HD-4001 Quad Input DVB-T HD Encoder/Modulator

Table of Contents

Safety Precautions..........................................................................................................................................2
Package Contents ...........................................................................................................................................2
Product Description........................................................................................................................................3
Specification...................................................................................................................................................4
Installation......................................................................................................................................................5
Hardware Installations and Connections........................................................................................................5
Connecting to the GUI Interface:...................................................................................................................6
Encoder Programming and Setup via GUI Interface: ....................................................................................6
Overview Page of Zycast Encoder.................................................................................................................6
Common Setup...........................................................................................................................................7
RF Setup....................................................................................................................................................9
Encoder Setup ............................................................................................................................................9
Network Configuration ...........................................................................................................................11
Administration............................................................................................................................................12
Saving your configuration files....................................................................................................................12
Front Panel LCD Encoder Menu Map .........................................................................................................13
Modulator Configuration via Front Panel LCD ...........................................................................................14
Network Setup............................................................................................................................................18
ASI Output .................................................................................................................................................18
EAS ...........................................................................................................................................................19
HD-4001DM User Guide and Install Manual
User Guide and Install Manual
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HD-4001 digi-mod and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for resi-linx HD-4001 digi-mod

  • Page 1: Table Of Contents

    HD-4001 Quad Input DVB-T HD Encoder/Modulator User Guide and Install Manual Table of Contents Safety Precautions............................2 Package Contents ............................2 Product Description............................3 Specification..............................4 Installation..............................5 Hardware Installations and Connections......................5 Connecting to the GUI Interface:........................6 Encoder Programming and Setup via GUI Interface: ..................6 Overview Page of Zycast Encoder.........................6 Common Setup............................7 RF Setup..............................9...
  • Page 2: Safety Precautions

    Safety Precautions The presence of this symbol is to alert the installer and user to the presence of uninsulated dangerous voltages within the product’s enclosure that may be of sufficient magnitude to produce a risk of electric shock. TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS DEVICE TO RAIN OR MOISTURE.
  • Page 3: Product Description

    Product Description resi-linx digi-MOD HD Series Encoder/Modulators provides a DVB-T & ASI output stream - making it ideal for any Commercial RF Network. The high quality HD design allows for watching action packed movies and sports channels on any HDTV. The optional AC-3 Dolby Audio, EAS, and AES-128 Encryption capabilities rounds out the feature rich product series.
  • Page 4: Specification

    Specification VIDEO INPUTS (Video by Priority) HDMI 1.4v Component YprPb (RCA) Composite CVBS (RCA) AUDIO INPUTS Audio Inputs L/R (RCA) Video Encoder Mode MPEG-2, MPEG-4(AVC) Video Resolutions 1080p (AVC Only), 1080i, 720p, 576p, 576i, 480p, 480i AUDIO Encoder Audio Compression MPEG-1 Layer II, AAC, AC-3 (Optional), AC-3 Pass Through RF DVB-T Support Frequency...
  • Page 5: Installation

    Installation System Installer must adhere to Article 820-40 of the NEC that provides guidelines for proper grounding and specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as possible. Unpacking and Inspection Each unit is shipped factory tested.
  • Page 6: Connecting To The Gui Interface

    Step 1: Right Click and Select “View device Webpage”. Overview Page of resi-linx digi-MOD HD Overview status of the Encoder when fully functioning. Alternate between viewing status of RF Output 1 and RF Output 2 by selecting the RF Output section of the device you want to monitor.
  • Page 7: Common Setup

    Note: Image displays the Quad version of the HDT Encoder. Step 2: Login Select Common Setup Once the Common Setup Tab is selected you will be prompted to enter the user name and password for device. Default User Name: admin Default Password: Admin123 Note: To change the Password for the GUI go to the Administration Tab Step 3: Common Setup Tab...
  • Page 8 2: Upload and Reboot. Notes on Channel Selection: The image below shows the Output Channel is set to CH # 21. RF1 will output 1 QAM signal carrying 2 digital audio/video channels (within your device's Bandwidth settings). The device will automatically set RF2 to Ch # 22. Using the above example the Physical Channel Outputs for the Quad Input device would be set: 21.1, 21.2 and 22.1, 22.2.
  • Page 9: Rf Setup

    CH # 68 CH # 69 Step 5: RF Setup RF Setup Use the RF Setup Page to setup each RF Output. Select RF Output 1 or RF Output 2. Select and set the required parameters you require for your installation. Step 6: Local Save Once all parameters are set you are required to do a Local Save.
  • Page 10 NOTE: There will be an Encoder tab present for each input on the device. Step 8: Local Save for each Encoder tab Once all parameters are set you are required to do a Local Save on EACH Encoder Tab where changes were performed.
  • Page 11: Network Configuration

    Step 10: Network Configuration Tab Network Configuration Use the Network Setup Tab to configure the device’s IP address, Subnet Mask, Gateway, Enable/Disable DHCP, and set Host Name. Step 11: Save Network Configuration Save Config: Once all parameters are set you are required to select Save Config. This function will reboot and save the changes setting for the Network Configuration.
  • Page 12: Administration

    Step 12: Administration Administration Administration Page Functions Actions Reboot Reboot device. All unsaved settings will be lost. Reset to Default Reset all settings back to original factory settings Backup Download all settings of device Upload Upload a saved config file New Password Create and save new password for GUI Step 13:...
  • Page 13: Front Panel Lcd Encoder Menu Map

    Front Panel LCD Encoder Menu Map Common Setup Output Channel Attenuation LCN Mode Device Address Default Configuration Back to Main RF SETUP Select RF Constellation Guard Interval OFDM RF Output Cell ID TS ID Network ID Org Network ID Network Name Back to Main ENCODER SETUP Encoder Setup...
  • Page 14: Modulator Configuration Via Front Panel Lcd

    Modulator Configuration via Front Panel LCD Once the encoder is powered up it will go through its initial booting process. Once the unit has completed its initial “Booting” up process the LCD will display IN-1..., Bit Rate information, Channel-1.., and other information in the LCD Display Window.
  • Page 15 Common Setup Menu Output Channel – Use the Scroll Up/Down button to change the output channel. Use the Scroll Up/Down buttons to select the desired output channel. Once the desired output channel is selected press the OK button to set the channel. The LCD Display will show both the channel number and the frequency number of the output channel (example: 21 480.5000MHz) Note: The RF2 Channel Physical output is determined by the selection of output channel of RF1...
  • Page 16 FEC- Use the Scroll Up/Down button to select the FEC menu. Press the OK button to enter  the FEC menu. Use the Scroll Up/Down button to select the desired FEC setting and press the OK button to set. GUARD INTERVAL –...
  • Page 17  Video Input Use the Scroll Up/Down button to select Video Input. Press the – OK button to enter the Video Input menu. Use the Scroll Up/Down button to select the Video Input option: Auto, Composite, Component, or HDMI. Factory default: Auto.
  • Page 18: Network Setup

    Analog. Factory Set: Analog.  Audio Output Use the Scroll Up/Down button to select Audio Output. Press the OK – button to enter the Audio Output menu. Use the Scroll Up/Down button to select the Audio Output option: MP2 (MPEG2 Layer I Audio), AAC, or AC3. Factory default: MP2. Press the OK button to set.
  • Page 19: Eas

    This device may be equipped EAS Terminals/connections and CVBS (Video Input) and L/R audio input connections on the rear panel. If applicable, connect your EAS Alert Device System outputs to the Encoder. If the encoder receives the proper Event signal from your EAS device, the normal input audio/video would be replaced by the audio and video from the EAS system device.
