Summary of Contents for AMagic ACV-3313B
- Page 1 HDMI 3-to-1 Switch User Manual ACV-3313B Specialize in high-clear video management...
- Page 2 User Manual Connection picture Connection picture...
- Page 3 User Manual Chapter 8. technology specifications Copyright belongs to aMagic Limited. All rights reserved Technology Index Declaration of Exemption. 1. Please read this manual carefully before use, we won't bear any losses if not according to our manual. HDMI SWITCH 2.
- Page 4 User Manual User Manual Chapter 8. technology specifications Catalog Technology Index Chapter 1. S ecurity and proceeding notice Chapter 2. Included fittings Chapter 3. F unction introduction Compliant to HDMI 1.3 and HDCP Chapter 4. P ort Introduction Transfer distance Audio input voltage 3vp-p impedance:47 Chapter 5.
- Page 5 User Manual User Manual Chapter 7. abnor mity phenomena and solution Chapter 1. security and proceeding notice Why appear blue screen on monitor? Please check to see if power supply light is illuminated and power supply is normal, Before installation and Please read this manual if ok, please check to see if the video channels of TV (HDMI) is chosen and input connection, Plese make...
- Page 6 User Manual User Manual Chapter 2. Included fittings Chapter 6. Setup introduction debugging Power on/off keystroke Press on-off keystroke of power supply after installation. Automatically identify signal input and output after turn on switch if it is only I channel signal input.If many channels signal input at the same time.The switch will acquiescence the output port as minimum(CH1<CH2<CH3).Also you can pressCH1/CH2/CH3 keystroke to switch signal source.
- Page 7 User Manual User Manual Chapter 5. Installation and Connection guides Chapter 3. Function introduction Connection guides Sketch map(look down) Make sure to turn off all the connected equipments. One end of the HDMI cable connect to equipment with HDMI output.(eg:DVD,STB,SP3 etc.) The other end of the HDMI cable connect to CH1,CH2 or Ch3 of HDMI switch.
- Page 8 User Manual User Manual Chapter 3. Function introduction Chapter 4. Por t introduction Functions Plug & Play no software or driver requirement. The best audio/video format will be Keystrokes chosen automatically via negotiation between Signal source and monitor. DC....to connect DC 5V/1A power supply HDMI OUT..to connect TV with HDMI interface Close output CH1/2/3.to connect equipment with HDMI interface...
