Speaker: reproduces the audio
Page Up: moves the cursor up one page
(disabled during games)
: moves the cursor left/right
Previous, next: makes a selection,
advances or reverses quickly through a file
: moves the cursor up/down
Vol +/-: increases or decreases the volume
Page Down: moves the cursor down one
page (disabled during games)
Remote control eye: receives the
commands from the remote control unit
Docking Station
CHARGE BATTERY
Flip down the pins
110Vac/60Hz
Install the DC plug
into the DC IN
power socket.
TV/LCD: press and hold to select
PocketDISH or TV for viewing
THIS PDF WAS DOWNLOADED FROM SATELLITEGUYS.US
THIS PDF FILE WAS DOWNLOADED FROM SATELLITEGUYS.US
DC-IN (power): connected to the AC/DC power adapter that
came with PocketDISH
Video: record video only from a TV. For recording audio, also
connect the analog AV-cable to the AV in connector
AV out: send the audio and video from the PocketDISH to a TV
AV in: record audio and video from a TV or audio device onto
the PocketDISH
CONNECT HEADSET
ON Charging
4 Hours Up to 4 hours
Flashing Ready
Headphones
USB-A (Host): connect USB (mass
storage device) compatible equipment,
like a camcorder, digital photo camera or
a USB flash drive
Upper, Center and Bottom Setup keys: to open and navigate through
the Setup menus, sub-menus and options to personalize your settings.
The upper and bottom Setup key are also used as Game Control key.

Charge the Battery

Your PocketDISH has a rechargeable Li Ion battery. The Li Ion battery
is a high capacity power source. Do not use another battery charger
or AC/DC adapter. For your safety, charge the Li Ion battery only with
the AC/DC adapter that came with the PocketDISH. Failing to do so
can cause permanent damage to equipment and can result in serious
personal injury.
00 ... 99
CHANGE VOLUME
Press and hold to increase
the volume
Press and hold to decrease
the volume

SPEAKER / HEADPHONES

Built-in speaker on/off: toggles
between speaker and headset.
USB-B (Device): connect to a compatible
DISH Network DVR or computer
Power (DC IN): connect to the AC/DC power
adapter that came with the PocketDISH
Speaker: reproduces the audio
ON: shows that PocketDISH is turned on
HDD: the hard drive is active when lit
CHG: a solid light indicates that PocketDISH is
connected to the battery charger. If charging is
complete, the light flashes
TV OUT: shows that the screen content is displayed on
a TV
ON: press and hold to turn on PocketDISH
Play: starts playback
Pause: pauses playback
Enter: acknowledges a selection
OFF: press and hold to turn off PocketDISH
Stop: stops playback
Escape: quits a selection
Exit: pauses or exits a game
Battery latch
CHANGE VOLUME
Min Volume control:
If nothing is heard, while volume
control on PocketDISH is set to
maximum, adjust the in-line volume
control to a higher level until sound
Max
is heard.
