Valloy Incorporation Any-001 Anytron User Manual

Digital color label press
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Valloy Incorporation
Any-001

User Manual

Anytron. Digital Color Label Press

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Any-001 Anytron and is the answer not in the manual?

Questions and answers

Summary of Contents for Valloy Incorporation Any-001 Anytron

  • Page 1: User Manual

    Valloy Incorporation Any-001 User Manual Anytron. Digital Color Label Press...

  • Page 2: Table Of Contents

    Ver 1.0.6 (12 -Dec-2012) Table of Contents ............................... 3 1.Certification and Safety ........................... 3 1.1. Status of certification ..........................3 1.2. afety instructions 1.2.1. Installation ................................ 3 1.2.2. In use ................................... 3 ......................4 1.3. Legal validity of this document ............................
  • Page 3 ..................24 6.3. How to mount 6 inch and 4 inch Paper ........................ 27 6.4. Overall operating process ..................29 6.5. Checking alignment of mounted media ..............................31 7.Printing Operation ............... 31 7.1. How to use the basics of illustrator for any-001 .......................

  • Page 4: Certification And Safety

    1. Certification and Safety 1.1. Status of certification Registration Number : KCC-REM-BTI-ANY-001 1.2. Safety instructions - Because safety instructions are necessary to prevent accidents or dangers, please make sure to follow them to ensure that you use this product safely. 1.2.1.

  • Page 5: Legal Validity Of This Document

    1.3. Legal validity of this document We inform you that this manual does not carry legal binding force, and we reserve the right to change this manual at will without giving a separate notice.

  • Page 6: Components Of The Product

    2. Components of the Product 2.1. Overview 2.2. Component names and descriptions 2.2.1. Press station Name Description Mechanical part to control the process of hanging, feeding roll Press Station paper and winding it back after printing. Part to mount roll paper. The unwinder releases as much Unwinder paper as is needed to feed the printer, which allows the paper to keep its tension constant.
  • Page 7 Cutter Cuts continuous paper when finishing ordered printing. Guide for paper moving from the feeding roller to the printer. Feeding Guide Role of aligning paper horizontally evenly during printing. Button Panel Front panel with 2 LEDs and 4 buttons 1. POWER LED LED to check on/off conditions of the station LED to check whether the sensor detects marks in the sensing 2.

  • Page 8: Digital Printer

    2.2.2. Digital printer Name Description Digital Printer Printing device Top Cover Release The top cover is opened by pressing the button. Button Top Cover The cover is opened by pressing the button 1. Operator Panel Menu-based control and LCD panel Multi-purpose Tray Tray for using continuous media Front Cover Release...

  • Page 9: Installation Of The Product

    3. Installation of the Product 3.1. Requirements for installation 3.1.1. Overview -This product is a printing device and digital electronic communication equipment. Accordingly, this product can implement optimum printing quality only if it is installed in a place meeting environmental requirements for digital equipment as well as the conditions required for a label printer. For this reason, our company makes it a rule to professionally install our products by our staff or our designated agency’s personnel and we request that customers follow our personnel’s suggestion for the locations of the equipment along with the environmental requisites for optimal operation.

  • Page 10: Delivery

    3.1.4. Delivery -The installation personnel will completely install this product and software (such as the printer driver) and also a test printa roll of continuous paper. At this time, the delivery will be completed by the customer’s signature on the receipt. 3.2.

  • Page 11: Installation Of The Printer (Digital Press)

    3.3. Installation of the printer (digital press) Carrying, installation and securing of the printer: After unpacking the printer box, place the  printer on the press station, and then secure the printer and the mechanics together tightly with bolts in the box (refer to the figure). Existence of Various Consumables (Toner, Cartridge, Transfer Belt, Fuser) Checking ...
  • Page 12 ① ~⑤: Check the IP. (refer to 4.1) ⑤...

