Summary of Contents for Neue IWM 601 W

  • Page 1 User manual Washing Ma- chine IWM 601 W...
  • Page 2: Table Of Contents

    Contents Safety information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 2 Daily use _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 11 Safety instructions _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3 Care and cleaning _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 13 Product description _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 4...
  • Page 3: Safety Instructions

    • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. • The operating water pressure (minimum and maximum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa) •...
  • Page 4: Product Description

    • Use this appliance in a household environment. • Do not use water spray and steam to clean the ap- • Obey the safety instructions on the detergent pack- pliance. aging. • Clean the appliance with a moist soft cloth. Only use •...
  • Page 5: Control Panel

    Compartment for liquid additives (fabric softener, starch). Follow the product manufacturer’s recommendations on quantities to use and do not exceed the «MAX» mark in the detergent dispenser drawer. Any fabric softener or starching additives must be poured into the compartment before starting the wash programme.
  • Page 6: Washing Programmes

    Delay Start When selecting a washing programme both lights A The start of the programme can be delayed by 3, 6 or 9 and B illuminate. hours by means of this button. After having pressed the button 5 the only light cor- Indicator pilot light responding to the running phase stays on.
  • Page 7 Programme Maximum and Minimum Temperature Cycle Description Detergent Options Maximum Spin Speed Compartment Maximum Fabrics Load Type of Laundry SPIN REDUCTION COTTON + ECONOMY RINSE HOLD 40° PREWASH Main wash - Rinses EXTRA RINSE Maximum spin speed at 1200 rpm Max.
  • Page 8 Programme Maximum and Minimum Temperature Cycle Description Detergent Options Maximum Spin Speed Compartment Maximum Fabrics Load Type of Laundry SPIN REDUCTION MIX 20° RINSE HOLD Main wash - Rinses EXTRA RINSE Maximum spin speed 900 rpm Max. load kg 3 kg Special programme for cotton, synthetic and mixed fabric with light soil.
  • Page 9: Consumption Values

    Programme Maximum and Minimum Temperature Cycle Description Detergent Options Maximum Spin Speed Compartment Maximum Fabrics Load Type of Laundry For cancelling the programme which is running or to switch the machine off . 1) If you select the Super Quick option by pressing button 3, we recommend that you reduce the maximum load as indicated. Full loading is possible however with somewhat reduced cleaning results.
  • Page 10: Helpful Hints And Tips

    Off Mode (W) Left On Mode (W) The information given in the charts above are in compliance with the EU Commission regulation 1015/2010 implementing directive 2009/125/EC. Helpful hints and tips Sorting out the laundry Ball point pen and glue: moisten with acetone , lay the garment on a soft cloth and dab the stain.
  • Page 11: First Use

    Your appliance incorporates a recirculation system • you are washing a small load which allows an optimal use of the concentrated deter- • the laundry is lightly soiled gent. • large amounts of foam form during washing. Follow the product manufacturer’s recommendations Degrees of water hardness on quantities to use and do not exceed the «MAX»...
  • Page 12 Select the required programme by turning the Select the delay start by pressing the button 6. programme selector dial (1) Press button 5: Turn the programme selector dial to the required pro- – the machine starts its hourly countdown. gramme. The green pilot light of the button 5 starts to –...
  • Page 13: Care And Cleaning

    Opening the door If you have set a programme or an option that ends with water left in the tub, the light C illuminates. The After the programme has started the door is locked. If, door remains locked to indicate that the water must be for any reason, you need to open it, set firstly the ma- emptied out before opening the door.
  • Page 14 Cleaning the drawer recess Having removed the drawer, use a small brush to clean the re- cess, ensuring that all washing powder residue is removed from the up- per and lower part of the When no more water comes out, unscrew the pump recess.
  • Page 15 Cleaning the water inlet filters • Screw the hose back to the machine and make Important! If the appliance doesn't fill, takes long to fill sure the connection is tight. with water, the starting button blinks yellow or the • Turn on the water tap. display (if available) shows the relevant alarm (see chapter "What to do if..."...
  • Page 16: What To Do If

    What to do if… Certain problems are due to lack of simple mainte- Once the problem has been eliminated, press the but- nance or oversights, which can be solved easily with- ton 5 to restart the programme. If after all checks, the out calling out an engineer.
  • Page 17 Problem Possible cause/Solution Too much detergent or unsuitable detergent (creates too much foam) has been used. • Reduce the detergent quantity or use another one. Check whether there are any leaks from one of the inlet hose fittings. It is not always easy to see this as the water runs down the hose;...
  • Page 18: Technical Data

    Problem Possible cause/Solution The electronic unbalance detection device has cut in because the laundry is not evenly distributed in the drum. The laundry is redistributed by re- verse rotation of the drum. This may happen several times before the un- balance disappears and normal spinning can resume.
  • Page 19: Installation

    Installation Unpacking carpets, rugs etc. Check that the machine does not touch the wall or other kitchen units. All transit bolts and packing must be removed before using the appliance. Level the washing ma- You are advised to keep all transit devices so that they chine by raising or lower- can be refitted if the machine ever has to be transpor- ing the feet.
  • Page 20 Water inlet The appliance must be connected to a cold water supply. Caution! A minimum water pressure of 0.05 MPa (0.5 bar) is • This appliance must be connected to a required for safe operation of the appliance. cold water supply. If you cannot make the cold water connection direct •...
  • Page 21: Building In

    If you intend to drain the hose from the machine into a sink, make sure that the sink is empty and the plug hole is not blocked. Use the plastic “U - Piece” sup- plied. In the interest of the environment The appliance should be connected to the FOUL drain- Min.
  • Page 22 Preparation and assembly of the door The machine is originally prearranged for the assem- bly of a door opening from right to left. In this case it is sufficient to screw in the hinges (1) and the counter-magnet (6) provided with the appli- min.
  • Page 23: Front View

    • a) Door d) Counter-magnet (6) The dimensions of the door should be: The appliance is prearranged for a magnetic closure - width 595-598 mm of the door. - thickness 16-22 mm To enable a correct operation of this device, it is nec- The height (C-Fig.
  • Page 24: Environmental Concerns

    Where the appliance has been raised by mounting Graphic H onto a wooden base provided by the installer. The material used to construct the base should have anon slip surface, be water repellent and if possible be one solid piece. If it is not possible to use one solid piece, due to the additional height required, ensure that any additional Hardwood strip...
  • Page 25 Ecological hints • With adequate pre-treatment, stains and limited soil- ing can be removed; the laundry can then be wash- To save water, energy and to help protect the environ- ed at a lower temperature. ment, we recommend that you follow these tips: •...
  • Page 28 132912830-A-262013...
