Summary of Contents for Winmate T4-series
- Page 1 T4-series Panel PC VIA Eden Mini-ITX Fanless SBC, Low Power Design with VIA Platform, TFT LCD and 10/100/1000 base-T Ethernet. User Guide Version 1.0 T4 series Panel PC User Guide...
-
Page 2: Fcc Statement
FCC Statement This device complies with part 15 FCC rules. Operation is subject to the following two conditions： This device may not cause harmful interference. This device must accept any interference received including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a class "a" digital device, pursuant to part 15 of the FCC rules. -
Page 3: Copyright Notice
If the customer discovers a defect, Winmate will, at its option, repair or replace the defective product at no charge to the customer, provided it is returned during the warranty period of one year, with transportation charges prepaid. -
Page 4: Check List
Customer Service We provide service guide for any problem as follow steps：First, visit the website at http://www.winmate.com to find the update information about the product. Second, contact with your distributor, sales representative, or our customer service center for technical support if you need additional assistance. You may have the following information ready before you call：... -
Page 5: Safety Precautions
Safety Precautions Warning! Always completely disconnect the power cord from your chassis whenever you work with the hardware. Do not make connections while the power is on. Sensitive electronic components can be damaged by sudden power surges. Only experienced electronics personnel should open the PC chassis. - Page 6 Safety and Warranty Please read these safety instructions carefully. Please keep this user's manual for later reference. Please disconnect this equipment from any AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. Use a damp cloth. For pluggable equipment, the power outlet must be installed near the equipment and must be easily accessible.
-
Page 7: Revision History
Revision History Version Date Note Author 2007.10.19 First Version Shawn 2007.11.19 Initial Release Shawn T4 series Panel PC User Guide... -
Page 8: Table Of Contents
Contents CHAPTER 1 GENERAL INFORMATION..................1 1-1 Introduction .....................1 1-2 V170 SBC and T4 series Panel PC System Specifications ......2 1-3 LCD Selection Guide..................3 CHAPTER 2 GETTING STARTED.....................4 2-1 Input / Output Devices..................4 2-2 Starting the Panel PC& O/S Installation............5 2-3 Driver Installation....................5 CHAPTER 3 TOUCH DRIVER INSTALLATION................6 3-1 Introduction .....................6 3-2 The ELO AccuTouch Driver Installation............7... -
Page 9: Chapter 1 General Information
Chapter 1 GENERAL INFORMATION 1-1 Introduction The T4 series Panel PC is fanless, low power PC with VIA CX700 single chipset combines with a TFT LCD Panel. The VIA Eden energy efficient processor delivers the most performance per watt available in the market. The Panel PC is designed to satisfy most of the applications in the industrial market, such as POS, KIOSK, Industrial Automation, HMI and Programmable Control System. -
Page 10: V170 Sbc And T4 Series Panel Pc System Specifications
1-2 V170 SBC and T4 series Panel PC System Specifications System Specification Processor VIA Eden™ 1.0GHz by EBGA Type Chipset VIA CX700 Single Chipset Memory Two DDR2 slots 240 pin Support up to 2GB DDR2 400 / 533 SDRAM BIOS Award 4Mbit Graphic Chipset Integrated VIA UniChrome™... -
Page 11: Lcd Selection Guide
1-3 LCD Selection Guide The T4 series Panel PCs various dimensions of TFT Panel w/ touchscreen function. Please refer the following table: Resolution Item Size Model Name Display Color (Recommended) 10.4” R10V17T-OFM3 1024x768 16.2M (6bits/color) 10.4” R10V17T-OFP1 800 x 600 262,144 (6bit/colors) 10.4”... -
Page 12: Chapter 2 Getting Started
Chapter 2 Getting Started 2-1 Input / Output Devices The following figure shows the I/O arrangement of the Panel PC. The backside of the chassis contains most of the connectors (10.4” for example). The Motherboard provides two PS/2 interface. The PS/2 PS/2 connector supports Keyboard (Green) and Mouse. -
Page 13: Starting The Panel Pc& O/S Installation
2-2 Starting the Panel PC& O/S Installation Connect the power to AC/DC adapter, and connect the power cord to the AC outlet. Press the power on switch to start the Panel PC. Press “DEL” to enter the CMOS setting and check the BIOS setup. You may install your own O/S if it is not installed. -