  • Page 13: Installation Of The Printer Driver

    4. Installation of the Printer Driver 4.1. Installation of the Driver Execute [Device and Printer] on the start menu. Click [Add a Printer] on the activated window. Click [Add a Local Printer].
  • Page 14 Click [Next] as the default value of [Use an Existing Port] when connecting through a USB. Select [Standard TCP/IP Port] of [Make a New Port], and then click [Next] when using LAN. After entering a printer’s IP address, click [Next]. Installation of the (Refer to the 3.3 printer fo...
  • Page 15 After clicking [Computer] on the finding location, select [Anytron Driver] in the [Anytron] media device, and then click the [Open]. Click [OK]. After checking the OKI WEB61, click [Next]. After entering a printer name, click [Next].
  • Page 16 After selecting [Do not share this printer], click [Next]. After selecting [Set as the Default Printer], click [Checking a Test Page] for checking the connection. (There should be A4 papers in the tray 1.) The installation will be completed when pressing [Close] and [End] after identifying the printed test page.

  • Page 17: Configuration Of The Roll (Continuous Paper) Driver

    4.2. Configuration of the Roll (Continuous Paper) Driver 1. After right clicking the Anytron driver in the [Devices and Printers], click the Default Print Setup. 2. Set the Size as the Super Long Paper in the Default Print Setup. 3. In the message box opened at this time, click the OK to change the paper source.
  • Page 18 4. Enter a desired printing edit size into the Width, Length. (Ex- A4 size print: 210x297) 5. Footer marginthe space between printed units, Start is the beginning point of the images,andcut is the cutting point after finishing all work.
  • Page 19 6. Set the Adjust Mode as the No Adjustment when using regular roll media. 7. Set the Weight as the Labels 2 when using regular matt papers(art papers).

  • Page 20: Description Of The Printing Mode

    4.3. Description of the Printing Mode - There are three printing modes for the Any-001 as the figure. Adjust Mode Sensing Description Print continuously after sensing the black mark once at the Normal beginning No Adjustment Print continuously without using the sensor (Default) Print consecutively by sensing every image unit’s black mark continuously Mode to support pre-cut papers...

  • Page 21: Multiple Of Printing According To Image Length

    4.4. Multiple of printing according to Image Length - Multiples of images to be printed in Any-001 vary according to label size. For example, Length 100mm image is printed as multiples of five. Thus, 10(5*2) images are printed if you enter the number of output as ‘9’. This is equally applied in Adjustable mode.

  • Page 22: Installation Of The Software

    Installation of the Software - Refer to the separate RIP manual. Mounting and Operation of the Roll (Continuous Paper) 6.1. Specification of the Roll (Continuous Paper) and Cautions 6.2. How to Mount Basic (215mm) Paper After pressing 215mm paper to the unwinder’s left guide and mounting it, turn the knob A to fix the paper.
  • Page 23 After moving paper to the cutter along the path viewed in the photo, fasten the lever A. Press the Feed(>) button on the right of the panel to move paper to the printer’s entry. Mount an empty paper jointing tube of 215mm on the rewinder.
  • Page 24 Move the paper printed out like the path viewed in the photo, and fix it on the empty paper jointing tube with tapes. When printing, shaft2 and tension bar of Unwinder are very hot. A high temperature- warning label is attached, so please DO NOT TOUCH the part.

  • Page 25: How To Mount 6 Inch And 4 Inch Paper

    6.3. How to Mount 6 Inch (4 Inch) Paper A grid is marked on each shaft and bobbin for center-aligning paper. This is the guide for aligning paper. Four guides are required for aligning 6 inch paper. Move the guide up to the 6 inch marking of the unwinder bobbin.
  • Page 26 After mounting 6 inch paper on the bobbin, fix the guide also on the other side. Turn the knob to fix the bobbin’s paper and the guide. This is the unwinder mounting 6 inch paper. Fix the guide matching with 6 inch also on the shaft grid marking of the unwinder.
  • Page 27 Fix the guide matching with 6 inch also on the shaft grid marking of the rewinder. Mount a 6 inch paper jointing tube also on the rewinder identical to the unwinder.

