  • Page 1 Installation and Operating Instructions Built-In Loudspeaker 1258 00...
  • Page 2 Device description With the built-in loudspeaker, the Gira Door Communication System is integrated in let- terbox systems, speech compartments, door side installations or front panels. The built-in loudspeaker assumes the function of a door station. It has two mounting openings which are matched to the mounting systems of common installation solutions.
  • Page 3 Device presentation Front 1 Loudspeaker 2 Mounting opening 3 Microphone Back 4 Interfaces System: Connection for add-on module or other system components Video: Connection of the UP colour camera 5 Terminal strip BUS: Connection to the 2-wire bus ZV: Supply of UP colour camera etc. 0: Common earth for bell buttons 1 - 8: Connection for bell buttons...
  • Page 4 Mounting Attention Installation and mounting of electrical devices may only be carried out by a quali- fied electrician. The built-in loudspeaker in mounted behind the speech cover plate of the existing sys- tem. Depending on the design, this is carried out directly on the front panel or via an installation carrier.
  • Page 5 Use only the screws provided to mount the built-in loudspeaker. When positioning the built-in loudspeaker, make sure that both the microphone and the loudspeaker are mounted in front of the sound openings. Here the position of the microphone should be given a higher prior- ity.
  • Page 6 3. Connect the bell buttons. The maximum cable length is 2 m. Do not connect "0" terminal When using an add-on module, the "0" ter- minal of the built-in loudspeaker may not be connected to the "0" terminal of the add- on module.
  • Page 7 Connecting door communication components Due to the full compatibility of the built-in loudspeaker to the door communication sys- tem, flush-mounted inserts, such as a colour camera, info module or call buttons, can also be connected. Colour camera 1. Connect the flush-mounted insert of the colour camera with the built-in speaker using the 2-pole video connection cable and the 6-pole audio connection cable.
  • Page 8 Start-up Once you have installed all of the devices (built-in loudspeaker, home station, control device etc.), you can put the door communi- cation system into operation. Commissioning is described in the system manual included with the control device. Note When commissioning large systems, please note that a maximum of 20 bell but- tons can be temporarily stored per work step.
  • Page 9 Operation Volume setting The volume can be set separately at each door station. The volume setting must be made by two people. 1. Start programming mode at the control device by pressing the "System progr." button for 3 seconds until the yellow LED next to the button starts flashing.
  • Page 10 5. End the voice connection. The most recently set volume level is saved in the door station. 6. Exit programming mode at the control device by briefly pressing the "System progr." button.
  • Page 11 We accept the guarantee in accordance with the corresponding legal provisions. Please return the unit postage paid to our central service department giving a brief description of the fault. Gira Giersiepen GmbH & Co. KG Service Center Dahlienstraße 12 42477 Radevormwald...
  • Page 12 Gira Giersiepen GmbH & Co. KG P.O. Box 1220 42461 Radevormwald Tel +49 21 95- 602-0 Fax +49 21 95- 602-339 info@gira.de www.gira.com...
