Page 5: Chapter 1 Introducing The Motherboard
Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the 945GCT-HM motherboard. This motherboard is a high perfor- mance, enhanced function motherboard designed to support the LGA775 socket Intel Core 2 Duo (E4400/E4300)/Pentium D/Pentium 4/Celeron D processors for high-end business or personal desktop markets. - Page 6 Feature Processor The motherboard uses an LGA775 type of Intel Core 2 Duo (E4400/E4300)/Pentium D/Pentium 4/Celeron D that carries the following features: • Accommodates Intel Core 2 Duo (E4400/E4300)/Pentium D/Pentium 4/Celeron D processors • Supports a system bus (FSB) of 800/533 MHz •...
-
Page 7: Onboard Lan
Audio • 5.1 + 2 Channel High Definition Audio Codec • All DACs support 192K/96K/48K/44.1KHz DAC sample rate • High-quality analog differential CD input • Meets Microsoft WHQL/WLP 3.0 audio requirements • Direct Sound 3D compatible Onboard LAN The onboard LAN controller provides the following features: •... -
Page 8: Motherboard Components
Motherboard Components Introducing the Motherboard... - Page 9 Table of Motherboard Components LABEL COMPONENTS LGA775 socket for Intel Core 2 Duo/Pentium 1. CPU Socket D/Pentium 4/Celeron D CPUs 2. CPU_FAN CPU cooling fan connector 240-pin DDR2 SDRAM slots 3. DIMM1/3 Standard 24-pin ATX power connector 4. ATX1 Floppy disk drive connector 5.
