INSTRUCTION MANUAL
POWER
Depress POWER ON button to turn on tuner. Turn off
tuner by depressing button again to release it to the out
position.
RECEPTION
AM
Depress AM button. Turn TUNING knob until pointer
indicates desired station on AM (bottom) dial. Adjust TUN-
ING knob until needle on tuning meter shows maximum
deflection to right.
FM RECEPTION
Depress FM and FM MUTE buttons. Turn TUNING
FM TUNER SECTION
TUNING RANGE: 87.5 MHz to 108.5 MHz @ 3 0 0 f-I
QUIETING SENSITIVITY: 1.5µV for 30 db @ 72fl
0.5µV for 20 db @ 72n
HARMONIC DISTORTION: 0.3% at 100% modulation.
FREQUENCY RESPONSE: 20-20,000 Hz fldb (after de-emphasis).
HUM AND NOISE LEVEL: 70 db below 100% modulation.
ALTERNATE CHANNEL SELECTIVITY: 60 db. LHFM
DETECTOR BANDWIDTH: 900 kHz.
CAPTURE RATIO: 1.9 db.
IMAGE REJECTION: 60 db.
I.F. REJECTION: 85
db.
CROSS MODULATION REJECTION: 80
ANTENNA: 3OOfI balanced; 720 unbalanced or built-in line.
PRlNTED IN U.S.A.
10-70A
OPERATING INSTRUCTIONS
SPECIFICATIONS
db.
LEAR SIEGLER, INC.
BOGEN DlVlSION
PARAMUS, N. J. 07652
knob until pointer indicates desired station on FM (top)
dial. Carefully adjust TUNING knob until needle on tuning
meter is at the center of the tuning dial, exactly on the
circle above the letters "FM".
NOTE
Muting removes the annoying noise between FM
stations. The muting circuitry may prevent the
receiver from distinguishing a very weak signal
from interstation noise. To tune in very weak
stations, defeat the mute circuit by releasing
the FM MUTE switch to the out position.
AM TUNER SECTION
TUNING RANGE: 530 kHz to 1620 kHz.
LOOP SENSITIVITY: 2µV @ 6db S/N and 60% modulation.
ALTERNATE CHANNEL SELECTIVITY: (±l0 kHz) 40 db.
HARMONIC DISTORTION: Less than 1% @ SO% modulation
MISCELLANEOUS
AUDIO OUTPUT: Adjustable (rear panel), 0-1.2V
OPERATING CONTROLS: Selector (Power, AM, FM, FM
Mute), Tuning.
POWER CONSUMPTION: 60W @ 120 vac, 6OHz
OVERALL DIMENSIONS: 14-l/2" W x 3-3/4" H x 12" D
RACK INTERIOR DIMENSIONS: 14" W x 3-l/4" H x 11" D
WEIGHT: 9-l/2 Ibs.
MODEL TP160
AM/FM TUNER
54-5516-01
