Summary of Contents for Jeasun SmartCam
- Page 1 User Manual Please read the user manual clearly for avoiding any wrong opeartion, current manual is not the newest and not complete, please contact us if any query. ~ 1 ~...
-
Page 2: Table Of Contents
Catalog Main Features ............................3 Install & Use ............................4 Camera Body Instruction ........................4 Remote Controller（Optional） ......................5 Install the battery..........................6 Close the battery cover ........................6 Install the Mount ..........................7 Install the Waterproof case ........................ 8 Install the Memory card ........................ -
Page 3: Main Features
Main Features 480 x 240，1.5” TFT LCD Screen Display 14MP HD CMOS Image Sensor 150° Super Wide angle under 720P; 118° under 1080P Full HD 1080P H.264 Video compression to MP4 format Waterproof, shockproof, support 50M depth diving ... -
Page 4: Install & Use
Install & Use Camera Body Instruction 1. Speaker 9. Power / Picture Shot 2. REC & Remote Indicator 10. Power charge indicator 3. USB Port 11. REC / Power Indicator 4. TF card slot 12. 1.5” TFT LCD 5. HDMI Port 13. -
Page 5: Remote Controller（Optional
Remote Controller（Optional） REC button Power button Picture Shot ① Press and hold the button for 3 seconds to Power on the remote controller ( or Power off) , the green indicator will turn on if powered on. ② Single press the button to power on the camera, the green indicator on remote will flash if camera was powered up successfully, single press the POWER button again to turn off the camera. -
Page 6: Install The Battery
Install the battery Please install the battery correctly according to pictures below: Open the face battery cover Place the battery ( Character side up ) Close the battery cover ~ 6 ~... -
Page 7: Install The Mount
Install the Mount Pull the both arms towards to outside like below, place the camera into it. ~ 7 ~... -
Page 8: Install The Waterproof Case
Install the Waterproof case Close the back door Note: Power on the camera first and then place into the waterproof case, or use the remote to power on the camera. Single press REC button to stop/start video record. ~ 8 ~... -
Page 9: Install The Memory Card
Install the Memory card a. Please install the memory card correctly as picture below: b. Camera does not built in storage, support 1~32GB SDHC TF card. c. Available storage volume could be seen on the screen. No memory card icon displayed on the screen if valid TF card detected. -
Page 10: Power Charge
Power charge Put the battery into the camera, use the offered USB cable connect with 3rd party 5V ① charger or PC to do the power charge. The red LED indicator of charger will turn on if power connected, means in normal charging. ②... - Page 11 Battery fully charging time and usage time Fully charging time Standby time Recording time Approximately 3.5 Approximately 2 Hours Approximately 110 minutes Hours Battery Icon Full power 75% power 35% power Low power Note: a ,Please do not keep the battery in the camera if long time aside. b ,Please do not use up the power completely.
-
Page 12: Record & Capture
Record & Capture ① Press Power button to turn on the camera, press REC button to start video record, when the red icon displayed on the left corner of screen, that means the camera is doing normally record. ② Camera could start video record immediately if Wi-Fi turned OFF, but if Wi-Fi turned ON, camera will only available to start video record after Wi-Fi boot up completely, more details please check the Wi-Fi setting page. -
Page 13: Media Playback
Media Playback Press MENU button to enter the main menu, use < & > button to select the video folder like below: Press REC button to enter the folder, the video files display like below: Use < & > to select the video, press REC button to confirm, press REC button again to play the video. - Page 14 Picture playback Press MENU button to enter the main menu, use < & > button to select the picture folder like below. Press REC button to enter the folder, the picture files display like below: Use < & > to select the picture, press REC button to confirm, press REC button again to play the picture.