Page 14: Chapter 3 Touch Driver Installation
Chapter 3 Touch Driver Installation 3-1 Introduction The PPC supports three kinds of Touch Panel Solutions: ELO AccuTouch touchscreen, Premier Touch system. Both of the touchscreen system consists of a touchscreen and an electronic touchscreen controller. The T4 series Panel PC’s touch device is used RS232 interface touch controller card via the COM1 port inside Panel PC. -
Page 15: The Elo Accutouch Driver Installation
3-2 The ELO AccuTouch Driver Installation ELO AccuTouch driver software provides a consistent software interface among all ELO AccuTouch touch screens and controllers. Go to http://www.elotouch.com/Support/dnld.asp for a complete list of available drivers. For Driver Installation, please install the “ELO Touch System Touch Tools CD” for Windows XP, Windows 2000, Windows Me, Windows 98, Windows 95, Windows NT, Windows CE 2.x, 3.0, 4.x, Windows XP Embedded, Windows 3.1, DOS, OS/2 Warp, and Apple Macintosh. -
Page 16: Configuration Utility
3-2-1 Configuration Utility After finishing the installation, please follow the steps to test the configuration utility. Step.1 Enter “My Computer”, click the “Elo touchscreen” shortcut function. Step.2 Click “Align” function key to go to next step. T4 series Panel PC User Guide... - Page 17 Step.3 Correct 4 point locations on screen with the Panel PC. Screen display as follows. Step.4 Touch the “yes” function if the cursor follows your finger and finish the utility test. T4 series Panel PC User Guide...
-
Page 18: The Premier Touch Driver Installation
3-3 The Premier Touch Driver Installation TouchKit is the Premier Touch software, which contains drivers of the touch panel controllers for the specified communication connectors, RS232, PS/2 and USB, and the other two utilities. The two utilities are as follows: Touch Tray support This is utility for emulating the right and left button of mouse through controlling touch panel. -
Page 19: Configuration Utility
3-3-1 Configuration Utility After finishing the installation, please follow the steps to test the configuration utility. Step.1 Click the “TouchKit” shortcut function in the desktop. Step.2 Enter “General” function and choose the language you need. Then go to next step. T4 series Panel PC User Guide... - Page 20 Step.3 Correct 4 point locations on screen with the Panel. Screen display as follows Step.4 Play “Yes” to continue if 4 points calibration test is fine and finish the test. T4 series Panel PC User Guide...
-
Page 21: Chapter 4 T5 Series Panel Pc Mounting Guide
Chapter 4 T5 series Panel PC Mounting Guide The Panel PC is suitable for most of the industrial/commercial application, by any kind of mounting approach. Three main mounting approaches, such as Panel Mount / Chassis / Open Frame, are very easy for user to install the Panel PC. - Page 22 Panel PC size VESA Mount Dimension Panel PC size VESA Mount Dimension 75 x 75 mm / 10.4” 75 x 75 mm 17” 100 x 100 mm 75 x 75 mm / 12.1” 75 x 75 mm 19” 100 x 100 mm 75 x 75 mm / 75 x 75 mm / 15”...
-
Page 23: 5Mm Panel Mount Panel Pc
4-2 5mm Panel Mount Panel PC: -Panel is aligned with the same height of the front of open frame metal housing. -Touch/Glass is higher than Open frame metal housing. -Customers can fix our Panel PC with their fixture (max.12mm) -VESA mount holes are also available for mounting from back side. T4 series Panel PC User Guide... - Page 24 PANEL PC PM 5mm PANEL PC size Mounting Kits(pcs) 10.4” 12.1” 15” 17” 19” 20.1” T4 series Panel PC User Guide...
-
Page 25: 10Mm Ip65 Panel Pc
4-3 10mm IP65 Panel PC -Touch/Glass is aligned with the same height of the front of open frame metal housing -Customers can fix our Panel PC with their fixture by M3 screws. -VESA mount holes are also available for mounting from back side. T4 series Panel PC User Guide... - Page 26 T4 series Panel PC User Guide...
-
Page 27: Chassis Panel Pc
4-4 Chassis Panel PC Fix the Panel PC with four screws (standard VESA), and fasten to the wall with other four screws. - 100 x 100 mm - 75 x 75 mm Panel PC size VESA Mount Dimension Panel PC size VESA Mount Dimension 75 x 75 mm / 10.4”... -
Page 28: Notices
NOTICES 1. The Operation Systems we currently support are Windows XP and XP Embedded. When installing driver, please make sure you’re using Windows XP Service Package1 (SP1) above. 2. The VGA output port for V170 is only for displaying the same images as built-in display.
