18v 1/2 inch (13mm)
Cordless Drill/Driver
Perceuse-visseuse sans fil
de 18v 1/2 po (13 mm)
Taladro/destornillador inalámbricos
de 18v y 13 mm (1/2 pulg.)
Instruction manual
Manuel d'instructions
Manual de'instrucciones
www.portercable.com
INSTRUCTIVO DE OPERACIÓN,
CENTROS DE SERVICIO Y PÓLIZA DE
GARANTÍA.
ADVERTENCIA: LÉASE ESTE
INSTRUCTIVO ANTES DE USAR EL
PRODUCTO.
CATALOG NUMBER
PCL180CD
Advertisement
Table of Contents
Related Manuals for Porter-Cable PCL180CD
Summary of Contents for Porter-Cable PCL180CD
- Page 1 18v 1/2 po (13 mm) Taladro/destornillador inalámbricos de 18v y 13 mm (1/2 pulg.) Instruction manual Manuel d'instructions Manual de'instrucciones www.portercable.com INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO. CATALOG NUMBER PCL180CD...
-
Page 2: General Power Tool Safety Warnings
General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. -
Page 3: Specific Safety Rules
4) Power tool use and care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use the power tool if the switch does not turn it on and off. -
Page 4: Safety Guidelines - Definitions
WARNING: ALWAYS use safety glasses. Everyday eyeglasses are NOT safety glasses. Also use face or dust mask if drilling operation is dusty. ALWAYS WEAR CERTIFIED SAFETY EQUIPMENT: • ANSI Z87.1 eye protection (CAN/CPA Z94.3), • ANSI S12.6 (S3.19) hearing protection, •... -
Page 5: Functional Description
Shock hazard. Do not allow any liquid to get inside charger. Burn hazard. To reduce the risk of injury, charge only designated CAUTION: PORTER-CABLE batteries. Other types of batteries may burst causing personal injury and damage. CAUTION: Under certain conditions, with the charger plugged in to the power supply, the charger can be shorted by foreign material. - Page 6 The charger and battery pack are specifically designed to work together. • These chargers are not intended for any uses other than charging designated PORTER-CABLE rechargeable batteries. Any other uses may result in risk of fire, electric shock or electrocution.
-
Page 7: Storage Recommendations
• Charge the battery packs only in PORTER-CABLE chargers. • DO NOT splash or immerse in water or other liquids. This may cause premature cell failure. • Do not store or use the tool and battery pack in locations where the temperature may reach or exceed 105°F (40˚C) (such as outside sheds or metal buildings in... - Page 8 Bad Battery The charger can detect a weak or damaged battery. The LED flashes in the pattern indicated on the label. If you see this bad battery blink pattern, do not continue to charge the battery. Return it to a service center or a collection site for recycling.
-
Page 9: Led Work Light
WARNING: Safety Warnings and Instructions: Drills 1. Hold the drill firmly with two hands, one hand on the handle, and the other gripping the bottom around the battery area. 2. When attaching accessories in the drill chuck, hand tighten the keyless chuck firmly. - Page 10 Adjusting Torque Control - Figure F This tool is fitted with a torque adjustment collar (3) to select the operating mode and to set the torque for tightening screws. Large screws and hard workpiece materials require a higher torque setting than small screws and soft workpiece materials.
-
Page 11: Maintenance
United States to facilitate the collection of spent Li-Ion batteries. Help protect our environment and conserve natural resources by returning the spent Li-Ion battery to an authorized PORTER-CABLE service center or to your local retailer for recycling. You may also contact your local recycling center for information on where to drop off the spent battery. -
Page 12: Troubleshooting
We cannot guarantee repairs made or attempted by others. You can also write to us for information at PORTER-CABLE, 4825 Highway 45 North, Jackson, Tennessee 38305, (888) 848-5175 - Attention: Product Service. Be sure to include all of the information shown on the nameplate of your tool (model number, type, serial number, etc.). -
Page 13: Three-Year Limited Warranty
The following are PORTER-CABLE trademarks for one or more power tools and accessories: a gray and black color scheme; a “four point star” design; and three contrasting/outlined longitudinal stripes. The following are also trademarks for one or more PORTER-CABLE and Delta products: 2 BY 4®, 890™, Air America®, AIRBOSS™, Auto-Set®, B.O.S.S.®, Bammer®, Biesemeyer®, Builders Saw®, Charge Air®, Charge Air Pro®, CONTRACTOR SUPERDUTY®, Contractor's...
