Notice
CORRECTION
SERVICE FLASH
Please add this notice to the Service Manual listed below.
Category :
Multi-media Projector
Model :
Destination :
NOTE: Match the Chassis No. on the unit's back cover with the Chassis No. in the Service
Manual.
If the Chassis. No. does not match the unit's, additional service literature is required.
Only the difference service information is given in this manual. For detailed service
information, refer to the original service manual and notice for Models PLV-70, PLV-70L.
Reason of the production change:
As this production change is to comply with RoHS, PWB units and some parts are changed.
Major chaged parts are as follows;
PWB BOARD
Main Board
A/V Board
I/F Board
Control Baord
RC Front Baord
Connect Board
Senser1 Board
FILE WITH ORIGINAL SERVICE MANUAL
PRODUCT CODE
PLV-70
PLV-70L
1 122 130 60 1 122 130 70
1 122 131 60 1 122 131 70
1 122 131 62
PRODUCTION CHANGE
●
ADD INFORMATION
PLV-70
PLV-70L
Canada, U.S./Europe,
Asia, Africa, U.K.
SM5110361 for PLV-70
SS5110737 for PLV-70L
Issued Date :
Chassis No.
Effective from :
REF. NO. :
FILE NO.
REVISION-5
July / 2005
M4L-7004
M4L-70L01
SM5110361
SM
REFERENCE NO.
5110361-05