  • Page 28: Overall Operating Process

    6.4. Overall Operating Process When starting to print with mounting paper, the feeding roller on the printer’s entry pulls the paper. If the paper is pulled, the tension bar in front of the printer would move up. At this time, the unwinder releases the roll paper by rotating at a speed proportional to the extent of the tension bar’s moving up...
  • Page 29 When printing is completed, the cutter cuts the paper. If you want to print again, use the Feed(>) button to move the paper to the printer’s entry.

  • Page 30: Checking Alignment Of Mounted Media

    6.5. Checking Alignment of Mounted Media - Create a working window of a 215x200mm document on the illustrator. - Make two vertical lines (90˚) of 200mm with two lines of the tool box. - Align the two lines as the figure, respectively.
  • Page 31 - Check the operating line whether the printed media has an equal margin at the both side. - If the margins are not the same, adjust the unwinder’s guide to print them identically. If the operating line is printed at the center, put the media on the rewinder to adjust the guide, and check whether the media is...

  • Page 32: Printing Operation

    7. Printing Operation 7.1. How to Use the Basics of Illustrator for Any-001 Create a new file with a width of 215mm and a desired height. ( Ex – 215 x 250 mm ) Make a black mark of 6 x 6mm on the top left of the base sheet.
  • Page 33 The RIP converts it into a printable file. (Save the file as an.PDFformat.)

  • Page 34: How To Use Pre-Cut Media

    7.2. How to use Pre-Cut Media - Overview When printing in the Any-001, if using media of the pre-cut form, the cutting procedure of the post-process can be skipped to save time and costs. 7.2.1. Adjustment of the Sensor’s Location and how to auto-sensing -Can choose the black mark sensor or gap sensor as an option Gap(Slot) Sensor Black-Mark Sensor...
  • Page 35 -How to auto-sensing of Gap sensor Button As the photo, pressing the button once on between the die-cut labels and once on the label, the sensor setting would be completed. -How to check the sensor is normally set Move the paper back and forth to sense the black mark for checking whether it is normally set.

  • Page 36: How To Change The Sensor

    How to change the sensor 7.2.2. - Use Black Mark Sensor for label that black mark is pre-printed. - Use Gap Sensor for Pre-cut label. - Black Mark Sensor and Gap Sensor are variable according to the purpose of use. - A sensor alter switch is equipped with as shown in the picture below.

  • Page 37: How To Use The Slongtool

    <Adjustable mode> - The case of setting a value of the ‘Start’option as 50.5mm Each output page would be printed from 50.5mm after sensing the black mark. To print on the pre-cut media, be sure to select this mode. <Normal mode> - The case of setting a value of the ‘Start’...
  • Page 38 Footer Margin: Footer Margin in “adjustable” mode is a sensing area and location-adjustable value. (Footer Margin ≥ 2) -When using the SLongTool, various usable data may be created. Here, enter more than 2 Footer Margin value when you configure printer driver as shown in the above example...

  • Page 39: Post-Printing Process (Cutting Andlaminating)

    8. Post-printing Process (cutting andlaminating) 8.1. Digitalization of process after printing It is an Any-Cut equipment for precision (laminating, die cutting) of roll printed through Any-001. For details related to Any-Cut, please visit www.anytron.netfor inquiry and instruction guide.

  • Page 40: Maintenance And Management

    9. Maintenance and Management 9.1. Overview 9.2. Types of Errors on the Printer (Press) LCD Messages and Its Description -Refer to the additional printer manual. 9.3. Checking of Consumables’ Replacement Cycle and Replacing 9.3.1. Checking of consumable’s replacement cycle Installation Personnel (Name: Tel: If the printer is connected through Ethernet, you may check the residual...

