatic detection of the number of pixels per line and the best phase (best point for A/D conversion within each pixel).

  • Page 128: Osd

    THOR-SSM Use the OSD submenu to define the position and size of the OSD window. To view this menu, select the Tools icon from the main menu and then select the OSD icon. Manually adjust the horizontal position of the OSD window...

  • Page 129: Ddc Configuration

    APPENDIX D: SETUP DVI-I LOCAL UNITS DDC Configuration Use the DDC Configuration menu to select which DDC information shall be transmitted to the graphic card. The default signals of the monitor attached are transmitted. Under some circumstances, it might be necessary to send a modified table to the graphics card.
  • Page 130 THOR-SSM 16. Select the first command icon: Automatic detection of number of pixels per line and the best phase. 17. Assess the desktop test pattern. If the vertical stripes are sharp and without jitter or smearing, the adjustment has been successful. Go to step 9.

  • Page 131: Appendix E: Protocol For Command Mode

    APPENDIX E: PROTOCOL FOR COMMAND MODE Appendix E: Protocol for command mode For the control of the THOR Small Switch device following parameters are used: For communication please set up the format of the serial data communication to: 115.2K, 8, 1, NO (115.2 KBAUD, 8 Data bit, 1 Stop bit, NO parity)

  • Page 132: Sequence Of Data Communication

    THOR-SSM Sequence of data communication THOR Small Switch Control-CPU Sending a command Acquiring command Processing the command, Blocking further commands a) Errors occurred <NAK> b) No errors <ACK> c) Optional : reply-command with data a) repeat command b) next command...

  • Page 133: Switching Functions

    APPENDIX E: PROTOCOL FOR COMMAND MODE Switching functions Glossary: INPUT = Input = to a Local Unit =CPU OUTPUT = Output = to a Remote Unit (= Workstation = KVM = Console) The INPUT- numbers are valid (depends on operating mode) in the range of 1..7 The OUTPUT- numbers are valid (depends on operating mode) in the range of 1..7 The INPUT- and OUTPUT- numbers are to encrypt in 7bit-data Commands, switching functions...

  • Page 134: Appendix F: Calling Technical Support

    THOR-SSM Appendix F: Calling Technical Support If you determine that your THOR Small Switch is malfunctioning, do not attempt to alter or repair it. It contains no user-serviceable parts. Please contact the technical support. Before you do, make a record of the history of the problem. We will be able to provide more...

  • Page 135: Appendix G: List Of Supported Usb Devices

    Appendix G: List of supported USB devices Although the USB connection’s implementation allows all keyboards and mice, we cannot guarantee that all available keyboards/mice are compatible with the THOR Small Switch system. The implementation is constructed for “HID” devices. HID is a device class enabling inputs to a CPU.

  • Page 136: Appendix H: Specifications

    THOR-SSM Appendix H: Specifications THOR Media/KVM Local/ Remote Unit Power Supply Voltage AC: 90-240VAC-0.5A-47-63Hz DC: 5VDC-2000 mA Power required Local Unit: max. 5V/750mA Remote Unit: max. 5V/750mA Interface (depending on type of device) DVI up to 1920x1200@60Hz Video source/Monitor USB (depending on model)

  • Page 137: Serial Interface

    APPENDIX H: SPECIFICATIONS Serial Interface Serial Speed Up to a maximum of 19, 200 Baud Serial Data Format Format Independent Flow Control Single-head Devices RTS, CTS, DTR, DSR are sent across link (Hardware Handshake) Dual-head Devices NO flow control (XON/XOFF only– Software Handshake) Maximum Length of Interconnection Cable 140m (400ft)

  • Page 138: Size And Shipping Weight

    THOR-SSM Size and Shipping Weight 103 x 143 x 29mm (4”x5.6”x1.1”) (2 devices) THOR Media or THOR KVM Single-head Weight Local/ Remote: 0,6kg (1.3lb) each Shipping box 210x140x165mm (8.3”x5.5”x6.5”) Weight: 1,6 kg (3.5lb) THOR KVM Dual-head or 103 x 143 x 42mm (4”x5.6”x1.1”) (2 devices) THOR Media w/ Audio/serial Weight Local/ Remote: 0,6kg (1.3lb) each...

  • Page 139: Bthor Small Switch Unit

    APPENDIX H: SPECIFICATIONS THOR Small Switch Unit Power Supply AC: 90-240VAC-0.5A-47-63Hz Voltage DC: 5VDC-2000 mA 5V/2000mA Power required Interface 1000 Mbit High-speed transmission. RJ45 Wiring acc. EIA/TIA 568B Gigabit Ethernet LC (fiber) 1000 Mbit High-speed transmission. Gigabit Ethernet RJ45 – Serial (switching 115.2 KBAUD, 8 bit data, 1 Stop, NO parity...

  • Page 140: Size And Shipping Weight

    THOR-SSM Size and Shipping Weight THOR Small Switch 103 x 143 x 42mm (4”x5.6”x1.1”) Weight: 0,6kg (1.3lb) Shipping box 260x210x150mm (10.2”x8.3”x5.9”) Weight: 2.0 kg (4.3lb) Environmental Operating Temperature 41 to 113°F (5 to 45 °C) -13 to 140°F (-25 to 60 °C)

  • Page 141: Appendix I: Connectors

    APPENDIX I: CONNECTORS Appendix I: Connectors THOR Media Local/ Remote Unit DVI-I connector 8 C1 C2 C3 C4 Signal Signal Signal T.M.D.S data 2- T.M.D.S data 1- T.M.D.S data 0- T.M.D.S data 2+ T.M.D.S data 1+ T.M.D.S data 0+ T.M.D.S data 2 GND T.M.D.S data 1 GND...
  • Page 142 THOR-SSM Keyboard/ Mouse connector, USB type B (Connector Local Unit) Signal VCC (+5V) Data - White Data + Green Black Keyboard/ Mouse connector, USB type A (Connector Remote Unit) Signal VCC (+5V) Data - White Data + Green Black Rev. : 02/09/2012...

  • Page 143: Serial Interface

    APPENDIX I: CONNECTORS Serial Interface (audio-/ serial option) Connector (Remote Unit) Connector (Local Unit) Signal Signal n.c. n.c. Rev. : 02/09/2012...

  • Page 144: Power Supply

    THOR-SSM Audio/serial connector Audio/RS232 at Dual head Local Unit AUDIO GND RS232 GND AUDIO OUT RIGHT CHANEL AUDIO OUT LEFT CHANEL RS232 RxD AUDIO IN RIGHT CHANEL AUDIO IN LEFT CHANEL RS232 TxD Power Supply Signal Inner Outer Rev. : 02/09/2012...

  • Page 145: Bthor Small Switch Unit

    APPENDIX I: CONNECTORS THOR Small Switch Unit Serial Interface (switch socket) DCE +5V (Out) TxD (Out) n.c. RxD (In) DSR (In) n.c. n.c. Rev. : 02/09/2012...

  • Page 146: C All Thor Devices

    THOR-SSM All THOR Devices Power Supply Signal Inner Outer CATx- Interfaces Wiring acc. EIA/TIA 568A (1000BaseT) Rev. : 02/09/2012...

  • Page 147: Appendix J: Connection Cable

    APPENDIX J: CONNECTION CABLE Appendix J: Connection Cable Serial cable to connect the THOR Small Switch to CPU Signal Signal n.c. n.c. n.c. n.c. n.c. Rev. : 02/09/2012...
  • Page 148 NOTES...

This manual is also suitable for:

Th-ssm-mmTh-ssm-smTh-ssmTh-su

Table of Contents
