Land Pride RBT40 SERIES Brochure

Ideal for ditching,
road grading and
all-around farm use.
RBT40
SERIES
65 - 100 HP — 84"
• Cat. 1 or 2 hitch
• Hydraulic adjustments with
hose and fittings
• Angle up to 45°
• Offset up to 30" left or right
• Tilt up to 15°
• 17" Moldboard precisely formed
to roll dirt ahead
• 5/16" Moldboard with fully welded
box reinforcement
• 3 1⁄8" Solid steel kingpin handles high
torque loads
• Fully welded main frame for stability
14
• Retractable parking stand for storage
and ease of hook-up
• Optional skid shoes and side plates
• Reversible cutting edge for longer wear
• An optional cylinder cushion valve
is available to help protect the blade
and cylinders in the event an
obstruction is hit.
96" 108"
Skid shoes and end plates are ideal aides
for large grading jobs.
Make
changes
On The Go
with our 3-Way
Hydraulic Rear
Blades