  • Page 41: Replacing Consumable Items

    Select the menu of consumables you want to check. Cyan Drum may check the residual quantity as shown in the picture. 9.3.2. Replacing consumable items - Only use genuine original consumables to ensure the best quality and performance from your hardware.
  • Page 42 (a) Pull thecoloured toner release lever on the cartridge to be replaced fully towards the front of the printer. (b) Lift the right-hand end of the cartridge and then draw the cartridge to the right To release the left-hand end as shown, and withdraw the toner cartridge out of The printer.
  • Page 43 5. Remove the new cartridge from its box but leave its wrapping material in place for the moment. 6. Gently shake the new cartridge from end to end several times to loosen and distribute the toner evenly inside the cartridge. 7.
  • Page 44 10. Pressing gently down on the cartridge to ensure that it is firmly seated, push the coloured lever towards the rear of the printer. This will lock the cartridge into place and release toner into the image drum unit. 11. Gently wipe the LED head surface with a clean, lint free cloth. 12.

  • Page 45: Image Drum Replacement

    9.3.2.2.Image Drum replacement CAUTION :Static sensitive devices, handle with care. WARNING :If the printer has been powered on, the fuser will be hot. This area is clearly labeled. Do not touch 1.Press the cover release and open the printer’s top cover fully. 2.
  • Page 46 CAUTION :The green image drum surface at the base of the ID unit is very delicate and light sensitive. Do not touch it and do not expose it to normal room light for more than 5 minutes. If thedrum unit needs to be out of the printer for longer than this, please wrap the cartridge insidea black plastic bag to keep it away from light.
  • Page 47 9.Push the coloured release lever away from you to lock the toner cartridge onto the new image drumunit and release toner into it. 10.Holding the complete assembly by its top centre, lower it into place in the printer, locating the pegsat each end into their slots in the sides of the printer cavity.

  • Page 48: Replacing The Transfer Belt Unit

    9.3.2.3.Replacing the Transfer Belt Unit - The belt unit is located under the four image drums. - Switch off the printer and allow the fuser to cool about 10 minutes before opening the cover. 1.Press the cover release and open the printer’s top cover fully. 2.
  • Page 49 5.Turn the two fasteners 90° to the left. This will release the belt from the printer chassis. 6. Pull the lifting bar (b) upwards so that the belt tilts up towards the front, and withdraw the belt unit (c)from the printer. 7.

  • Page 50: Fuser Replacement

    9.3.2.4.Fuser replacement - The fuser is located inside the printer just behind the four image drum units. WARNING :If the printer has recently been powered on, some fuser components will be very hot. Handle the fuser with extreme care, holding it only by its handle, which will only be mildly warm to the touch.

  • Page 51: Clean The Led Heads

    7. Lower the fuser into the printer, locating the two lugs (c) into their slots in the metal partition which separates the fuser area from the image drums. 8. Push the two retaining levers (b) towards the rear of the printer to lock the fuser in place. 9.

  • Page 52: Purchasing Of Consumables

    9.4. Purchasing of Consumables Please refer to the Anytron home page at www.Anytron.net. 9.5. Inquiry and Download Please refer to the Anytron home page at www.Anytron.net...

  • Page 53: Product Specifications

    Product Specifications Digital Press Plain paper Print speeds (Max)up to 9m/m (8.26 x 11.7 inch) Temperature 50°F – 89.6°F Operating Environment (cut paper) Humidity 20 – 80% RH Operating Environment Temperature 62.6°F – 80.6°F (continuous) Humidity 40 - 60% RH Media weight 64 –...
  • Page 54 SUPPLIES(8.26 x 11.7inch) Toner Cartridge Mono 11,000 pages Life Color 11,500 pages Image Drum Life Continuous printing :28,000 pages Transfer belt 60,000 pages Fuser unit 60,000 pages PRESS STATION Dimensions(LxWxH) 64 x 23 x 15(inch) (38 x 58 x 162 cm) Maximum 11.8 inch (30 cm) Roll Diameter...

  • Page 55: Service Guide And Product Warranty

    -If you need any more information on the product and A/S service, visit our home page at www.anytron.net, or contact us by [phone] or [email]. VALLOY Incorporation Room 403, Haeju Bldg., #639-5, Ilwon-dong, Kangnam-gu, Seoul, Korea 135-231 Tel : +82-2-6082-5022 Fax : +82-2-445-5441 e-mail : support@valloy.net...
