3/3 Techno Park Drive Williamstown North VIC Australia 3016
Phone: 03 9397 3993 Fax: 03 9397 3994
Email:
ultimate@virginbroadband.com.au
Web: www.ultimatesolar.com.au
INSTALLATION MANUAL
USB 24/30 KIT
CAUTION
When working with this equipment:
Shut off water supply to prevent scalding and burning
Notice
1. Consult or hire professionals in your area for your installation, the lightening arrester
should be considered in installation.
2. The system has to be mounted facing NORTH.
3. All exposed piping should be insulated properly to prevent heat loss and provide freezing
protection.
4. Any modifications on the structures of water heater might lead to problems during service..
Advertisement
Table of Contents
Summary of Contents for Ultimate Solar USB 24
-
Page 1: Installation Manual
Phone: 03 9397 3993 Fax: 03 9397 3994 Email: ultimate@virginbroadband.com.au Web: www.ultimatesolar.com.au INSTALLATION MANUAL USB 24/30 KIT CAUTION When working with this equipment: Shut off water supply to prevent scalding and burning Notice 1. Consult or hire professionals in your area for your installation, the lightening arrester should be considered in installation. -
Page 2: Installation Orientation
INTRODUCTION USB series solar water heaters are all-glass evacuated solar domestic water systems combined with heat pipes. The selective coating in the inner cover of the evacuated tubes ensures high energy absorption and low heat radiance losses, which converts solar energy into heat energy and transfers to the heat pipe by an aluminium fin. - Page 3 Specifications of SB series solar domestic water systems SB- 1800/Φ SB- 1800/Φ SB- 1800/Φ SB- 1800/Φ SB- 1800/Φ Model 58-AL-12 58-AL-18 58-AL-20 58-AL-24 58-AL-30 Weight for 10.00 12.50 14.00 17.00 21.50 Manifold KG) Packing Size 1130*170*190 1610*170*190 1770*170*190 2090*170*190 2570*170*190 for manifold Weight for Heat 30.30...
- Page 4 Component and Material Tab.1 Name Material Front leg SUS201 Back leg SUS201 Diagonal bar SUS201 Diagonal bar of upright SUS201 support Bazi bar SUS201 Top reflector bar SUS201 Baseboard SUS201 The manifold Aluminum Heat Pipe Boron silicon3.3 The bottom holder of the PA66 heat pipes The bottom support...
- Page 5 Features - Very fast start-up even under low solar irradiance, due to the small heat capacity of the heat pipe combined with good thermal conductivity of the aluminium fin which contacts the inside of the inner glass tube. - Utilisation all year round even in cold climates; - The system will still operate in the event of occasional tube breakages;...
-
Page 6: Parts Included
Parts included The front leg The back leg Side diagonal bar Diagonal bar forback legs 5. Middle bar . Top middle bar Baseboard The manifold Heat pipe The bottom holder of the heat pipes The bottom support Screws M8X16 M6X25 M6X45... -
Page 7: Installation
INSTALLATION Fix the middle holes of the cross supports with M6×25 screws, and then connect the three back legs together. See the picture below. Using the M8×16 screws to connect the upper rail with the three front legs, and also fix the upper rail with the left and right front legs by u sing... - Page 8 Put the aluminum manifold on the top of the front legs with the link parts. And install the bottom support on the bottom of the front legs. Put the plastic holder of the heat pipes in the bottom support. Fasten the baseboard on the front legs with the bolt and nuts M6×45. Insert the heat pipes: Heat Pipe - 9 -...
-
Page 9: Series Connection
Solar Collector Connecting The connecting of the collectors to a collector array can de designed according to the location and position of the system. Different ways of the connecting reflects the different operation efficiency. And generally parallel connection and in series connection is suitable for the collectors as shown with below drawings. - Page 10 Installation on the roof: The optional reflecting angle for SB series solar collector is 20°, 30° and 40° according to the locallongitude and latitude. Procedures: 1. Put the assembled frame on the roof. 2. Move the tile according to the location of the hole on the front support and baseboard for frame.
- Page 12 Maintenance for the system Maintenance - There’s maybe dust and oil existing in water pipe when installing. Please turn out the tap to get rid of the sundries at the first using. - For collector surface, please do the cleaning regularly according to the local dusty rate. Raining can clean the solar water heater and maintaining a clean surface can be higher collection efficiency.
