Summary of Contents for mikroElektronika BassBoy
- Page 1 assBoy Manual Monophonic digit al MIDI controlled bass synthesizer CREATED BY: Aleksandar Krsti @ ć POWERED BY:...
- Page 2 BassBoy technical support : andigo.office@gmail.com BassBoy BassBoy is a monophonic digital MIDI controlled bass synthesizer. Device receives all information via MIDI input ( MIDI IN connector). Sampling frequency is 31.25KHz which generates audio range up to 15.625Khz. Although it's based on 8-bit processor, the signal processing inside the unit is 16-bit.
-
Page 3: Midi Control
BassBoy technical support : andigo.office@gmail.com SEQ MODE with CHANNEL SELECTION LIVE MODE with CHANNEL SELECTION MIDI CH1 MIDI CH9 MIDI CH1 MIDI CH9 MIDI CH2 MIDI CH10 MIDI CH2 MIDI CH10 MIDI CH3 MIDI CH11 MIDI CH3 MIDI CH11 MIDI CH4... - Page 4 BassBoy technical support : andigo.office@gmail.com LIVE MODE is a mode in which the duration of the note is defined by the GATE. VELOCITY defines the way notes are being played: Velocity 0 – 100 = NOTE ON. Triggers the envelope. Duration of the envelope is defined by the MIDI command CC 57.
- Page 5 16V +3.3V 10uF 100nF tant 16V tant 16V 10uF AUDIO OUTPUT 100nF DAC DATA VOUTR DAC CLK BCKIN DAC WS LRCIN 100K MCLK VOUTL 16.000MHz WM8762 6.35mm JACK CLOCK 32.000MHz +3.3V +3.3V MC74HC74AD Figure 1-4: BassBoy MIDI device schematic MikroElektronika...
- Page 6 BassBoy technical support : andigo.office@gmail.com MikroElektronika...