-
Page 15: Delete Files
Delete Files Under playback or browse mode, press and hold the MENU button for 2 seconds, the delete option menu will appear. Use < & > button to select suitable option, press REC button to confirm. Yes：Confirm to delete Cancel：Drop current operation Press REC button to confirm the operation. -
Page 16: Connect With Tv
Connect with TV A，USB&RCA cable connect with TV Insert the USB side to camera, insert the RCA head to TV ( Yellow-video; White-Audio), like below: B，HDMI cable connect with TV Insert the Micro-HDMI head to camera, insert the standard HDMI head to TV, like picture below: Note: The video output resolution is 1080P when play the recorded video clip, the real-time output resolution is 480i. -
Page 17: Connect With Pc
Connect with PC Camera connect with computer by USB cable, could browse the files in camera or charge the power. Power ON the camera after connect it with the computer by USB cable, the screen will display connecting graphic like below: Please choose the suitable option according to need. -
Page 18: System Icons
System Icons Booting Picture Icons 1080P/30 Video size and FPS REC icon 28000M Available storage Picture taking mode Recorded time Burst 00：33：24 2010/09/21 Date TF Card Time Battery 16：18 Wi-Fi OFF Wi-Fi ON ~ 18 ~... -
Page 19: Main Menu
Main Menu Icons Video folder Picture folder REC setting System Setting ~ 19 ~... -
Page 20: System Setting
System Setting Fast Setting Press & Hold the POWER button 2 seconds to turn on the camera, press MENU to enter the main menu, use < & > button to select “System Setting” and press REC button to confirm & enter. 1，Language Setting Press REC button to enter language setting, use <... -
Page 21: Date & Time
Date & Time Use < & > button to select and press REC button to enter. Grey background means changeable, use < & > button to change numbers, press REC button to confirm and turn to next option. Press MENU to save and quit after finish the setting. ~ 21 ~... - Page 22 Frequency Auto：Auto system 50Hz：Suitable for country & area that got power frequency at 50Hz 60Hz：Suitable for country & area that got power frequency at 60Hz Auto Power OFF OFF： Turn OFF this feature 5 Minutes：Camera will power OFF automatically after 5 minutes if without any operation 10 Minutes：Camera will power OFF automatically after 10 minutes if without any operation.
-
Page 23: Video System
Video System Use < & > button to select, press REC button to enter. Use < & > button to select suitable system. Press REC button to confirm choice, and the camera will reboot and back to this setting menu automatically. -
Page 24: Wi-Fi
Use < & > to select ON, press REC button to save, camera will reboot automatically. Pair the mobile phone with camera by Wi-Fi，turn on the Wi-Fi. Android phone: Setting-WLAN-Search Smartcam-connect，Password：00000000 Apple phone: Setting-Wi-Fi-Search Smartcam-connect，Password: 00000000 After connected successfully, then quit this and open the APP that install in the tablet or mobile phone. -
Page 25: Download & Install The App
We will find the Smartcam APP like below on the cellphone if successfully installed. Connect the Cellphone with APP Turn on the Wi-Fi on the camera and the Cellphone like image below, and then find the “Smartcam” hotspot in the WLAN list of cellphone, choose to connect it, default passward: 00000000 ( Eight “... -
Page 26: Screenshot Of App Works
Screenshot of APP works Real Time View Replay video on the camera Replay image on the camera Change camera settings 01 Change camera settings 02 Browse the media files on camera ~ 26 ~... -
Page 27: Rec Mode
REC Mode: Press MENU to enter system menu, press REC button to confirm and enter video setting. 1. REC Mode Press REC button to enter REC mode, use < & > button to select, press REC button to confirm and save the setting. Normal REC：Press REC button on camera to start &... - Page 28 2. Record Split Use < & > button to select, press REC button to confirm & enter, select “ record split” button to save and quit. Note: ： ： 5Min Means 5 minutes per footage ; 30Min Means 30 minutes per footage. Camera will stop video record while card full.
-
Page 29: Other Features
Other Features REC Content Video & Audio： Normal video with sound Video: If a mute video needed Dual Streams OFF：System will not create thumbnail video file, only the original video read while browse via APP, the picture would be delay because the original video need big bandwidth. ON：... -
Page 30: Specifications
Specifications Built in Memory 32MB Memory Expand Support 1G-32G SDHC Micro-SD Size 1.5 inch Resolution 480x240 （AMBARELLA）A5L30 Chipset （CHIPSIP）DDR3 CT49248DD486C1 Sensor Size 1/2.3” 14MP Aperture F2.8 Lens Angle 150° Construction 6G+1MG Basic Spec Video output HDMI/USB Built in Interface Audio output HDMI/USB Speaker 8Ω... - Page 31 Optional REC content Video / Audio Picture Size 14MP/10MP/8MP Picture mode Single shot, burst , self-timer Capture Burst 3 / 5 / 10 pieces , OFF Self-timer 3 / 5 / 10 seconds, OFF Video Loop playback Playback Picture Thumbnail, next, previous Frequency 433.92MHz Distance...
- Page 32 Please login www.jeasun.net for more product information. ~ 32 ~...
